User Guide

For TP-Link Omada Access Points

1910012768 REV4.6.0

June 2020

CONTENTS

About This User Guide........................................................................................................ 1

Overview ................................................................................................................................. 3

1 Quick Start....................................................................................................................... 4

1.1 Determine the Management Method.................................................................................................. 5

1.2 Build the Network Topology................................................................................................................... 6

1.3 Log In to the EAP........................................................................................................................................ 7

1.3.1 Log In via a Wireless Connection................................................................................................ 7

1.3.2 Log In via a Wired Connection ...................................................................................................... 9

1.4 Do the Basic Configurations ................................................................................................................11

1.5 Configure and Manage the EAP..........................................................................................................13

2 Configure the Network.............................................................................................. 14

2.1 Configure the Wireless Parameters..................................................................................................15

2.1.1 Configure SSIDs .............................................................................................................................. 16

2.1.2 Configure Wireless Advanced Settings ................................................................................. 22

Radio Setting.................................................................................................................................... 22

Load Balance.................................................................................................................................... 24

Airtime Fairness .............................................................................................................................. 24

More Settings .................................................................................................................................. 25

2.2 Configure Portal Authentication ........................................................................................................26

Configure Portal............................................................................................................................................ 27

Configure Free Authentication Policy .................................................................................................. 33

2.3 Configure VLAN........................................................................................................................................35

2.4 Configure MAC Filtering........................................................................................................................36

2.5 Configure Scheduler...............................................................................................................................38

2.6 Configure Band Steering.......................................................................................................................41

2.7 Configure QoS...........................................................................................................................................43

2.8 Configure Rogue AP Detection...........................................................................................................47

Detect Rogue APs and Move the Rogue APs to the Trusted AP List....................................... 48

Manage the Trusted AP List..................................................................................................................... 50

3 Monitor the Network ..................................................................................................52

3.1 Monitor the EAP........................................................................................................................................53

3.2 Monitor the Wireless Parameters......................................................................................................54

Monitor the SSIDs........................................................................................................................................ 55

Monitor the Radio Settings....................................................................................................................... 56

Monitor Radio Traffic .................................................................................................................................. 56

Monitor LAN Traffic ..................................................................................................................................... 57

3.3 Monitor the Clients ..................................................................................................................................58

View Client Information.............................................................................................................................. 59

View Block Client Information ................................................................................................................. 60

4 Manage the EAP...........................................................................................................61

4.1 Manage the IP Address of the EAP....................................................................................................62

4.2 Manage System Logs .............................................................................................................................64

View System Logs ....................................................................................................................................... 65

Configure the Way of Receiving Logs.................................................................................................. 65

4.3 Configure Web Server............................................................................................................................67

4.4 Configure Management Access.........................................................................................................68

Configure Access MAC Management.................................................................................................. 68

Configure Management VLAN ................................................................................................................ 69

4.5 Configure LED ...........................................................................................................................................70

4.6 Configure Wi-Fi Control (Only for Certain Devices)....................................................................70

4.7 Configure PoE Out (Only for Certain Devices) ..............................................................................71

4.8 Configure SSH...........................................................................................................................................72

4.9 Configure SNMP.......................................................................................................................................73

5 Configure the System................................................................................................ 75

III

5.1 Configure the User Account ................................................................................................................76

5.2 Controller Settings..................................................................................................................................77

Enabling Cloud-Based Controller Management............................................................................... 77

Configuring Controller Inform URL........................................................................................................ 78

5.3 Configure the System Time..................................................................................................................78

Configure the System Time ..................................................................................................................... 79

Configure Daylight Saving Time............................................................................................................. 81

5.4 Reboot and Reset the EAP....................................................................................................................83

5.5 Backup and Restore the Configuration............................................................................................84

5.6 Update the Firmware ..............................................................................................................................84

6 Application Example ..................................................................................................86

6.1 Determine the Network Requirements ............................................................................................87

6.2 Build the Network Topology.................................................................................................................87

6.3 Log in to the EAP ......................................................................................................................................88

6.4 Configure the EAP ...................................................................................................................................89

Configure SSIDs ........................................................................................................................................... 89

Configure Portal Authentication............................................................................................................. 90

Configure Scheduler................................................................................................................................... 92

6.5 Test the Network......................................................................................................................................93

Appendix: Omada App .................................................................................................96

1 Install Omada App on the Mobile Device ........................................................................................97

2 Manage and Monitor your EAP Device.............................................................................................97

About This User Guide

When using this guide, notice that features available in the EAP may vary by model and software

version. Availability of the EAP may also vary by region or ISP. All images, steps, and descriptions in

this guide are only examples and may not reflect your actual experience.

