TreadReader HANDHELD Manuel utilisateur

TREADREADERTM

HANDHELD 3D SCANNER

PRODUCT MANUAL

Redening tire measurement

CONTENT

QUICK START 06

01 TreadReader HandHeld scanner 08

02 Buttons and LED’s on the HandHeld scanner 09

2.1 Buttons 09

2.1.1 Power button 09

2.1.2 Battery button 09

2.1.3 Wi-Fi button 10

2.2 LED’s 10

03 TreadReaderTM Android® app 11

3.1 Connectivity 11

3.1.1 Direct mode 12

3.1.2 Network mode 14

3.1.2.1 Switch from network mode to direct mode

(factory reset)

3.2 TreadManager.net 17

3.2.1 Setup and user types 18

3.2.2. Login/upload to TreadManagerTM in the Android® app

(11.53.1.0 and newer)

3.3 Navigation 21

3.4 Vehicle scan 22

3.4.1 Identify registration number 22

3.4.2 Scanning/results screen 23

3.4.3 Visualize the scans all together and create report 25

Redening tire measurement

3.5 Quick scan 27

3.6 Settings 27

3.6.1 Connections 28

3.6.2 Reports 28

3.6.3 Tread depth 29

3.6.4 General/regional 29

3.6.5 Calibration check 30

3.6.6 System info and rmware update 31

3.6.7 Network 32

3.6.8 Scan settings 32

3.7 Where to nd the les stores on the mobile device? 33

3.8 Troubleshooting: TreadManager.net on smartphones and

tablets

04 Integrations to other software 34

05 Hardware specication 34

5.1 Dimensions 34

5.2 Control pad buttons and LEDs 35

5.3 Label and label position 35

5.4 Charging 36

5.5 Maintenance and cleaning 36

5.6 Main specications summary 37

06 LED’s Errors 38

6.1 Basic errors: 39

6.1.1 LED 2 and LED 7: Battery temperature too low.

Blink count = 5

Redening tire measurement

6.1.2 LED 2 and LED 3 : Battery temperature too high.

Blink count = 5

6.1.3 LED 5 : Fuel gauge fault. Blink count = 5 40

6.1.4 LED 7 : Charge level (coulomb count) is too low

(< 1% charge left). Blink count = 5

6.1.5 LED 7 : Battery voltage is too low (Below 3.4V).

Blink count = 8

6.2 Charging errors 40

6.2.1 LED 1 and LED 3 : Timeout error while charging

completion

6.2.2 LED 1 and LED 5 : Timeout error while fast charging 42

6.2.3 LED 1 and LED 7 : Timeout error while slow charging 43

6.3 Other faults: 43

6.3.1 LED 3 : Blink count = 25 - Current limit exceeded 43

6.3.2 LED 3 : Blink count = 10 - Voltage limit exceeded 44

6.3.3 LED 1,2,3,5,7 : Blink count = 7 - Error undetermined 44

07 Legal warnings 45

7.1 Warnings 45

7.2 CE marking and declaration of conformity 45

7.3 Disclaimer 45

7.4 Safe use of a laser product 46

QUICK START

A • WHAT’S INSIDE THE BOX

B • CHECK THE BATTERY LEVEL

HandHeld

Scanner

Plug Adaptors

USB Cable Calibration

Certicate

Quick Guide

The LEDs indicate the battery level. Make sure that the scanner is fully charged before

starting.

NOTE: Extra items might be included according to your region.

Learn more about battery status

and charging in sections 5.2 and

5.4 (pages 35 and 36).

67 - 100%

34 - 66%

0 - 33%

C • PAIRING THE SCANNER TO THE APP

D • REGISTER

Informing the following:

NOTE: It can take up to 24 hours for your user to be ready, you’ll receive an e-mail conrmation.

• Workshop name

• User name

• User e-mail

• Country and

• Sales agent or distributor

Learn more about the app

connectivity in section 3.1

(beginning on page 11).

Learn more about setup and user

types in section 3.2.1 (beginning

on page 18).

The Android® app for phones or tablets can be downloaded from Google Play®.

