TRENDnet TE100-S16R Manuel utilisateur

TE100-S16R

TE100-S24R

Quick Installation Guide

Table of Contents

Version 01.24.2007

Español .......................................................................................................

Technical Specifications .............................................................................

Troubleshooting ..........................................................................................

1. Antes de iniciar ...................................................................................

2. Instalación del Hardware ....................................................................

Español

1. Antes de iniciar

Un cable de red RJ-45

Un PC con adaptador de red instalado correctamente.

La toma de corriente debe estar a 1.82 metros (6 pies) del conmutador

Contenidos del paquete

Guía de instalación rápida

Kit para montaje en estante

TE100-S16R/TE100-S24R

Cable de alimentación

Compruebe que existe una correcta regulación de la temperatura y una

ventilación adecuada alrededor del conmutador

No coloque objetos pesados encima del conmutador

Aplicación

Requisitos del sistema

Estructura de nivel y bastidor de 19 pulgadas estándar EIA o robusto

que pueda soportar el peso del chasis

16/24 Ports 10/100Mbps Fast Ethernet Switch

(TE100-S16R or TE100-S24R)

10/100Mbps Multi-Port

Print Server

(TE100-P21)

Printers

Workstations with PCI Adapter

(TE100-PCIWN)

Laptop with PC Card

(TE100-PCBUSR)

Server with PCI Adapter

(TE100-PCIWA)

Cable/DSL

Modem Router

Internet

10/100Mbps

Español

2. Instalación del Hardware

2. Conecte un cable de red RJ-45

CAT-5 del PC a un puerto Ethernet

disponible en el TE100-S16R/

TE100-S24R

1. Conecte el Power Cord (Cable de

alimentación) en la parte trasera

del TE100-S16R/ TE100-S24R y

después a la toma corriente.

Español

1. Fije las abrazaderas de sujeción a

ambos lados del chasis y

asegúrelas con los tornillos

suministrados.

2. Coloque el chasis con cuidado

encima del bastidor. Procure que

la abrazadera coincida con los

orificios de los tornillos del

bastidor, luego use los tornillos

suministrados junto con el bastidor

del equipo para montar el chasis.

Para montaje en bastidor

El chasis puede montarse sobre un bastidor de 19 pulgadas tamaño estándar

EIA, que puede colocarse en un armario de empalmes junto con otros equipos.

Standards IEEE 802.3 10BASE-T Ethernet

IEEE 802.3u 100BASE-TX Fast Ethernet

Protocol CSMA/CD

Data Transfer Rates

Ethernet:

10Mbps (Half-Duplex), 20Mbps (Full-Duplex)

Fast Ethernet:

100Mbps (Half-Duplex), 200Mbps (Full-Duplex)

Network Cables Ethernet: UTP/STP CAT-3, 4, 5

Fast Ethernet: UTP/STP CAT-5, 5e , 6

Number of Ports

TE100-S16R: 16 x 10/100Mbps

Auto-negotiation, Auto-MDIX ports

TE100-S24R: 24 x 10/100Mbps

Auto-negotiation, Auto-MDIX ports

General

Topology

LEDs

Star

Power, Link/Activity, 100Mbps

Technical Specifications

Transmission Method Store-and-forward

MAC Address Table

RAM Buffer

SSRAM

8Kbytes Entries Per Device

2Mbits

1.25Mbits

MAC Address Learning Automatic update

Performance

Power 100-240VAC. 50/60Hz. Internal Power Supply

Power Consumption TE100-S16R: 5.9Watts (Max)

TE100-S24R: 7.5Watts (Max)

Temperature Operating: 0 ~ 50 C, Storage: -20 ~ 70 C° ° ° °

Dimensions (L x W x H) 280 x 180 x 45 mm

Weight TE100-S16R: 1.45kg

TE100-S24R: 1.54kg

Physical and Environmental

Humidity

Certification

Operating: 10% ~ 90%, Storage:5% ~ 90%

CE, FCC

Troubleshooting

Q1:

A1:

Q2:

A2:

Q3:

A3:

Q4:

A4:

After connecting the Switch to a power outlet, the LEDs do not turn

on.

Check the connection of the external power adapter to the

TE100-S16R/TE100-S24R and the power outlet. Also check that the power

outlet is receiving power.

