TRENDnet TV-H400 Manuel utilisateur

TV-H400

H/W: V2

Quick Installation Guide

Table of Contents

Version 10.09.2008

English ...................................................................................................... 1

1. Before You Start

2. Hardware Installation .........................................................................

................................................................................

Troubleshooting ........................................................................................ 11

English

1. Before you start

Installation Requirements

Package Contents

The following items below are not included. Users must provide the items

themselves. Make sure to have each item on hand before installation.

?Power Adapter (12V DC, 0.6A)

?1 x Wall Mount Bracket

?Allen wrench (4mm)

?Screws and lock washers

?Rubber seal

TV-H400

Quick Installation Guide

?Mounting screws and screw anchors (for wall mounting)

?Dry wall or wood surface

?Phillips screwdriver

?RJ-45 Ethernet cable

Pan and tilt Internet camera

2. Hardware Installation

English

Note: Configure your Internet Camera Server to match your network before

installing the device.

Bracket:BR001

Bracket:BR002

Round Head x 5pcsScrew

Bracket:BR003

3.5cm Hex x 2pcsScrew

Flat Head Screw x 3pcs

Washer x 3pcs

Hex Nut Top x 3pcs

Rubber x 1pcsSeal

5cm Hex x 3pcsScrew

English

3. Run all necessary cables (Ethernet

cable, power adapter cable, and

the power terminals) through the

wall mount bracket.

2. Unscrew the thumbscrew. Save

this screw. You will need to use this

screw later.

1. Rotate the TV-H400's cover

counter clockwise and remove the

cover.

English

4. Connect the power terminal to the

provided 12V DC, 0.6A power

adapter.

5. Run each cable through the

opening located at the top of the

TV-H400.

6. After inserting the appropriate

cables, extend each cable to 6

inches for camera installation.

7. Use the provided rubber seal to

seal the housing.

English

8. Secure the protective plating into

the wall mount bracket using the

thumb screw.

10. Connect the three 5 cm Hex

screws to the circular base

bracket. Secure the Hex screws

with the nuts and washers. The

5cm Hex screws are in the plastic

bag labeled Q3. The nuts and

washers are in the plastic bag

labeled Q5.

9. Screw the wall mount bracket on

top of the TV-H400 with the

provided Allen wrench and three

hexagon socket screws. The

screws are in the plastic bag

labeled Q2.

English

12. Use three round head screws to

mount bracket BR002 on top of

the 3 Hex screws. The three

round head screws are in the

plastic bag labeled Q6.

11. Mount bracket BR003 to the

camera enclosure using the three

flat head screws. These screws

are in the plastic bag labeled Q1.

13. Connect the two 3.5 cm hex

screws to this bracket. These

screws are in the plastic bag

labeled Q4.

English

15. Use the two round head screws to

mount bracket BR001 to the two

hex screws. The two round head

screws are in the plastic bag

labeled Q6.

16. Connect the Ethernet cable and

power adapter to the Internet

Camera Server.

14. Attach bracket BR001 to the

camera with 3 small screws.

These screws should come with

the Internet Camera Server.

English

18. Plug the power to the Internet

Camera Server and the camera

enclosure into an available power

outlet.

17. Place the TV-H400's cover over

the camera and rotate the cover

clock-wise.
