TRENDnet TEW-634GRU Manuel utilisateur
TEW-634GRU
rev:07.23.2009
• Wi-Fi compliant with IEEE 802.11n and IEEE 802.11b/g standards
• 4 x 10/100/1000Mbps Auto-MDIX LAN port and 1 x 10/100Mbps WAN port (Internet)
• Supports Cable/DSL modems with Dynamic IP, Static IP, PPPoE, PPTP, L2TP & BigPond connection types
• High-speed up to 300Mbps data rate using IEEE 802.11n connection
• H2 x 2dBi external antennas support high speed performance and great coverage with MIMO technology
• Support Wi-Fi Protected Setup (WPS) for easy connection
• Universal Plug and Play (UPnP)
• Provides additional security of enable/disable wireless SSID, Internet Access Control (MAC Address, Domain & IP Filtering)
• Easy management via web browser and remote management
• Supports 64/128-bit WEP, WPA/WPA2 and WPA-PSK/WPA2-PSK
• Works with Windows 95/98/NT/2000/XP/2003 Server/Vista, Linux and Mac OS
• *Coverage up to 100 meters (330ft.) indoor and 300meters (980ft) outdoor (depends on the environment)
• 3- year limited warranty
FEATURES
The 300Mbps Wireless N Gigabit Router with USB Port (model TEW-
634GRU) incorporates the latest wireless n technology, Gigabit Ethernet
ports and a convenient USB port to create a secure high performance
wireless local area network.
Connect USB flash drives, hard drives or printers directly to the router,
to share data across your wirelessly local area network.
A robust firewall and advanced wireless encryption protects your
network. Wi-Fi Protected Setup (WPS) integrates other WPS devices
into your network quickly. Advanced MIMO antenna technology
optimizes wireless coverage. Quality of Service (QoS) technology
prioritizes gaming, Internet calls and video streaming. An intuitive
installation process and remote management capabilities make this
product well suited for your most demanding networking needs.
TEW-634GRU(V1.0R)
300Mbps Wireless N Gigabit Router with USB Port
*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage
will vary depending on interference, network traffic, building materials and other conditions.
** Internet Explorer 6.0 and above is recommended
Internet Access Control
LAN
WAN
WPS Button
Power Consumption
• Wired: IEEE 802.3/u Fast Ethernet, IEEE 802.3ab Gigabit Ethernet
• MAC Address Filter, Domain/URL Filter, Protocol/IP Filter
• 1 x 10/100Mbps Auto-MDIX port (Internet)
• 4 x 10/100/1000Mbps Auto-MDIX port
• Enable Wi-Fi Protected Setup function
• Dynamic IP, Static (Fixed) IP, PPPoE, PPTP, L2TP, BigPond
• 1 x USB 2.0, 1.1 Compliant USB Type A Port
USB
Connection Type
Standards
Hardware
SPECIFICATIONS
Frequency
Media Access Protocol
• 2412~2484MHz ISM band
• 2 x 2dBi detachable dipole antennas
• DBPSK/DQPSK/CCK/OFDM (BPSK/QPSK/16-QAM/64-QAM)
Wireless
• 1~ 11 (FCC), 1~13 (ETSI)
• WPA(AES/TKIP): WPA/WPA2, WPA-PSK/WPA2-PSK
• WMM enable/disable feature
Modulation Technique
Data Rate
Security
• Protocol filtering
QoS
Output Power
• Wireless: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n (draft 2.0), IEEE 802.11e QoS
Power Adapter
LED Indicator
Dimension (L x W x H)
Humidity
Weight
Temperature
Certifications
• 12V DC, 2A external power adapter
• 7watts (max.)
• Power, LAN1~LAN4, WAN, and WLAN
• 245g (8.6 oz)
• Operation: 0°C~ 40°C (32°F~ 104°F); Storage: -10°C~ 70°C (-4°F~158° F)
• 10%~95% RH, no condensation
• CE, FCC
Antenna
• CSMA/CA with ACK
• 802.11b: 11Mbps, 5.5Mbps, 2Mbps, and 1Mbps
• WEP(HEX/ASCII): 64/128-bit
• 802.11b: 15dBm (typical)
• Enable/Disable broadcast SSID
• 150 x 110 x 30 mm (5.9 x 4.3 x 1.1 inches)
TEW-634GRU
rev:07.23.2009
TEW-634GRU(V1.0R)
300Mbps Wireless N Gigabit Router with USB Port
• USB: v1.0, 1.1, 2.0
• 802.11g: 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 9Mbps and 6Mbps
• 802.11n: up to 300Mbps
• Domain filtering
Receiving Sensitivity
Channels
• 802.11g: 15dBm (typical) • 802.11n: 14dBm (typical)
• 802.11b: 11Mbps -85dBm (typical) @ 10% per
• 802.11g: 54Mbps -68dBm (typical) @ 10% per
• 802.11n: 300Mbps -59dBm (typical) @ 10% per
NETWORKING SOLUTIONS
TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet
products and is subject to change at any time, without notice. For the most recent product information please visit
http://www.trendnet.com.
©
Copyright TRENDnet. All Rights Reserved.
RELATED PRODUCTS
PACKAGE CONTENTS
TEW-642EC
TEW-641PC Wireless N PC Card
• CD-ROM (User’s Guide)
300Mbps Wireless N Express card
• TEW-634GRU
• Multi-Language Quick Installation Guide
ORDERING INFORMATION
To Order Please Call:
1-888-326-6061
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: 1-310-961-5500
Fax: 1-310-961-5511
Web:
Email: [email protected]
www.trendnet.com
TEW-623PI Wireless N PCI Adapter
• Power adapter (12V DC, 2A)
• Cat. 5 Ethernet cable (1.5m / 5ft.)
TEW-634GRU(V1.0R)
300Mbps Wireless N Gigabit Router with USB Port
300Mbps wireless multimedia sharing
300Mbps Wireless N
Gigabit Router with USB Port
(TEW-634GRU)
Notebook with 300Mbps
Wireless N USB Adapter
(TEW-624UB)
Cable/DSL
Modem
Workstation with Gigabit PCI Adapter
(TEG-PCITXR)
USB Hard Drive
Internet
USB Printer
OR
Workstation with 300Mbps
Wireless N PCI Adapter
(TEW-623PI)
Gigabit
TEW-644UB Wireless N USB Adapter
