TRENDnet TV-IP612WN Manuel utilisateur
Quick Installation Guide
TV-IP612WN
1.01
Table of Contents
Version 08.26.2010
English 1
1. Before You Start
2. 2
1
Hardware Installation and Configuration
Troubleshooting 8
Wireless Tips 9
1. Before You Start
?
?
?VGAResolution: 800 x 600 or above
?Web Browser: Internet Explorer (6.0 or higher)
?Wireless router orAccess Point
?An available DHCP Server –routers usually have a built-in DHCPserver
Acomputer with a wired network adapter properly installed.
CD-ROM Drive
Package Contents
?
?CD-ROM (Utility and User’s Guide)
?Multi-Language Quick Installation Guide
?2 x 2dbi DetachableAntenna
?Cat. 5 Ethernet Cable (1.5m/5ft.)
?Mounting Kit
?PowerAdapter (12V DC, 2A)
TV-IP612WN
System Requirements
1
Supported Operating Systems CPU Memory
Windows 7 (32/64-bit)
Windows Vista (32/64-bit)
Windows XP (32/64-bit) / 2000 1.3GHz or above
1.3GHz or above
1.3GHz or above
1GB RAM or above
512MB RAM or above
256MB RAM or above
2. Hardware Installation and Configuration
1. Insert the Utility CD-ROM into your CD-ROM
drive.
2
Note:
1．It is recommended that you configure the IP Camera from a wired computer.
2．If you would like to use IPViewPro 2.0 software, please install the software by clicking
the Install IPView Pro 2.0 in theAutorun window and refer to the User's Guide on the
CD for more information
2. Click Run autorun.exe (Windows 7/Vista only).
3. Click Setup Wizard.
4. Click Next. Then follow the Setup Wizard
instructions.
3
6. Double click on the SetupWizard icon on your
desktop.
5. Click Close.
10. Click Next.
8. Connect a RJ-45 network cable from a
Switch/Router to the Ethernet port on the IP
Camera.
9. Connect the PowerAdapter to the IP Camera
and then to a power outlet.
7. Attach the antennas to the IP camera.
11. Select the IP camera and click Next.
4
14. If you would like to change the administrator
password, click Change Password, enter a
new password, retype the new password and
then click Next. Leave Change Password
unchecked if you do not wish to change the
password.
Note: Password is limited to up to 8 characters.
15. Select DHCP and then click Next.
12. Enter your ID and password. Then click Next.
By default:
ID: admin
Password: admin
13. Configure the Camera Name and Camera
Time. Click Copy Local Time to automatically
configure the Camera Time to match your
computer. Then click Next.
16. Click I want to use wireless for the camera
and then click Next .
5
17. Select your wireless network from the
Available AP dropdown list. If your wireless
network does not appear, manually enter the
SSID of your wireless network. If you have
Encryption enabled, select the Authentication,
select the Encryption and enter your Key.
Then click Next.
18. Click Next.
19. Please wait while the settings on your cameras
are being saved.
20. Select By using wireless and then click Next.
21. Disconnect the RJ-45 cable. Verify that the
LINK (RED) LED is lit and then click Next.
Note: TheTV-IP612WN will not work wirelessly until you disconnect the Ethernet cable
from the back of the camera.
6
22. Please wait while the settings on your
cameras are being saved.
23. Click on the following URLor click Link to
open up the browser configuration.
24. Enter the User name and Password, and then
click OK. By default:
User Name: admin
Password: admin
25. Click Live View to view live video.
26. Right click on the information bar and select
Install ThisAdd-on for All Users on This
Computer… (Internet Explorer 8)
27. Click Install. (Internet Explorer 8)
7
28. Right click on the information bar and select
RunAdd-on (Internet Explorer 6/7).
31. Use the command icons to control the IP
camera.
30. Live Video will now appear.
Your installation is complete
Register Your Product
To ensure the highest level of customer service and support, please take a moment to
register your product Online at: www.trendnet.com/register
Thank you for choosing TRENDnet
For detailed information regarding the TV-IP612WN configuration and advanced settings,
please refer to the Troubleshooting section, User's Guide on the Utility CD-ROM, or
TRENDnet's website at http://www.trendnet.com.
29. Click Run (Internet Explorer 6/7).
1.
1.
1.
I inserted the Utility CD-ROM into my computer's CD-ROM Drive but the installation menu
does not appear automatically. What should I do?
For Windows 7, if the installation menu does not appear automatically, click on the
Windows Icon on the bottom left hand corner of the screen,, click the “Search programs
and files” box, and type D:\autorun.exe, where “D” in “D:\autorun.exe” is the letter
assigned to your CD-ROM Drive, and then press the ENTER key on your keyboard .
2. For Windows Vista, if the installation menu does not appear automatically, click Start, click
the Start Search box, and type D:\autorun.exe where "D" in "D:\autorun.exe" is the letter
assigned to your CD-ROM Drive, and then press the ENTER key on your keyboard.
3. For Windows XP/2000, if the window does not appear automatically, click Start, click Run
and type D:\autorun.exe where “D” in “D:\autorun.exe” is the letter assigned to your
CD-ROM Drive, and then press the ENTER key on your keyboard.
2. Setup Wizard is unable to detect my camera. What should I do?
Verify that you have followed all the steps in Section 2: Hardware Installation.
2. Disable any software firewall programs such as ZoneAlarm or Norton Internet Security. If
you are using Windows 7, Vista or XPdisable the built in firewall.
3. Click on Rescan.
4. Take a pin or paper clip.Then press on the Reset button on the back on the IP Camera
for 10 seconds, then let go.
3. I do not have a DHCP server or DHCPis disabled on my network and I am unable to
configure the TV-IP612WN. What should I do?
1. Go to the TCP/IPsettings on your computer and assign a static IP address on your
computer's network adapter in the subnet of 192.168.10.x. Since the default IP address of
the TV-IP612WN is 192.168.10.30, do not assign a static IP address of 192.168.10.30 on
your computer's network adapter.
2. Open Internet Explorer and enter into the address bar.
4. The Image is blurry. How can I adjust the focus on the Internet camera?
If you have manual focus enabled in the IP camera's browser configuration, you can press
the plus or minus sign. Selecting auto focus will automatically adjust the focus on the IP
camera.
5. When I click on Live View the image does not load?
1. Make sure that you are using a browser that supportsActive X.
2. Make sure thatActiveX is installed. See steps 20 to 23 in Section 2: Hardware
Installation and Configuration.
6. How do I connect the TV-IP612WN to my wireless router or access point?
Make sure that you configure the camera to have the same SSID, encryption mode and key
(if enabled). Follow the instructions in section 2 to configure the camera with the SSID and
encryption key.
http://192.168.10.30
Troubleshooting
8