Some models featured in this guide may be unavailable in your country or region. For local sales

information, visit

https://www.tp-link.com

The information in this document is subject to change without notice. Every effort has been made

in the preparation of this document to ensure the accuracy of the contents, but all statements,

information, and recommendations in this document do not constitute the warranty of any kind,

express or implied. Users must take full responsibility for their application of any product.

Conventions

Unless otherwise noted, the introduction in this guide takes EAP245 as an example.

Wireless Speed, Range and Connected Devices Disclaimer

Maximum wireless transmission rates are the physical rates derived from IEEE Standard 802.11

specifications. Range and coverage specifications along with the number of connected devices

were defined according to test results under normal usage conditions. Actual wireless transmission

rate, wireless coverage, and number of connected devices are not guaranteed, and will vary as a

result of 1) environmental factors, including building materials, physical objects and obstacles, 2)

network conditions, including local interference, volume and density of traffic, product location,

network complexity, and network overhead and 3) client limitations, including rated performance,

location, connection quality, and client condition.

MU-MIMO Disclaimer (for EAPs that support MU-MIMO)

MU-MIMO capability requires client devices that also support MU-MIMO.

Seamless Roaming Disclaimer (for EAPs that support Seamless Roaming)

Seamless roaming requires both the access point and client devices to support 802.11k and

802.11v protocols.

Lightning and Electro-Static Discharge Protection Disclaimer (for Outdoor EAPs)

Protection against lightning and electro-static discharge may be achieved through proper product

setup, grounding and cable shielding. Refer to the instruction manual and consult an IT professional

to assist with setting up this product.

More Info

Some models featured in this guide may be unavailable in your country or region. For local sales

information, visit

https://www.tp-link.com

For technical support, latest software, and management app, visit

https://www.tp-link.com/support

The Quick Installation Guide can be found where you find this guide or inside the package of the

EAP.

The authentication information can be found where you find this guide.

Specifications can be found on the product page at

https://www.tp-link.com

To ask questions, find answers, and communicate with TP-Link users or engineers, please visit

https://community.tp-link.com

to join TP-Link Community.

If you have any suggestions or needs on the product guides, welcome to email

[email protected]

Overview

Omada series products provide wireless coverage solutions for small-medium business and

households. They can either work independently as standalone APs or be centrally managed by

Omada Software Controller, Omada Hardware Controller (OC200/OC300), or Omada Cloud-Based

Controller, providing a flexible, richly-functional but easily configured wireless network for small-

medium business and households.

Quick Start

This chapter introduces how to build a wireless network using the EAPs and how to

complete the basic settings. Follow the steps below:

Determine the Management Method

2. Build the Network Topology

3. Log In to the EAP

4. Configure and Manage the EAP

1.1 Determine the Management Method

Before building your network, choose a proper method to manage your EAP based on

your actual network situation. The EAP can support two configuration options: Standalone

Mode or Controller Mode.

■ Controller Mode

If you want to configure and manage a large-scale network centrally, which consists

of mass devices such as access points, switches, and gateways, Controller Mode is

recommended. In Controller Mode, the EAP can be centrally configured and monitored via

Omada SDN Controller.

To prepare the EAP for Omada SDN Controller Management, refer to

Controller Settings

For detailed instructions about the network topology in such situations and how to use

Omada SDN Controller, refer to the User Guide of Omada SDN Controller. The guide can

be found on the download center of our official website:

https://www.tp-link.com/support/download/

■ Standalone Mode

If you have a relatively small-sized network and only one or just a small number of devices

need to be managed, Standalone Mode is recommended. In Standalone Mode, the EAP

can be singly configured and monitored via the GUI (Graphical User Interface, also called

web interface in this text).

