Trane BAYDUCT010A Manuel utilisateur

SSAAFFEETTYY WWAARRNNIINNGG

Only qualified personnel should install and service the equipment The installation, starting up,

and servicing of heating, ventilating, and air-conditioning equipment can be hazardous and

requires specific knowledge and training Improperly installed, adjusted or altered equipment

by an unqualified person could result in death or serious injury When working on the

equipment, observe all precautions in the literature and on the tags, stickers, and labels that

are attached to the equipment

June 2020 AACCCC--SSVVNN222222BB--EENN

Installation Guide

Duct Flange Kit

Odyssey Split System Air Handlers

5 to 25 Tons

BBAAYYDDUUCCTT001100AA:

TWE051, TWE060,

TWE072, TWE076,

TWE090, TWE120

and TWE101

BBAAYYDDUUCCTT001111AA:

TWE126, TWE150,

TWE156, TWE180,

TWE201, TWE240,

TWE251 and

TWE300

Introduction

Read this manual thoroughly before operating or servicing this unit

Warnings, Cautions, and Notices

Safety advisories appear throughout this manual as required Your personal

safety and the proper operation of this machine depend upon the strict

observance of these precautions

The three types of advisories are defined as follows:

WARNING

Indicates a potentially hazardous situation which, if not avoided,

could result in death or serious injury.

CAU

TION

Indicates a potentially hazardous situation which, if not avoided,

could result in minor or moderate injury. It could also be used to

alert against unsafe practices.

NOTICE

Indicates a situation that could result in equipment or property-

damage only accidents.

Important Environmental Concerns

Scientific research has shown that certain man-made chemicals can affect

the earth’s naturally occurring stratospheric ozone layer when released to

the atmosphere In particular, several of the identified chemicals that may

affect the ozone layer are refrigerants that contain Chlorine, Fluorine and

Carbon (CFCs) and those containing Hydrogen, Chlorine, Fluorine and

Carbon (HCFCs) Not all refrigerants containing these compounds have the

same potential impact to the environment Trane advocates the responsible

handling of all refrigerants-including industry replacements for CFCs and

HCFCs such as saturated or unsaturated HFCs and HCFCs

Important Responsible Refrigerant Practices

Trane believes that responsible refrigerant practices are important to the

environment, our customers, and the air conditioning industry All

technicians who handle refrigerants must be certified according to local

rules For the USA, the Federal Clean Air Act (Section 608) sets forth the

requirements for handling, reclaiming, recovering and recycling of certain

refrigerants and the equipment that is used in these service procedures In

addition, some states or municipalities may have additional requirements

ACC-SVN222B-EN 3

that must also be adhered to for responsible management of refrigerants

Know the applicable laws and follow them

WWAARRNNIINNGG

PPrrooppeerr FFiieelldd WWiirriinngg aanndd GGrroouunnddiinngg RReeqquuiirreedd!!

Failure to follow code could result in death or serious injury

All field wiring MUST be performed by qualified personnel Improperly

installed and grounded field wiring poses FIRE and ELECTROCUTION

hazards To avoid these hazards, you MUST follow requirements for field

wiring installation and grounding as described in NEC and your local/state/

national electrical codes

WWAARRNNIINNGG

PPeerrssoonnaall PPrrootteeccttiivvee EEqquuiippmmeenntt ((PPPPEE)) RReeqquuiirreedd!!

