TBW-106UB

H/W: V1

Quick Installation Guide

Table of Contents

Version 02.10.2009

English ......................................................................................................

Troubleshooting .........................................................................................

1. Before You Start

2. How to Install .....................................................................................

3. Configuring the Bluetooth Adapter ....................................................

................................................................................

System Requirements

1. Before You Start

English

Package Contents

Application

?Utility& Driver CD-ROM

TBW-106UB

Multi-Language Quick Installation

Guide

?USB Port: 2.0 or 1.1

CD-ROM drive

CPU: 600MHz or Above / 800MHz or Above (Windows Vista)

Memory: 256MB or Above / 512MB RAM or Above (Windows Vista)

?Hard Drive Space: 50MB or Above

?Windows 2000/XP/Vista

* Backwards compatible with USB 1.1 at 12Mbps

Keyboard

Bluetooth

Headset

Printer

(TBW-106UB)

Micro Bluetooth USB Adapter

Cell Phone

Note:

1. Do not insert the TBW-106UB USB adapter until instructed to do so.

2.If you have any Bluetooth driver (software) previously installed on your

computer or built-in Bluetooth device, please remove the driver and disable

the built-in Bluetooth device first.

2. How to Install

English

1. Insert the Utility & Driver

CD-ROM into your CD-ROM drive.

3. Click Install Utility.

4. Select the Language from the drop

down menu. Click OK.

2. Click Run Setup.exe (Windows

Vista).

English

6. Select I accept the terms in the

license agreement. Click Next

7. Follow the InstallShield Wizard

instructions and then click Finish.

5. Click Next.

English

10. Drivers will install automatically.

11. If this window appears, click OK.

12. Click Yes (Windows 2000 and XP

only).

9. Connect the TBW-106UB into the

computer's USB port.

8. Click Yes to restart the computer

(Windows 2000 and XP only).

Windows 2000

Windows XP

English

3. Configuring the Bluetooth Adapter

1. Double-click the BlueSoleil icon

on your desktop.

Note: Make sure your Bluetooth device is powered on and in pairing mode.

4. Right click on your Bluetooth

device and select Pair Device.

2. If this window appears, click OK.

3. Go to View -> Refresh Devices.

English

5. Type in a Passkey (for example:

0000. Please consult your

Bluetooth device's manual for more

information) and then click OK.

Then put in the same Passkey on

your Bluetooth device.

Your configuration is now complete.

For detailed information regarding the configuration and

advanced settings, please refer to the User's Guide included on the Utility &

Driver CD-ROM or TRENDnet's website at www.trendnet.com

TBW-106UB

6. Double left-click on your Bluetooth

device to show the available

services. The available services

will appear in yellow.

To ensure the highest level of customer service and support, please take a moment to

Thank you for choosing TRENDnet

Q1:

A1:

Q2:

A2:

Q3:

A3:

Q4:

A4:

Windows is unable to recognize my hardware. What should I do?

First, make sure your computer meets the minimum requirements as specified

in Section 1 of this quick installation guide. Second, you must install the Bluetooth

utility BEFORE you physically install your Bluetooth Adapter. Third, plug the

adapter into a different USB slot.

The Bluetooth software is unable to detect my Bluetooth-enabled device.

What should I do?

First, disable any software firewall programs such as ZoneAlarm or Norton

Internet Security. If you have Windows XP or Vista installed on your computer,

make sure to disable the built-in firewall. Second, make sure your Bluetooth

device is powered on. Third, make sure your Bluetooth device is within 50 meters

of the TBW-106UB. Fourth, manually add in the Bluetooth device. Find out the

Mac address of your Bluetooth device. Then go to Tools -> Add New Device.

Enter the Mac Address of the Bluetooth device and then click OK.

I cannot pair my Bluetooth device to the TBW-106UB USB Adapter. What

should I do?

First, make sure that the Bluetooth device is powered on. Second, make sure

that your Bluetooth device is in pairing mode. Third, make sure to put in the same

Passkey on both devices.

I am not receiving 3Mbps data rate through the adapter. What should I do?

In order to get the full data rate, your Bluetooth device must support Bluetooth

v2.0 with Enhanced Data Rate (EDR)

If you still encounter problems or have any questions regarding the TBW-106UB, please

refer to the User's Guide included on the Utility & Driver CD-ROM or contact

TRENDnet's Technical Support Department.

Troubleshooting

Certifications

This equipment has been tested and found to comply with FCC and CE Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received. Including interference that may

cause undesired operation.

NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV

INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS

EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO

OPERATE THE EQUIPMENT.

Waste electrical and electronic products must not

be disposed of with household waste. Please

recycle where facilities exist. Check with you Local

Authority or Retailer for recycling advice.

ADVERTENCIA

En todos nuestros equipos se mencionan claramente las caracteristicas del adaptador de

alimentacón necesario para su funcionamiento. El uso de un adaptador distinto al

mencionado puede producir daños fisicos y/o daños al equipo conectado. El adaptador

de alimentación debe operar con voltaje y frecuencia de la energia electrica domiciliaria

existente en el pais o zona de instalación.
