Access5830™ M5830S-SU-EXT/M5830S-AP-EXT Professional Installation Guide
Trango Broadband Wireless – Rev. C Page 2
Overview
This manual covers basic configuration and installation of the Access5830 Subscriber Unit M5830S-SU-EXT and
Access point unit M5830S-AP-EXT. Since these devices require manual maximum power limit, they are classified
by the FCC as a professional install device. To be in compliance with FCC guidelines, the radio must be installed
with one of several approved antennas listed in this document.
The M5830S-SU-EXT is currently FCC certified for use with three external antennas.
Antenna Part # Descrition Gain
AD5830-24-D 18” DSS Dish 24 dBi
AD5830-23-D 15” Flat Panel 24 dBi
SPD3-5.2 3’ Dish from Radiowaves 31 dBi
The M5830S-AP-EXT is currently FCC certified for use with three external antennas.
Antenna Part # Descrition Gain
OD58-12 Vert. pol Omni from Pac Wireless 12 dBi
SAH58-120-16 120 degree Horiz. Pol sector from Pac Wireless 16 dBi
SEC-55D-90-16 90 degree H and V sector from Radiowaves 16 dBi
The M5830S-SU-EXT subscriber unit (SU) works in conjunction with the M5830S-AP-60 or M5830S-AP-EXT
access point. Please see the Access5830 User Manual for general information on overall system implementation,
configuration, and management of the access point. The Access5830 User Manual also covers many important
aspects of subscriber unit configuration and management which is applicable to the M5830S-SU-EXT.
FCC Information
This device complies with Part 15 of FCC Rules and Regulations. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio-frequency energy and, if not installed
and used in accordance with these instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in any particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to correct the interference by one of more of the following measures:
1) Reorient the antenna;
2) Increase the separation between the affected equipment and the unit;
3) Connect the affected equipment to a power outlet on a different circuit from that which the receiver is
connected to;
4) Consult the dealer and/or experienced radio/TV technician for help.
FCC ID: NCYM5830SSUEXT (Subscriber unit)
Canada: 2945A-M5830SUE (Subscriber unit)
FCC ID: NCYM5830SAP60 (Access point)
Canada: 2945A-M5830SAP (Access Point)
IMPORTANT NOTE:
Intentional or unintentional changes or modifications must not be made unless under the express consent of the
party responsible for compliance. Any such modifications could void the user’s authority to operate the equipment
and will void the manufacturer’s warranty. To comply with FCC RF exposure requirements, the following antenna