The app controls the HandHeld scanner and connects to TREADMANAGERTM, the

cloud-based service platform.

Before logging in to TREADMANAGERTM (in the Android app or through the website

(www.treadmanager.net), request your registration by sending an e-mail to:

treadmanager@treadreader.com

TREADREADERTM HANDHELD • PRODUCT MANUAL

The TreadReaderTM HandHeld scanner is a compact and lightweight device. It is

quick and easy to use and eliminates errors associated with manual depth gauges.

TreadReaderTM is suitable for wet or dirty tyres and is ideal for all tyre inspection

applications in workshops, service centres, inspection lanes, commercial vehicle

yards and at the roadside. Accurate tread depth readings for tyres of all vehicle

types, such as passenger cars, LCVs, HGV, buses, and trailers, can reveal uneven

wear symptomatic of problems such as wheel misalignment or worn suspension. The

calculated data can be imported into different eet management systems to log tyre

scans and produce wear analysis or tyre lifetime modelling.

The scanner is positioned on one edge of the tyre and operated by pushing it across

the tread face. A 3D scan of each tyre constructed from up to 300,000 measurement

points is used to calculate treads depths with an accuracy of <0.2mm or 0.008”. The

3D models of the tyre tread obtained using the TreadReaderTM HandHeld scanner

can be viewed, alongside the calculated tread depths, on a tablet or mobile phone.

A report for the operator is instantly generated containing vehicle identication, 3D

tyre scans with colour-coded tread warning, and error alarms for every axle and tyre

position.

Fig.1 TreadReaderTM HandHeld Scanner

01 • TREADREADERTM HANDHELD SCANNER

There are three buttons on the HandHeld scanner. The LEDs indicate power (on/off),

wi- connectivity, battery level and scanner status.

Below is the general description of the use and interaction of the buttons on the

HandHeld scanner. Throughout the manual there are other uses for the buttons and

combinations of button presses. For more detailed information please see chapter 5.

Holding down the power button for 2 seconds will turn the scanner on/off. The top

LED will be lit when the HandHeld scanner is on, and a vibration will indicate the on/

off event.

Fig.2 Layout of the buttons and LEDs

02 • BUTTONS AND LED’S ON THE HANDHELD

SCANNER

2.1 • BUTTONS

2.1.1 • POWER BUTTON

Power (On/Off)

Battery level/

scanner status

Network mode/

transmiting data 67 - 100%

Ready to scan

Device connected

to the application 34 - 66%

Processing data

Wi-Fi enable and

ready for connection 0 - 33%

Fault

Holding down the battery button for 1 second will indicate the battery level of the

HandHeld scanner, as shown by the LEDs in Fig. 2.

2.1.2 • BATTERY BUTTON

TREADREADERTM HANDHELD • PRODUCT MANUAL

This button does not have a function in normal operation. If pressed it will disable the

power and battery buttons for 3 seconds.

Throughout the manual the following interactions will be explained in greater detail.

For more detailed information please see chapter 5.

1. Top (green): indicates that the HandHeld scanner is on.

2. Top-left (blue):

a. Before pairing with a mobile device this LED indicates that the scanner is

connected to a wi- network (must be connected to in network mode).

b. Once paired with a mobile device, it indicates that the scanner is transmitting

data to the application.

3. Middle-left (blue): Indicates that a connection is made to the HandHeld scanner

from the application.

4. Bottom-left (blue): Indicates that wi- is enabled. After powering the scanner

on (and this LED turning on), it needs around 5-6 seconds to be fully ready for a

connection from the mobile application.

5. Top-right (green): Indicates that the scanner is ready to scan, it is also used to

show the battery level (if the battery button is pushed down for 1 second or more).

6. Middle-right (orange): Indicates that the scanner is processing the captured data.

It is also used to show the battery level (if the battery button is pushed down for 1

second or more).

7. Bottom-right (red): Indicates various error messages (see chapter 5). It is also used

to show the battery level (if the battery button is pushed down for 1 second or more).

2.1.3 • WI-FI BUTTON

2.2 • LED’S