Failure to wear proper PPE for the job being undertaken could result in

death or serious injury

Technicians, in order to protect themselves from potential electrical,

mechanical, and chemical hazards, MUST follow precautions in this manual

and on the tags, stickers, and labels, as well as the instructions below:

• Before installing/servicing this unit, technicians MUST put on all

PPE required for the work being undertaken (Examples; cut

resistant gloves/sleeves, butyl gloves, safety glasses, hard hat/

bump cap, fall protection, electrical PPE and arc flash clothing)

ALWAYS refer to appropriate Safety Data Sheets (SDS) and OSHA

guidelines for proper PPE

• When working with or around hazardous chemicals, ALWAYS

refer to the appropriate SDS and OSHA/GHS (Global Harmonized

System of Classification and Labelling of Chemicals) guidelines

for information on allowable personal exposure levels, proper

respiratory protection and handling instructions

• If there is a risk of energized electrical contact, arc, or flash,

technicians MUST put on all PPE in accordance with OSHA, NFPA

70E, or other country-specific requirements for arc flash

protection, PRIOR to servicing the unit NEVER PERFORM ANY

SWITCHING, DISCONNECTING, OR VOLTAGE TESTING

WITHOUT PROPER ELECTRICAL PPE AND ARC FLASH CLOTHING

ENSURE ELECTRICAL METERS AND EQUIPMENT ARE PROPERLY

RATED FOR INTENDED VOLTAGE

IInnttrroodduuccttiioonn

4ACC-SVN222B-EN

WWAARRNNIINNGG

FFoollllooww EEHHSS PPoolliicciieess!!

Failure to follow instructions below could result in death or serious injury

• All Trane personnel must follow the company’s Environmental,

Health and Safety (EHS) policies when performing work such as

hot work, electrical, fall protection, lockout/tagout, refrigerant

handling, etc Where local regulations are more stringent than

these policies, those regulations supersede these policies

• Non-Trane personnel should always follow local regulations

This document and the information in it are the property of Trane, and may

not be used or reproduced in whole or in part without written permission

Trane reserves the right to revise this publication at any time, and to make

changes to its content without obligation to notify any person of such

revision or change

rademarks

All trademarks referenced in this document are the trademarks of their

respective owners

Inspection

Inspect the shipping carton and its contents Check for concealed damage

before it is stored or used If damaged, it should be reported to, and claims

made against the transportation company Replace damaged parts with

authorized parts only

Parts List

able 1. BAYDUC 010* — Single Blower AH Kit

Part Description Quantity

Long Duct Flange 2

Short Duct Flange 2

Screws 12

IInnttrroodduuccttiioonn

ACC-SVN222B-EN 5

able 2. BAYDUC 011* — Dual Blower AH Kit

Part Description Quantity

Duct Flange 2

Screws 20

IInnttrroodduuccttiioonn

6ACC-SVN222B-EN

Installation

Single Blower Air Handler (4.6 – 10 ton)

For single blower air handlers, there are four duct flanges See “Parts

List,” p 4 for details

1 Align the duct flanges with the holes provided on the top of the unit

2 Use the screws provided in the kit to secure the duct flanges to the air

handler See drawing that follows

Figure 1. WE051 and WE060 Single Blower Air Handler

16 1/4"

(412.8)

24 1/16"

(611.2)

DUCT FLANGE

1" (25.4)

HEIGHT

SUPPLY

OPEN

Dual Blower Air Handler (10.4 – 25 ton)

1 Bend both duct flanges to 90 degrees at the notch position

Figure 2. BAYDUC 011* 90 degree bend

2 Align the duct flanges with the holes provided on the top of the unit

See drawing that follows

ACC-SVN222B-EN 7

Figure 3. BAYDUC 011* dimensions

54.89

16.13

3 Use the screws provided in the kit to secure the duct flanges to the air

handler See drawing that follows

Figure 4. WE126, WE150, WE156 and WE180 Dual Blower Air

Handler

16 5/16"

(414.3)

54 15/16"

(1395.4)

DUCT FLANGE

1" (25.4)

HEIGHT

SUPPLY

OPEN

SUPPLY

OPEN

IInnssttaallllaattiioonn

Trane and American Standard create comfortable, energy efficient indoor environments for

residential applications For more information, please visit trane com or americanstandardair com

Trane and American Standard have a policy of continuous product and product data improvement and reserve the

right to change design and specifications without notice We are committed to using environmentally conscious

print practices

ACC-SVN222B-EN 17 Jun 2020
