TRENDnet TPL-302E Manuel utilisateur

TPL-302E

Quick Installation Guide

Table of Contents

Version 02.18.2009

English .....................................................................................................

Troubleshooting ........................................................................................

1. Before You Start

2. ....................................................................................

................................................................................

How to Install

System Requirements

Application

?TPL-302E

?Utility CD-ROM

?Quick Installation Guide

Package Contents

1. Before You Start

English

?A Desktop or Laptop PC with Network Adapter Installed

?CPU: 300MHz or above / 800MHz or above (Windows Vista)

?Existing Powerline AV network

?Existing 10/100Mbps wired network when TPL-302E is used as a bridge

device

Memory: 256MB RAM or above / 512MB RAM or above (Windows Vista)

D-ROM drive

Outlet

200Mbps Powerline AV

Fast Ethernet Adapter

(TPL-302E)

Workstation with

Fast Ethernet PCI Adapter

(TE100-PCIWN)

4-Port Cable/DSL

Broadband Router

(TW100-S4W1CA)

Internet

Cable/DSL

Modem Outlet

10/100Mbps Powerline

2. How to Install

English

Important! DO NOT install the TPL-302E until instructed to do so

Note:

1. DO NOT plug the TPL-302E into a power strip or surge protector.

2. In order for the TPL-302E to see each other, each unit must be on the same

circuit breaker.

3. A maximum of 16 TPL-302E can be networked.

1. Insert the Utility CD-ROM into

your computer's CD-ROM Drive

and then click Install Utility.

3. On the back of the unit, copy down

the 12 digit device password.

For Windows Users

2. Follow the InstallShield Wizard

instructions and then click Finish.

Outlet

English

6. Plug a second TPL-302E into an

outlet where your remote PC,

wireless access point or other

device with a built in Ethernet port

is located.

5. Connect a CAT-5 cable from the

TPL-302E to your router (e.g.

TEW-633GR). Then connect a

CAT-5 cable from your router to

your computer.

4. Plug the TPL-302E into an

available power outlet.

Note: The default network name is TRENDnet. If the network ID of your

existing Powerline network is NOT TRENDnet, you must change this in the

utility.

7. Double-click the TRENDnet

Powerline AV Utility on your

desktop.

English

10. Repeat step 8-9 for the second

TPL-302E.

8. Select Local or Remote device,

then click Security.

Note: Configure the Remote

device first.

9. If you would like to change the

Network ID, enter the desired ID.

If you are configuring a remote

device, you must enter the device

password (see step 3). Then click

Save Changes.

11. Connect a CAT-5 cable from the

TPL-302E into your remote PC,

Wireless Access Point (e.g. TEW-

630APB) or other device with

built-in Ethernet port.

Your installation is now complete.

For detailed information regarding the TPL-302E configuration and advanced

settings, please refer to the User's Guide included on the Utility CD-ROM or

TRENDnet's website at www.trendnet.com

Outlet

Q1:

A1:

Q2:

A2:

Q3:

A3:

I inserted the TPL-302E CD-ROM into my computer's CD-ROM Drive and the

installation menu does not appear automatically. What should I do?

If the installation menu does not appear automatically, click Start, click Run,

and type D:\Autorun.exe where "D" in "D:\Autorun.exe" is the letter assigned to

your computer's CD-ROM Drive. And then click OK to start the installation.

I have verified that my Powerline device is connected to my workstation, but I

cannot detect other Powerline devices. What should I do?

First, verify that you are using Cat-5e Ethernet cables. Second, open up the

Powerline AV Utility and click scan. Third, verify the network name of your

Powerline network. Then click on the security link in the TRENDnet Powerline

Utility, type in the network name and click Save changes. Fourth, verify that the

power outlet the TPL-302E is plugged into is on the same electrical power

distribution and/or circuit breaker.

I can detect my Powerline devices on my Powerline network, but I cannot

connect to the Internet. What should I do?

First, make sure you are not connecting the device into a power strip or surge

protector. Second, make sure that your Router is connected to the internet. Third,

verify that the TCP/IP settings are set to Obtain an IP address automatically.

