Product Specifications
Product Applications
Dickson’s new Flat Panel LCD Recorder lets you view detailed temperature (FT300/325) or temperature and
humidity (FH320/325) data on its large screen and allows for optional PC downloads. Its large 4.5” x 3.4”
display shows you current temperature and humidity readings and displays a graph of data ranging from 1
hour to 32 days. No paper charts or running back to your PC to see data, this recorder shows you everything
at the push of a button.
Ideal for:
• Checking building automation systems
• Tracking Critical Processes
• Monitoring Walk-in Freezers, Coolers and Storage Rooms.
• Monitoring Clean Rooms & Isolation Rooms
FT300/325
User Selectable
Temperature Ranges:
FT300: 0 to +100˚F, -10 to +40˚C, 0 to +50˚F/C FT325: -20 to +80˚F/C,
-40 to +140˚F/C, 0 to +100˚F/C, 0 to +150˚F/C, 0 to +250˚F, 0 to +300˚F
Temperature Range: 0 to +120˚F (-17.8 to +48.9˚C)
Remote Temperature: FT325: -40 to +300˚F (-40 to +150˚C)
Temperature Accuracy: ±1.2˚F (±0.7˚C) from +22 to +122˚F (-5 to +50˚C); ±1.8˚F (±1˚C)
remaining
Remote Temperature
Accuracy: (FT325)
±1.2˚F (±0.7˚C) from +22 to +122˚F (-5 to +50˚C); ±1.8˚F (±1˚C)
remaining
Temperature Sensor: Thermistor
Remote Sensor: (FT325) Thermistor with coated tip practical for immersion. 10 ft. long.
Sample Storage Rate: (user
selectable)
Time graph interval options: 10 sec; 20 sec, 30 sec, 40 sec, 1 min, 2 min,
3 min
Time Samples Displayed: Sample Rate/Time: 10 sec/45.8 min; 20 sec/1.5 hrs; 30 sec/2.3 hrs; 40
sec/3 hrs, 1 min/4.5hrs; 2 min/9.1 hrs; 3 min/13.7 hrs
Download Type: USB (1:15 minutes) or FLASH Memory Card (36 seconds)
Alarm Type: Audio/visual; High/low and low battery conditions
Ambient Operating
Conditions:
Logger: 0 to +120˚F (-17.8 to +49˚C), 0 to 95% RH (non-condensing,
dependent upon display operating range); Probe: -40 to +300˚F (-40 to
+150˚C), 0 to 95% RH (non-condensing)
Data Capacity: 64,000 (32,000 per channel) 275 Sample Points Displayed on Graph
Power Source: 120 VAC / 60 Hz / 16 W adapter (9V battery back-up)
Power Status Indicator: LCD Display
Battery Backup: Yes
Battery Life (Avg): 48 hours (when on battery power display goes to sleep after 1 minute
- can be reactivated with the push of any button)
Software Required: None Required, A016 or A026 optional (v 11.7.0)
IP Rating IP20
