Installation Guide

Wireless N Access Point

EAP110/EAP120/EAP220

CONTENTS

About This Installation Guide

This guide is designed to familiarize you with the general layout of the EAP110,

EAP120 and EAP220, describe how to perform the hardware installation, and how

to configure the EAP Controller software in your network. Your EAP has more

features and functionalities which can be found in the User Guide.

Conventions

Unless otherwise noted, the EAP or the device mentioned in this guide stands for

300Mbps Wireless N Access Point EAP110, Wireless N Gigabit Access Point EAP120

and EAP220.

Network Topology ————————————————————— 01

Hardware Overview ———————————————————— 02

Hardware Installation ——————————————————— 05

1. Installation Requirements ....................................................... 05

2. Mounting Bracket ................................................................... 05

3. Installation ............................................................................ 06

4. Power Supply......................................................................... 11

Software Conguration —————————————————— 13

Q&A ——————————————————————————— 14

Specications ——————————————————————— 15

Network Topology

A typical network topology for the EAP is shown below.

Controller Host

Hardware Overview

1. LED

EAP110, EAP120 and EAP220 have the same LED status and corresponding

indications.

System LED

LED Status Indication

Solid green The device is working properly.

Flashing red System errors. RAM, Flash, Ethernet, WLAN or

firmware may be malfunctioning.

Flashing yellow Firmware update is in progress. Do not disconnect

or power off the device.

Double-flashing red, green, yellow The device is being reset to its factory default

settings.

2. Interface Panel

■EAP110

ARROW 1

RESET ETHERNET

■EAP120/EAP220

ARROW 1

RESET CONSOLE ETHERNET ON/OFF POWER

Please note that EAP110 does not have the CONSOLE port, POWER port or ON/OFF

button. The interface panel components of the EAP, from left to right, are described

in the following list.

Kensington Security Slot

Secure the lock (not provided) into the security slot to prevent the device from

being stolen.

RESET

With the device powered on, press and hold the RESET button for about 8 seconds

until the LED ashes red, then release the button. The device will restore to factory

default settings.

CONSOLE

This port is used to connect to the serial port of a computer or a terminal to check

and monitor system information of EAP120/EAP220.

Note: CLI commands are not available in current software version. We will release

a new version supporting CLI commands soon. Please pay close attention to our

ofcial website.

ON/OFF

Press this button to turn on/off the EAP120/EAP220.

POWER

The power port is used to connect the EAP120/EAP220 to an electrical wall outlet

via power adapter. Please only use the provided power adapter. Refer to next

chapter 4.Power Supply to learn how to power the EAP120/EAP220 via power

adapter.

ARROW 1

This arrow is used to align with ARROW 2 on the mounting bracket to lock the EAP

into place. Please refer to next chapter 2.Mounting Bracket to locate ARROW 2.

ETHERNET

For EAP110, this port is used to connect to the POE port of the provided PoE

adapter for both data transmission and power supply through Ethernet cabling.

For EAP120/EAP220, this port is used to connect to a router or a switch to transmit

data or to a PSE (Power Sourcing Equipment), such as a PoE switch, for both data

transmission and Power over Ethernet (PoE) through Ethernet cabling.

■Passive PoE Adapter

The PoE adapter is ONLY provided with EAP110 for power supply. Refer to next

chapter 4.Power Supply to learn more about power supply for EAP110.

Power LED

The Power LED indicates the status of the electric current: green (0-0.8A), red

(0.8A-1A).

POE Port

This port is used to connect to the ETHERNET port of EAP110.

LAN Port

This port is used to connect to your LAN.

Hardware Installation

The EAP can be wall-mounted or ceiling-mounted. Please suitably arrange your

wire layout before mounting the EAP. We take EAP110 as example to explain the

installation. EAP110 can be powered via the provided PoE adapter, while EAP120

and EAP220 can be powered via a PoE switch or the provided power adapter.

1. Installation Requirements

Before installation, check the package contents for the following items:

Other installation equipments may require, including a pencil, ruler, drill, drill bit,

screwdriver and a ladder.

2. Mounting Bracket

The following figure describes the layout of the mounting bracket.

Locking clip

ARROW 2 is used to align

with ARROW 1 under the

interface panel

Ceiling mounting slot

Wall mounting slot

EAP Mounting Bracket Installation Guide

Wing Nuts (3) Washers (3) Plastic Wall

Anchors (3)

Self-tapping

Screws (3)

Pan-head

Screws (3)

3. Installation

■Ceiling Mounting

Note:

■Make sure the thickness of the ceiling is less than 18mm and

the ceiling can bear at least five kilograms.

■It is NOT recommended to mount the EAP on a low-strength

material, such as gypsum ceiling panel. If no other choice is

available, make sure you add a piece of strong material under

the wing nuts to ensure the EAP is mounted solidly.

1. Remove the ceiling tile.

2. Place the mounting bracket in the center of the ceiling tile. Mark the positions

of the three mounting slots and a hole for the Ethernet cable to feed through.

L≈40mm

Mark of the hole for Ethernet

cable to feed through

3. Use a drill with the appropriate size drill bit to drill three 4mm holes for

the pan-head screws, and drill a 10mm hole for the Ethernet cable to feed

through.

10mm hole for Ethernet cable feed

4mm hole for mounting bracket

4. Secure the mounting bracket to the ceiling tile using the pan-head screws,

washers and wing nuts, as shown below.

Hole to feed the Ethernet cable

Hole to feed the screw

Pan-head screw

Wing nut

Washer
