TREMONTI
USER MANUAL
PHASER
CONGRATULATIONS
on your purchase of Tremonti Phaser, the signature phase shifter
brought to you by T-Rex Engineering and Mark Tremonti.
Tremonti Phaser gives you everything you could ask for in a modern
phase shifter. From a raw 70s grind to 21st-century sophistication, a few
simple controls put you in charge of the entire history of phase-shifted
tone. Take a few minutes to read this manual, and then plug in your axe
and start mangling your sound.
We promise you’ll enjoy yourself!
SET THE CONTROLS...
The main controls on Tremonti Phaser are the DEPTH, RATE, LEVEL and
BITE knobs, and the 4 STAGE/8 STAGE switch.
DEPTH determines the degree of modulation, or how heavy your
phased sound is. Turn it down for a subtler shift, and crank it up for a
radical mangle.
The RATE knob controls the phase speed – from almost imperceptible
motion, to a fast and freaky warble. To start with, try combining a slow
RATE setting with a high DEPTH rate, and cut back on the DEPTH as you
increase your RATE.
LEVEL determines the pedal’s overall output volume.
The BITE knob adds just a touch of overdrive edge to your phased
sound to give you an even more authentic vintage tone.
The 4 STAGE/8 STAGE switch lets you choose between a more primi-
tive early-70s phased sound (4-STAGE) and a higher-resolution phase
(8-STAGE) that might be more at home in music from the 80s, 90s and
beyond.
We recommend that you experiment with different combinations of
these settings, since each separate parameter will affect all the others.
STEREO OUT
Tremonti features a stereo output so you can take advantage of all the
glory of stereo chorus/flange when you’re in the studio or running a
stereo live setup. If you think The Tremonti Phaser sounds great in mono,
try running it in stereo. It will blow your mind!
I have never used many effects but the phaser
is one I have always enjoyed.
T-Rex gave me the opportunity to collaborate
with them to create the perfect pedal.
The pedal is transparent, dynamic, and
durable and has the great tones that T-Rex is
known for.
I love it! - Mark Tremonti
TECHNICAL SPECIFICATIONS
Input Impedance@1KHz 464 KOhm
Output Impedance@1KHZ 37 Ohm
Power supply 9V DC (Power tool 9)
Minimum Power supply Voltage 8,5V DC
Maximum Power supply Voltage 12,5V DC
Current Draw @ 9V DC 81 mA
Maximum Input signal Vp/p Adjustable
Battery Type 9 V battery 6F22
Battery Life 30 - 60 min.
External connectors Input Jack., Output Jack (L), Output
Jack (R), 9V DC jack
Controls On/Off, Level, Depth, Rate, Bite
4 Stage / 8Stage switch
Depth 120 mm
Width 100 mm
Height 55 mm
Weight (excl. battery) 0,430 kg
RoHS
REACh
T-REX WARRANTY CONDITIONS
T-Rex oers a 2-year warranty on all our products. In the unlikely event of a
malfunction, please contact our technical support at info@t-rex-eects.com
before sending us the product for repair. When the product has been sent to
us at sender’s cost, we will repair or replace your product and send it back to
you - free of charge and usually within 3 weeks (shipping not included). The
product needs to be accompanied by a copy of your receipt, serial number,
return address, phone number, e-mail address and a brief explanation of
the problem. Please note that we cannot replace a product until we have
received it here in Denmark.
The warranty is lost if the product has been damaged by alteration, misuse,
accident, or neglect; or if the product has been repaired or serviced by
persons not authorized by T-Rex. Read more about warranty conditions at
www.t-rex-eects.com.
ABOUT T-REX
Based in Vejle, Denmark, T-Rex Engineering makes classic and sig-
nature eects pedals for the world’s best musicians. Our approach
blends hi-tech innovation with old-world craftsmanship – always
in the service of killer tone.
EU REGULATIONS • ENVIRONMENT PROTECTION
T-Rex accepts and follows the regulations and directives issued
by the EU. We nd these environment protecting regulations very
good, and we are happy to follow them.
ISSUED IN VEJLE, 2009
Lars Dahl-Jørgensen
Development Director
Sebastian Jensen
Production Director
T-Rex Engineering ApS
www.t-rex-eects.com
