Transition Networks E-MCC-1600 Manuel utilisateur

Manageable

Media Conversion

Center 33035.G

E-MCC-1600

For assistance in installing, using, or

maintaining the TRANSITION Networks

Media Conversion Center, contact

TRANSITION Networks Technical

Support at:

(800) 260-1312

or contact your local distributor.

CAUTION: RJ connectors are NOT INTENDED FOR CONNECTION TO THE PUBLIC

TELEPHONE NETWORK. Failure to observe this caution could result in damage to the public

telephone network.

Compliance Information

UL Listed

C-UL Listed (Canada)

CISPR/EN55022 Class A

FCC Regulations

This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to

part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment. This equipment generates, uses,

and can radiate radio frequency energy and, if not installed and used in accordance with the instruction

manual, may cause harmful interference to radio communications. Operation of this equipment in a

residential area is likely to cause harmful interference, in which case the user will be required to correct the

interference at the user’s own expense.

Canadian Regulations

This digital apparatus does not exceed the Class A limits for radio noise for digital apparatus set out on the

radio interference regulations of the Canadian Department of Communications.

European Regulations

Warning

This is a Class A product. In a domestic environment this product may cause radio interference in

which case the user may be required to take adequate measures.

graphic, electronic, or mechanical – without written permission from Transition Networks.

Trademark Notice

All registered trademarks and trademarks are the property of their respective owners.

Der Anschluss dieses Gerätes an ein öffentlickes Telekommunikationsnetz in den EG-Mitgliedstaaten verstösst

gegen die jeweligen einzelstaatlichen Gesetze zur Anwendung der Richtlinie 91/263/EWG zur Angleichung

der Rechtsvorschriften der Mitgliedstaaten über Telekommunikationsendeinrichtungen einschliesslich der

gegenseitigen Anerkennung ihrer Konformität.

