Transcend USB JetFlash Manuel utilisateur

USB

16~128MB JetFlash™

User’s Manual

Table of Contents

Introduction

Package Contents ................................................................................ 1

Features................................................................................................... 1

System Requirements ......................................................................... 2

Driver Installation

Driver Installation for Windows 98SE ............................................ 2

Driver Installation for Windows Me/2000/XP................................ 2

Driver Installation for Mac OS 9.0 or Later .................................. 2

Driver Installation for Linux Kernel 2.4 or Later ........................ 3

Write-Protect Function .............................................................. 3

How to Safely Unplug JetFlash

To Remove JetFlash in Windows Me/2000/XP............................. 3

To Remove JetFlash in Mac OS ....................................................... 5

To Remove JetFlash in Linux ........................................................... 5

UMSDTools

UMSDTools Installation ...................................................................... 5

To Uninstall UMSDTools..................................................................... 7

Security Function

Partition Types..................................................................................... 8

Resize ................................................................................................... 9

Access Data in Security Area ........................................................... 12

Log Out of Security Area .................................................................. 14

Change Password.............................................................................. 14

Boot-Up Function

System Requirements for Boot-Up Function .................................. 16

Initialize Boot-Up Function in Windows 98SE/Me........................... 16

Initialize Boot-Up Function in Windows XP..................................... 18

Boot-Up Function Error Messages................................................... 21

Recover Disk ........................................................................................ 21

Specifications.................................................................................. 23

Ordering Information................................................................. 23

Warranty

Introduction

Thank you very much for purchasing Transcend’s JetFlash™. This small device

is designed to expedite exchanging huge amounts of data between any desktop

or notebook computer. With higher storage capacity and a much faster data

transfer rate than typical portable storage media, it can easily replace floppy

disks and hard disks. In addition, its mobility, strong data retention ability and

impressive appearance will provide you a brand new user experience.

Package Contents

The JetFlash package should include the following items:

 JetFlash

 Label

 Driver CD

 USB Extension Cable

 Quick Installation Guide

Features

• USB Interface: USB 1.1 compliant & USB 2.0 compatible, True Plug

and Play connection for hot swap function

• Expedited Data Transfer: Maximum transfer speed of 12M bit (1.5 MB)

per second

• Power Supply: Powered directly via the USB port. No external power

or battery needed.

• Write Protection: Write-protect switch provided

• Security Function: Password protection provided

• Boot-Up Function: Makes JetFlash a bootable disk

• Recover Disk: Return JetFlash to its initial status

• LED indication: Steady LED indicates Power On/Ready. Flashing

LED indicates Data Traffic.

System Requirements

Desktop or notebook computer with USB port

One of following operating systems:

• Windows® 98SE

• Windows® Me

• Windows® 2000

• Windows® XP

• Mac™ OS 9.0 or later

• Linux™ kernel 2.4 or later

Driver Installation

Driver Installation for Windows 98SE

1. Insert Driver CD into CD-ROM. Find 98Driver.exe in CD-ROM:\Driver.

2. Double-click on 98Driver.exe to run this program.

3. Follow the on-screen instructions to complete driver installation.

4. Plug JetFlash into an available USB port. You will be able to find a new

Removable Disk drive with a newly assigned drive letter in the My

Computer window.

Driver Installation for Windows Me/2000/XP

No driver is required. These Windows operating systems have built-in drivers to

support JetFlash. Simply plug JetFlash into an available USB port, and

Windows will install the files needed to use your device. You will be able to find a

new Removable Disk drive with a newly assigned drive letter in the My

Computer window.

Driver Installation for Mac OS 9.0 or Later

No driver is required. Just plug JetFlash into an available USB port and your

computer will automatically detect it. You can see a new Disk icon on the

Desktop.

Driver Installation for Linux Kernel 2.4 or Later

1. Execute cat /etc/sysconfig/hwconf | more

2. Search desc:”Jetflash xxxMB” (xxxMB is the JetFlash memory size) and

find the mount point for the device.

