TRENDnet TEW-692GR Manuel utilisateur

Quick Installation Guide

TEW-692GR

1.01

Table of Contents

Version 05.05.2011

English 1

Troubleshooting 10

Wireless Tips

1. Before You Start 1

2. Hardware Installation 4

3. Configure the Wireless Router 6

ENGLISHFRANÇAISDEUTSCHESPAÑOL

РУССКИЙ

1. Before You Start

Package Contents

System Requirements

TEW-692GR

Multi-Language Quick Installation Guide

CD-ROM (User's Guide)

Network Cable (1.5m / 5ft)

Power Adapter (12V DC, 1A)

A computer with a wired or wireless network adapter properly installed

(Note: It is recommended that you configure the Wireless Router from a wired

computer)

Web Browser: Internet Explorer (6.0 or higher), Firefox 2.0 (6.0 or above), Opera,

Chrome, Safari

Broadband Internet

Installed Cable or DSL Modem

ENGLISHFRANÇAISDEUTSCHESPAÑOL

РУССКИЙ

Collect Internet Service Provider (ISP) Information

Please verify your Internet broadband connection type with your ISP and ensure you have all the information for

one of the following connection types:

1. DHCP (Dynamic IP Address)

Host Name (Optional): ________________

Manually Configure DNS (Enable/Disable)

Primary DNS Server: _____. _____._____._____

Secondary DNS Server: _____. _____._____._____

Use Default MTU Setting (Enable/Disable)

MTU (default: 1500)

MAC Address Clone (Enable/Disable)

2. Static IP Address

IP Address: _____. _____._____._____ (e.g. 215.24.24.129)

Subnet Mask: _____. _____._____._____

Default Gateway: _____. _____._____._____

Primary DNS Server: _____. _____._____._____

Secondary DNS Server: _____. _____._____._____

Use Default MTU Setting (Enable/Disable)

MTU (default: 1500)

MAC Address Clone (Enable/Disable)

3. PPP over Ethernet

User Name: ________________

Password: ________________

Manually Configure DNS (Enable/Disable)

Primary DNS Server: _____. _____._____._____

Secondary DNS Server: _____. _____._____._____

Operation Mode (Keep Alive, On Demand, Manual)

Keep Alive Mode Redial Period (Default: 10 seconds)

On Demand Mode Idle Time (Default: 5 minutes)

Use Default MTU Setting (Enable/Disable)

MTU (default: 1500)

MAC Address Clone (Enable/Disable)

4. PPTP

PPTP Server IP Address: ________________

User Name: ________________

Password: ________________

Address Mode: Dynamic IP or Static IP

IP Address:_____. _____._____._____ (e.g. 215.24.24.129)

Subnet Mask: _____. _____._____._____

Default Gateway: _____. _____._____._____

Operation Mode (Keep Alive, On Demand, Manual)

Keep Alive Mode Redial Period (Default: 10 seconds)

On Demand Mode Idle Time (Default: 5 minutes)

Primary DNS Server: _____. _____._____._____

Secondary DNS Server: _____. _____._____._____

Use Default MTU Setting (Enable/Disable)

MTU (default: 1500)

MAC Address Clone (Enable/Disable)

ENGLISHFRANÇAISDEUTSCHESPAÑOL

РУССКИЙ

5. L2TP

Server IP Address : ________________

User Name: ________________

Password: ________________

WAN Interface IP Type: Dynamic IP or Static IP

IP Address:_____. _____._____._____ (e.g. 215.24.24.129)

Subnet Mask: _____. _____._____._____

Default Gateway: _____. _____._____._____

Operation Mode (Keep Alive, On Demand, Manual)

Keep Alive Mode Redial Period (Default: 10 seconds)

On Demand Mode Idle Time (Default: 5 minutes)

Primary DNS Server: _____. _____._____._____

Secondary DNS Server: _____. _____._____._____

Use Default MTU Setting (Enable/Disable)

MTU (default: 1500)

MAC Address Clone (Enable/Disable)

ENGLISHFRANÇAISDEUTSCHESPAÑOL

РУССКИЙ

2. Hardware Installation

Note: Gather all information related to your Internet Connection before you start. If necessary,

contact your Internet Service Provider (ISP).

Cable/DSL Modem

Internet

1. Verify that you have an Internet connection

when connecting your computer directly to the

Cable or DSL modem. Open your browser (e.g.

Internet Explorer) and type in a URL (e.g.

http://www.trendnet.com) in the address bar.

2. Power off your cable or DSL modem.

3. Disconnect the network cable from your Cable

or DSL modem and your computer.

4. Connect one end of a network cable to one of

the TEW-692GR's network ports. Connect the

other end of the cable to the computer's

network port.

5. Connect one end of a network cable to the

TEW-692GR's WAN port. Connect the other

end of the cable to your modem's network port.

ENGLISHFRANÇAISDEUTSCHESPAÑOL

РУССКИЙ

7. Power on your cable or DSL modem. Wait until

the LEDs indicate that modem is fully booted

up. Consult with the modem user's guide for

more information.

6. Connect the Power Adapter to the TEW-692GR

and then to a power outlet. Move the power

switch to the “On” position (EU version only).

8. Verify that the following panel lights are on:

Power (Green), LAN (port (1,2,3,4) your

computer is connected to)(Green), WAN

(Green), Wireless (2.4GHz)(Green) and

Wireless (5GHz)(Blue). Please see trouble

shooting section for additional information on

LED behaviors.

ENGLISHFRANÇAISDEUTSCHESPAÑOL

РУССКИЙ

3. Configure the Wireless Router

Note: It is recommended that you configure the Wireless Router from a wired computer.

3. Click Wizard.

1. Open your web browser, type

http://192.168.10.1 in the Address bar, and

then press Enter.

2. Enter the User Name and Password and then

click OK. By default:

User Name: admin

Password: admin

Note: User name is case sensitive.

4. Click Launch Internet Connection Setup

Wizard.

5. Click Next.

ENGLISHFRANÇAISDEUTSCHESPAÑOL

РУССКИЙ

10. Click Wizard.

6. Select the proper Internet Connection Type.

Configure the settings based on information

provided by your ISP. Then click Next.

Note: Each Internet Connection type may have

different options.

7. Click Apply.

8. Click OK.

9. Please wait while the router reboots.

11. Click Wireless Security Setup Wizard.

ENGLISHFRANÇAISDEUTSCHESPAÑOL

РУССКИЙ

12. You will need to configure the following:

Wireless Network Name (SSID) (2.4GHz)

Wireless Network Name (SSID) (5GHz)

The SSID is the wireless network name of

your wireless network (e.g. wireless router or

access point). Enter a unique SSID. Choose

something that you would easily identify when

searching for available wireless networks.

Then click Apply.

Note:

1. To protect your network from any unauthorized access it is recommended to enable wireless

encryption.

2. The example below is for WPA-PSK/WPA2-PSK (AES) (Best) security. If you select WPA-PSK

or WPA2-PSK, make sure your wireless adapters support WPA or WPA2. If your wireless

adapters do not support WPA or WPA2, then select WEP (Good).

3. WEP encryption only supports 802.11b/g speed of up to 54Mbps.

4. Once encryption is enabled on the router, each wireless computer and device must be

configured with the same encryption key.

13. Select Best and then click Apply.

14. Enter characters for your wireless security

password and then click Apply. For

WPA-PSK or WPA2-PSK, the Pre-Shared Key

must be between 8 and 63 ASCII or 64 HEX

characters. Make sure to copy down the

Pre-Shared Key. You will need the Pre-Shared

key when you configure your wireless

adapter(s).