Table of Contents

Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v

1. INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.1

1.1 The Media Conversion Center . . . . . . . . . . . . . . . . . . 1.2

1.2 Connectors, Indicators, and Switches . . . . . . . . . . . . . . 1.4

1.3 The Media Conversion Center in the Network . . . . . . . 1.5

1.4 Optional Network Management . . . . . . . . . . . . . . . . . 1.5

1.4.1 SNMP Management Agent . . . . . . . . . . . .1.5

1.4.2 Command Line Interface (CLI) . . . . . . . . .1.5

1.4 Optional Network Management (continued) . . . . . . . . 1.6

2 SITE PLANNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.1

3 INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3.1

3.1 Unpacking E-MCC-1600 Equipment . . . . . . . . . . . . . . 3.2

3.2 Installing Optional AC Power Supply Module in Media

Conversion Center Chassis . . . . . . . . . . . . . . . . . . . . . . 3.3

3.3 Installing Optional 48 VDC Power Supply Module in

Media Conversion Center Chassis . . . . . . . . . . . . . . . . 3.6

3.4 Installing Optional Management Module in Media

Conversion Center Chassis . . . . . . . . . . . . . . . . . . . . . . 3.9

3.5 Installing Media Converter Slide-in-Module(s) in Media

Conversion Center Chassis . . . . . . . . . . . . . . . . . . . . . 3.10

3.6 Installing Media Conversion Center at Site . . . . . . . . . 3.11

3.6.1 Standard 19-Inch Rack Installation . . . . .3.11

3.6.2 Table-Top Installation . . . . . . . . . . . . . .3.11

16-SLOT MEDIA CONVERSION CENTER i

3.7 Connecting Media Converter Slide-In-Modules to Network .

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.12

3.8 Optionally Connecting Management Module to Terminal or

Terminal Emulator . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.12

3.9 Powering the Media Conversion Center . . . . . . . . . . 3.13

3.10 Optionally Using Attached Terminal Interface to Set IP

Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.14

3.11 Optionally Configuring Telnet and Telnet Security . . . 3.15

3.11 Optionally Configuring Telnet and Telnet Security

(continued) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.16

3.12 Optionally Configuring SNMP Traps . . . . . . . . . . . . . 3.16

4. OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4.1

4.1 Using Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.2

4.1.1 Media Conversion Center LED Indicators .4.2

4.1.2 Media Converter Slide-In-Module LED

Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4.2

4.2 Using Management Module Command-line Interface (CLI) .

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.3

4.2.1 At an Attached Terminal . . . . . . . . . . . . .4.3

4.2.2 At a Telnet Connection . . . . . . . . . . . . . .4.4

4.2.3 Command-line Interface Commands . . . .4.5

4.2.4 Command-line Interface Messages . . . .4.10

4.2.5 Command-line Interface Trace Masks . .4.34

4.2.6Traps . . . . . . . . . . . . . . . . . . . . . . . . . . . .4.35

4.3 Using Remote SNMP . . . . . . . . . . . . . . . . . . . . . . . . 4.36

5 MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5.1

5.1 Fault Isolation and Recovery . . . . . . . . . . . . . . . . . . . . 5.2

5.1.1 At the Remote Network Managment Station 5.2

5.1.2 At the Chassis Front or Back . . . . . . . . . .5.4

E-MCC-1600

5.2 Hardware Replacement Procedures . . . . . . . . . . . . . . . 5.6

5.2.1 Replacing Media Converter Slide-In-

Module5.6

5.2.2 Replacing Fuse on Standard Power Supply

Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5.7

5.2.3 Replacing Standard Power Supply Module 5.8

5.2.4 Replacing 48V Power Supply Module . .5.10

5.2.5 Replacing Management Module . . . . . .5.12

5.3 Firmware Upgrades . . . . . . . . . . . . . . . . . . . . . . . . . . 5.13

Appendix A. E-MCC-1600 Technical Specifications . . . . . . . A.1

Certificate of Compliance . . . . . . . . . . . . . . . . . .A1

Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . .A.1

Shipping Weight . . . . . . . . . . . . . . . . . . . . . . . .A.1

Appendix B. Null Modem Cable Specifications . . . . . . . . . . . B.1

Appendix C. Introduction to SNMP in the E-MCC-1600 . . . . C.1

Appendix D. Displaying the E-MCC-1600 MIB Tree . . . . . . . D.1

Displaying MIB Variables . . . . . . . . . . . . . . . . .D.1

Displaying the Entire MIB Tree . . . . . . . . . . . . .D.1

Appendix E. SNMP GLOSSARY . . . . . . . . . . . . . . . . . . . . . . E.1

16-SLOT MEDIA CONVERSION CENTER iii

Preface

This user’s guide is intended for the network administrator responsible for

installing, configuring, using, and maintaining a Transition Networks

16-Slot Media Conversion Center. A working knowledge of local area

network (LAN) operations, including familiarity with communications

protocols used on interconnected LANs, is assumed.

16-SLOT MEDIA CONVERSION CENTER v

1. INTRODUCTION

The modular Transition Networks E-MCC-1600 16-Slot Media Conversion

Center allows the network administrator to select from among Transition

Networks Media Converter Slide-in-Modules, to install the Media

Converter Slide-in-Modules in the Media Conversion Center chassis, and

then to connect various network media, at a central wiring location,

through the Media Converter Slide-in-Modules.

If a Management Module is installed in the Media Conversion Center, the

network administrator also can use a remote Network Management

Station to monitor the status of the Media Conversion Center and of any

installed Media Converter Slide-in-Modules.

As network conditions change, the network administrator can add or swap

Media Converter Slide-in-Modules, install a redundant Power Supply

Module (if not originally configured and installed) and/or install the SNMP

Management Module (if not originally configured and installed).

This introduction to the 16-Slot Media Conversion Center provides:

1.1 The Media Conversion Center ..............................................1.2

Media Converter Slide-in-Modules ..............................1.3

Power Supply Module(s) .............................................1.3

Optional Management Module ....................................1.3

1.2 Connectors, Indicators, and Switches ....................................1.4

1.3 The Media Conversion Center in the Network ......................1.5

1.4 Optional Network Management ............................................1.6

SNMP Management Agent ...........................................1.6

Command Line Interface (CLI) ......................................1.6

CLI Access via Serial Port .............................................1.7

CLI Access via Telnet ...................................................1.7

1.1

16-SLOT MEDIA CONVERSION CENTER

1.1 The Media Conversion Center

The Transition Networks 16-Slot Media Conversion Center chassis

provides installation space for up to sixteen Media Converter Slide-in-

Modules, up to two Power Supply Modules, and one SNMP Management

Module, as shown in the cut-out top view below:

NOTE: Media Converter Slide-in-Modules, Power Supply Modules, and

Management Modules are all hot-swapable.

1.2 E-MCC-1600

Power

Supply

Module

Fan

AC Power

POWER SUPPLY MODULE

MANAGEMENT

MODULE

MEDIA CONVERTER SLIDE-IN-MODULES