Troubleshooting

1. Go into the Control Panel and double-click the

Network Connections icon, and then right-click the

Local Area Connection icon and then click

Properties.

2. Click Internet Protocol (TCP/IP) and then click

Properties. Click on Obtain an IP automatically and

then click OK.

Q4:

A4:

Q5:

A5:

When I try to configure a remote device, an error message appears. What

should I do?

First, make sure you copy down the 12 digit device password. Second, enter

the 12 digit device password in the utility. You need to enter dashes. For

example: XXXX-XXXX-XXXX-XXXX.

I have a HomePlug 1.0 or HomePlug turbo network. Can I use this with my

network?

The TPL-302E is not backwards compatible with HomePlug 1.0 or HomePlug

turbo.

If you still encounter problems or have any questions regarding the TPL-302E, please

refer to the User's Guide included on the Utility CD-ROM or contact TRENDnet's

Technical Support Department.

Limited Warranty

- 3-Year Limited Warranty

TRENDnet warrants its products against defects in material and workmanship, under

normal use and service, for the following lengths of time from the date of purchase.

TPL-302E

If a product does not operate as warranted above during the applicable warranty period,

TRENDnet shall, at its option and expense, repair the defective product or deliver to

customer an equivalent product to replace the defective item. All products that are

replaced will become the property of TRENDnet. Replacement products may be new or

reconditioned.

TRENDnet shall not be responsible for any software, firmware, information, or memory

data of customer contained in, stored on, or integrated with any products returned to

TRENDnet pursuant to any warranty.

There are no user serviceable parts inside the product. Do not remove or attempt to

service the product through any unauthorized service center. This warranty is voided if

(i) the product has been modified or repaired by any unauthorized service center, (ii) the

product was subject to accident, abuse, or improper use (iii) the product was subject to

conditions more severe than those specified in the manual.

Warranty service may be obtained by contacting TRENDnet office within the applicable

warranty period for a Return Material Authorization (RMA) number, accompanied by a

copy of the dated proof of the purchase. Products returned to TRENDnet must be pre-

authorized by TRENDnet with RMA number marked on the outside of the package, and

sent prepaid, insured and packaged appropriately for safe shipment.

WARRANTIES EXCLUSIVE: IF THE TRENDNET PRODUCT DOES NOT OPERATE

AS WARRANTED ABOVE, THE CUSTOMER’S SOLE REMEDY SHALL BE, AT

TRENDNET’S OPTION, REPAIR OR REPLACEMENT. THE FOREGOING

WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER

WARRANTIES, EXPRESSED OR IMPLIED, EITHER IN FACT OR BY OPERATION OF

LAW, STATUTORY OR OTHERWISE, INCLUDING WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. TRENDNET

NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT

ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION,

MAINTENANCE OR USE OF TRENDNET’S PRODUCTS.

TRENDNET SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND

EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES

NOT EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S

MISUSE, NEGLECT, IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED

ATTEMPTS TO REPAIR OR MODIFY, OR ANY OTHER CAUSE BEYOND THE

RANGE OF THE INTENDED USE, OR BY ACCIDENT, FIRE, LIGHTNING, OR OTHER

HAZARD.

LIMITATION OF LIABILITY: TO THE FULL EXTENT ALLOWED BY LAW TRENDNET

ALSO EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY LIABILITY, WHETHER

BASED IN CONTRACT OR TORT (INCLUDING NEGLIGENCE), FOR INCIDENTAL,

CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND,

OR FOR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF

INFORMATION OR DATE, OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN

CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE, USE,

PERFORMANCE, FAILURE, OR INTERRUPTION OF THE POSSIBILITY OF SUCH

DAMAGES, AND LIMITS ITS LIABILITY TO REPAIR, REPLACEMENT, OR REFUND

OF THE PURCHASE PRICE PAID, AT TRENDNET’S OPTION. THIS DISCLAIMER OF

LIABILITY FOR DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED

HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE.

Governing Law: This Limited Warranty shall be governed by the laws of the state of

California.

Note: AC/DC Power Adapter, Cooling Fan, Power Supply, and Cables carry a 1-Year

Warranty
