Print Server Application Guide
TD‐W8968TD‐W8970/TD‐W8970B
TD‐W8980/TD‐W8980B
1910010772
Rev:1.0.0
Contents
Overview..............................................................................................................................................................................................1
Installation for Windows OS ..............................................................................................................................................................2
Application for Windows OS .............................................................................................................................................................7
How to launch/exit the TP-LINK USB Printer Controller ....................................................................................................................7
How to Print.......................................................................................................................................................................................7
How to scan.....................................................................................................................................................................................10
Other functions/ settings..................................................................................................................................................................16
Troubleshooting ...............................................................................................................................................................................33
Overview
Print server is a function embedded in your modem router. It allows you to share your printer with computers that are connected to
the modem router.
Typical Topology
Here in this guide, we take the configuration procedures of TD-W8968 for example.
Computer A
TD-W8968
Printer
Computer B
USB Storage Device
Before installing the print server, make sure you have the following devices and accessories:
9Computer with Windows XP/ Vista/ 7/ 8
9USB printer and USB cable
)Note:
(1) Before connection, please check the Printer Compatibility List to verify whether your printer is supported by the modem router.
You can refer to Troubleshooting for downloading the Printer Compatibility List.
(2) Make sure you have already installed the printer’s driver on your computer. Otherwise, please install it first.
(3) Any computer in your LAN must first install the software if it wants to share the print server via the modem router.
-1-
Installation for Windows OS
1. Insert the modem router’s Resource CD into the
CD-ROM drive.
3. Click START.
2. Select your modem router model and click
Printer Sharing Setup.
4. Connect your computer and printer to the modem
router step by step as instructed. Click NEXT.
-2-
5. Check the LED lights and click NEXT.
6. Click NEXT to start installing the printer share
software.
7. Please wait a moment for the installation
preparation.
8. Click Next and go on to install the TP-LINK USB
Printer Controller.
-3-
9. Click Change… to select another destination folder, or
leave it default and click Next.
11. Click Finish to complete and exit the InstallShield
Wizard.
10. Please wait a while for the installation process.
-4-
When the installation is completed, the TP-LINK
USB Printer Controller will pop up, with whose help
you can print documents via the modem router
now.
)Note:
In your LAN, each computer that wants to share the print server should also install the TP-LINK USB Printer Controller. Please
follow the previous steps to configure other computers in your LAN.
-5-
Application for Windows OS
TP-LINK USB Printer Controller is used to operate the USB Printer on your own computer. After successful installation, the icon
will appear on the desktop of your computer.
How to launch/exit the TP-LINK USB Printer Controller
¾To launch the USB Printer Controller, double-click the icon on your desktop.
¾To exit the USB Printer Controller, click System->Exit on the TP-Link USB Printer Controller.
How to Print
To print, first of all, you need to set your Auto-Connect Printer. After successful setting, you can execute your printing tasks
automatically. Please follow the steps below to set your auto-connect printer.
-7-
Step 1: Highlight the printer you want to set as
auto-connect printer.
Step 2: Click the inverse triangle mark on the
Auto-Connect for printing tab to pull
down the list, where you can select Se
t
Auto-Connect Printer.
Step 3: Tick the name of the printer you would like
to set as auto-connect printer, and then
click Apply.
-8-
After successful setting, you will see the printer marked as Auto-Connect Printer. Then you can execute your printing task freely.
If you want to disable your printer's auto-connect function, you can delete it.
Method One:
Select Delete Auto-Connect Printer from the
drop-down list of the Auto-Connect for
Printing tab.
Method Two:
1. Go to Tools->Auto-Connect Printer List.
-9-