When I connect a computer to the Switch's port, the LNK/ACT LED

turns on, but the 100Mbps LED remains off.

When the 100Mbps LED remains off, the computer's connection speed

is 10Mbps.

After I connect my PCs to the Switch, I am unable to share files.

First, check the LEDs on the Switch. Make sure the LINK/ACT LED is

on. Second, check the network cable. The minimum length of the cable is

1.5 meters and the maximum length of the cable is 100 meters. Third,

disable any software firewall program. Fourth, verify that you have file

sharing enabled. Please contact your Operating System support for more

information.

After I connect my PCs to the Switch, I can only get onto the Internet

from one computer.

The Switch was not designed to share Internet between multiple

computers. You need to get an Internet router such as the

TW100-S4W1CA.

If you still encounter problems or have any questions regarding the

TE100-S16R/TE100-S24R please contact TRENDnet's Technical Support

Department.

Limited Warranty

- 5-Year Warranty

TRENDnet warrants its products against defects in material and workmanship, under

normal use and service, for the following lengths of time from the date of purchase.

TE100-S16R/TE100-S24R

If a product does not operate as warranted above during the applicable warranty period,

TRENDnet shall, at its option and expense, repair the defective product or deliver to

customer an equivalent product to replace the defective item. All products that are

replaced will become the property of TRENDnet. Replacement products may be new or

reconditioned.

TRENDnet shall not be responsible for any software, firmware, information, or memory

data of customer contained in, stored on, or integrated with any products returned to

TRENDnet pursuant to any warranty.

There are no user serviceable parts inside the product. Do not remove or attempt to

service the product through any unauthorized service center. This warranty is voided if

(i) the product has been modified or repaired by any unauthorized service center, (ii) the

product was subject to accident, abuse, or improper use (iii) the product was subject to

conditions more severe than those specified in the manual.

Warranty service may be obtained by contacting TRENDnet office within the applicable

warranty period for a Return Material Authorization (RMA) number, accompanied by a

copy of the dated proof of the purchase. Products returned to TRENDnet must be pre-

authorized by TRENDnet with RMA number marked on the outside of the package, and

sent prepaid, insured and packaged appropriately for safe shipment.

WARRANTIES EXCLUSIVE: IF THE TRENDNET PRODUCT DOES NOT OPERATE

AS WARRANTED ABOVE, THE CUSTOMER’S SOLE REMEDY SHALL BE, AT

TRENDNET’S OPTION, REPAIR OR REPLACEMENT. THE FOREGOING

WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER

WARRANTIES, EXPRESSED OR IMPLIED, EITHER IN FACT OR BY OPERATION OF

LAW, STATUTORY OR OTHERWISE, INCLUDING WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. TRENDNET

NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT

ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION,

MAINTENANCE OR USE OF TRENDNET’S PRODUCTS.

TRENDNET SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND

EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES

NOT EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S

MISUSE, NEGLECT, IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED

ATTEMPTS TO REPAIR OR MODIFY, OR ANY OTHER CAUSE BEYOND THE

RANGE OF THE INTENDED USE, OR BY ACCIDENT, FIRE, LIGHTNING, OR OTHER

HAZARD.

LIMITATION OF LIABILITY: TO THE FULL EXTENT ALLOWED BY LAW TRENDNET

ALSO EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY LIABILITY, WHETHER

BASED IN CONTRACT OR TORT (INCLUDING NEGLIGENCE), FOR INCIDENTAL,

CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND,

OR FOR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF

INFORMATION OR DATE, OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN

CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE, USE,

PERFORMANCE, FAILURE, OR INTERRUPTION OF THE POSSIBILITY OF SUCH

DAMAGES, AND LIMITS ITS LIABILITY TO REPAIR, REPLACEMENT, OR REFUND

OF THE PURCHASE PRICE PAID, AT TRENDNET’S OPTION. THIS DISCLAIMER OF

LIABILITY FOR DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED

HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE.

Governing Law: This Limited Warranty shall be governed by the laws of the state of

California.

Note: AC/DC Power Adapter, Cooling Fan, Cables and Power Supply carry a 1-Year

Warranty