3. Make a directory in /mnt (example: mkdir /mnt/JetFlash)

4. Execute mount /dev/sda /mnt/JetFlash (/dev/sda is the mount point)

Write-Protect Function

When the Write-Protect switch is set to “ ”, you can read/write data from/into

JetFlash. When the Write-Protect switch is set to “ ”, you can’t write data into

JetFlash. You can only read data from JetFlash.

How to Safely Unplug JetFlash

To Remove JetFlash in Windows Me/2000/XP

1. Locate the green arrow icon on the system tray. Right click on the icon.

2. Unplug or eject hardware pop-up menu will appear. Click to enter the

window.

3. Select USB Mass Storage Controller and click Stop to continue.

4. Stop a Hardware device window will appear. Click OK to continue.

5. Safe To Remove Hardware window will appear. Click OK to continue.

6. JetFlash is now ready to be unplugged.

To Remove JetFlash in Mac OS

Drag and drop the Disk icon corresponding to JetFlash into the trashcan. Then,

unplug JetFlash from the USB port.

To Remove JetFlash in Linux

Execute umount /mnt/JetFlash to un-mount the device.

Before removing JetFlash, please make sure the LED is steady and not

flashing!If you remove JetFlash while the LED is flashing,

unpredictable damage to the files and/or JetFlash may occur.

If you don’t follow the above procedure to remove JetFlash, data may

be lost due to a write cache issue.

UMSDTools

UMSDTools is an Application Program for JetFlash, supported by most

Windows platforms. It adds exciting features to JetFlash, including Security

Function and Boot-Up Function, and Recover Disk to restore JetFlash

function if JetFlash is ever damaged. Before utilizing these features, you need

to first refer to the following procedures to install the UMSDTools Application

Program to JetFlash.

UMSDTools is not supported by Mac or Linux operating systems.

UMSDTools Installation

1. Insert the Driver CD into the CD-ROM. Find Setup.exe in D:\UMSDTools\.

(Where “D” is the drive letter of your CD-ROM drive.) (If JetFlash has been

Resized, you can also find Setup.exe in the Public Area of your JetFlash

『Security Area』or in the Public Area of a 『Public Area Only』Type.)

2. Double-click on the Setup.exe icon to install UMSDTools.

3. Follow the on-screen instructions to complete UMSDTools installation.

4. The UMSD Install window will appear.

5. If Yes is selected, the UMSD 2.33 window will appear. And you can

establish a Security Area on JetFlash.

6. or will appear on the Windows system tray when JetFlash is

connected to a USB port. If one of these icons does not appear, unplug

JetFlash and try plugging it in again.

If appears on the Windows system tray, please follow the steps below to

reinstall the Driver for JetFlash.

1. Click the button on the task bar and select Programs.

2. Select .

3. Select and follow the on-screen instructions to reinstall the

driver for JetFlash.

To Uninstall UMSDTools

1. Click the button on the task bar and select Programs.

2. Select .

3. Select and follow the on-screen instructions to uninstall

UMSDTools.

Security Function

Partition Types

UMSDTools can be used to partition JetFlash into three partition types. Before

partitioning (Resize), you need to understand the following terms and concepts.

Type 1: 『Public Area Only』Type

This is the default partition type for JetFlash, which makes the entire JetFlash

memory accessible by anyone. Access to data is unrestricted. No secure data

area is established. If Security function had been previously setup, it is cancelled

if this partition type is selected.

『Public Area Only』Type

Type 2: 『Security Area』Type

JetFlash is partitioned into a single Logical Unit Number (LUN) identified device,

which contains a Public Area and a Security Area. Secure data can be

established in the Security Area, which is protected by password. As for the

data in the Public Area, access is unrestricted.

『Security Area』Type

Both data areas cannot be seen at the same time. You must “Log In” by

entering the correct password to access data in the Security Area. You

switch from Security Area to Public Area by using “Log Out”.

Type 3: 『Public Area + Security Area』Type

JetFlash is partitioned into two LUN identified devices—a 『Public Area Only』

Type device and a 『Security Area』Type device. A『Public Area Only』Type

device is a Public Area with unrestricted access to data. A『Security Area』

Public Area

Security Area
