TP-Link KC300S2 Manuel utilisateur

User Guide

Kasa Wire-Free Camera

About This Guide

This guide provides a brief introduction to the Indoor/Outdoor Security Camera System and the Kasa app, as well as regulatory information.

Features available in Kasa Smart Wire-Free Camera may vary by model and software version. Kasa Smart Wire-Free Camera availability may also vary

by region. All images, steps, and descriptions in this guide are only examples and may not reect your actual experience.

Conventions

In this guide, the following convention is used:

Convention Description

Camera Stands for Kasa Smart Wire-Free Camera.

Hub Stands for Kasa Smart Camera Hub.

Teal Key information appears in teal, including management page text such as menus, items, buttons and so on.

Underline Hyperlinks are in teal and underlined. You can click to redirect to a website.

More Info

• Specications can be found on the product page at https://www.tp-link.com.

• Our Technical Support and troubleshooting information can be found at https://www.tp-link.com/support.

Introduction

An Indoor/Outdoor Security Camera System generally includes one Kasa Smart Camera Hub and one or more Kasa Smart Wire-Free Cameras.

The Kasa Smart Wire-Free Camera monitors anywhere and everywhere. Monitor live video and recordings directly on the Kasa Smart app from the

convenience of your smartphone. The Kasa Smart Camera Hub adds a layer of security with a siren, alert and audio recordings to mimic occupancy.

Your home is always protected.

• Night Vision

At night, the camera will detect activity up to 25 ft. away with night vision.

• Wired or Wire-free

A camera that gives you freedom to take it anywhere you want. When connected to our adapter, the

Kasa Smart camera allows for a pre-roll which begins recording a few seconds before every clip.

• Crystal Clear 1080p Video

Sharp and clear 1080p video makes sure you never miss a thing. In the dark, the camera will detect

activity up to 25 feet away with Night Vision.

• Rechargeable Lithium Ion Battery*

With a low-power Wi-Fi protocol, we’ve extended the battery life for a longer and smarter experience.

*Optional: Adapter for wired use if needed.

• Built-in Siren and 2-way Talk

Use crisp 2-way audio to communicate with the delivery person at your front door or use the

camera’s siren to scare away intruders.

• More Than A Hub

The hub helps save power and also plays as a secondary security alarm. Any intruder will be met with

an unwelcome sound.

• Weatherproof

The Kasa Smart Wire-Free Camera is weatherproof and will be protected against rain and dust.

Appearance

Kasa Smart Wire-Free Camera has a system LED that changes color according to its status, speakers and microphone, and a Sync button. See the

explanation below:

Speaker and Microphone

Built-in internal speaker and microphone are protected by the waterproof membrane.

！

Warning: Do NOT insert objects into the holes!

Sync button

• Press for 1 second duringDiscovery

mode:

Initiates the syncing process with hub

• Press and hold for about 15 seconds:

Resets the camera to factory settings

System LED

• Alternating amber and green:

Powering on or starting up

• Flashing green:

Connecting to hub (Discovery

mode)

• Solid green:

Connected to hub

• Quick ashing red:

Failed to connect to or sync with

hub

Flashing red once per minute:

Low battery (below 15%)

• Quick ashing amber:

Firmware updating

Flashing amber once per second:

Factory resetting

• Solid amber:

No connection, initializing, or

rebooting

• Solid blue:

Battery starts charging

• O:

No power or Status LED o

Kasa Smart Camera Hub has a LED ring that changes color according to its status, a Siren O button, and a Reset button. See the explanation below:

Reset button

• Press and hold for about 15 seconds

when neither siren nor alert is playing:

Resets the hub to factory settings

Siren O button

• Press for 1 second when siren is on:

Turns o the siren

System LED

• Alternating orange and green:

Connected to home router but no internet connection

• Alternating red and green:

Not connected to home router and internet

• Quick ashing green:

Camera attempting to sync with hub (Discovery mode)

Flashing green once per second:

Connected to home router and internet

• Solid green:

Camera connected to hub

• Solid red:

Camera too far from hub

• Flashing red:

Siren or speaker is on

• Quick ashing orange:

Firmware updating

Flashing orange once per second:

Factory resetting

• Solid orange:

Powering on or starting up

• O:

Communicating with camera and internet, no camera

connected, or no power

Power Up Your Camera

Method 1: Powered by Battery

1. Remove the protective lm on the battery. 2. Open the cover of the camera. 3. Insert the battery. Make sure its positive and

negative ends are facing the correct direction.

4. Firmly press the cover for the secure seal.

Power Up Your Camera

Method 2: Powered by Power Adapter

1. Pull up the cover for USB cable on the back and connect it

to the provided power adapter.

2. Connect the power adapter to an outlet.

How to Charge Your Battery?

If you have installed the battery but the LED of the camera is o, then probably the battery is out of power and need to be charged. When the LED of

the camera blinks red once per minute, it means the battery power is low and need to be charged. Follow the instructions below to charge the battery.

1. Insert the battery based on Method 1 above.

2. Connect the camera to a power outlet based on Method 2 above.

Set Up Your Camera

Follow the steps below to get started with your new camera.

Step 1. Download Kasa

Get the Kasa Smart app from the Apple App

Store or Google Play, or by scanning the QR

code below.

Step 2. Log In

Open the app, and log in with your TP-Link ID.

If you don't have an account, create one rst.

Step 3. Add Camera

Tap the button in the Kasa app, select

Add a Device, then select Kasa Cam Wire-

Free. Follow app instructions to add hub and

cameras.