This User Guide introduces how to configure and monitor the EAP in Standalone Mode.

Note:

The GUI is inaccessible while the EAP is managed by a controller. To turn the EAP back to

Standalone Mode and access its GUI, you can forget the EAP on the controller or reset the EAP.

1.2 Build the Network Topology

To manage the EAPs in Standalone mode, refer to the following topology.

EAPEAPPC

IP: 192.168.0.100

Switch Router (DHCP Server)

LAN: 192.168.0.1 Internet

Clients

• The router is the gateway of the network, and devices in the LAN surf the internet via

the router. At the same time, the router acts as a DHCP server to assign dynamic IP

addresses to the EAPs and clients.

• The Layer 2 switch is connected to the LAN interface of the router.

• The PC and the EAPs are all connected to the Layer 2 switch. Since the PC and the EAPs

are in the same network segment, the PC can log in to the web pages of the EAPs and

manage them.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels TP-Link Point d'accès sans fil

TP-Link

TP-Link TL-WA7510N Manuel utilisateur

TP-Link

TP-Link Omada EAP225-Wall Manuel utilisateur

TP-Link

TP-Link Auranet Series Manuel utilisateur

TP-Link

TP-Link Auranet EAP110 Manuel utilisateur

TP-Link

TP-Link CPE Series Manuel utilisateur

TP-Link

TP-Link TL-WA701ND Manuel utilisateur

TP-Link

TP-Link WA801ND Manuel utilisateur

TP-Link

TP-Link deco AC1300 Guide de configuration

TP-Link

TP-Link TL-WA701ND Manuel utilisateur

TP-Link

TP-Link TL-WA801ND Manuel utilisateur

TP-Link

TP-Link TL-WA5210G Manuel utilisateur

TP-Link

TP-Link omada OC200 Manuel utilisateur

TP-Link

TP-Link TL-WA3001 Manuel utilisateur

TP-Link

TP-Link Omada EAP615 Manuel utilisateur

TP-Link

TP-Link AP8635-I Manuel utilisateur

TP-Link

TP-Link Auranet EAP115 Manuel utilisateur

TP-Link

TP-Link TL-WA901ND Manuel utilisateur

TP-Link

TP-Link TL-WA801ND Manuel utilisateur

TP-Link

TP-Link TL-WA801N Manuel utilisateur

TP-Link

TP-Link Omada EAP620 HD V2 Manuel utilisateur

TP-Link

TP-Link Omada Pro Manuel utilisateur

TP-Link

TP-Link Omada EAP653 Manuel utilisateur

TP-Link

TP-Link Omada EAP110 Manuel utilisateur

TP-Link

TP-Link Auranet EAP225 Manuel utilisateur

Manuels Point d'accès sans fil populaires d'autres marques

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Manuel utilisateur

Ubiquiti

Ubiquiti NanoStation NSM2 Manuel utilisateur

Cisco

Cisco Aironet 1550 Series Manuel utilisateur

Aruba

Aruba IAP-335 Manuel utilisateur

Advantek Networks

Advantek Networks AWN-AP-54MR Manuel utilisateur

IP-COM

IP-COM AP355 Manuel utilisateur

Buffalo

Buffalo AirStation WLA-L11G Manuel utilisateur

EnGenius

EnGenius EnStationACv2 Manuel utilisateur

D-Link

D-Link DAP-3662 Manuel utilisateur

xG Technology

xG Technology xMax CN1300 Manuel utilisateur

Widelink

Widelink ezWave WAP-1100 Series Manuel utilisateur

Edimax

Edimax CAP1200 Manuel utilisateur

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Manuel utilisateur

Aruba

Aruba AP-203R Manuel utilisateur

LuXout Shades

LuXout Shades LUXSHADE MOTION Manuel utilisateur

CreatComm

CreatComm TB5F Manuel utilisateur

SineDigital

SineDigital MW-1500AP(H) Manuel utilisateur

Draytek

Draytek VIGORAP 902 Manuel utilisateur
