TP-Link RE450 Manuel utilisateur

Quick Installation

Guide

• English

• Français

AC1750 Wi-Fi Range Extender

TP-LINK TECHNOLOGIES CO., LTD.

Specifications are subject to change without notice. TP-LINK is a registered trademark of TP-LINK

TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or registered trademarks

of their respective holders.

No part of the specifications may be reproduced in any form or by any means or used to make any

derivative such as translation, transformation, or adaptation without permission from TP-LINK

www.tp-link.com

7106505637 REV1.0.0

CONTENTS

01 / English

08 / Français

English

Button Explanation

LED button: Press the LED button to turn all LEDs on or off.

Power button: Press the Power button to turn the extender on or off.

Two easy setup options:

　Option ONE: Using a Web Browser

　Option TWO: Using WPS (Wi-Fi Protected Setup)

LED Explanation

(RE)

Solid Blue: The extender is connected to the router,

and is in a good location.

Solid Red: The extender is connected to the router,

but too far away from the router.

Blinking: WPS connection is in progress.

Off: No active connection.

2.4GHz/5GHz

On: The extender is connected to both 2.4GHz and

5GHz Wi-Fi bands of your host network.

Off: No connection.

Power

On/Off: The extender is on/off.

Blinking: The extender is initializing.

English

1 Power on

Plug the extender into an electrical outlet near your

router, and wait until the Power LED is lit and solid blue.

2 Login

① Disconnect the Ethernet (wired) connection

to your computer. Click the Wi-Fi icon on the

taskbar and connect to the extender's network :

TP-LINK_Extender_2.4GHz/5GHz.

Connections are available

Not connected

Wireless Network Connection

Connect automatically Connect

TP-LINK_Extender_2.4GHz/5GHz

√

② Launch a web browser and type

http://tplinkrepeater.net in the address ﬁeld. Use

admin (all lowercase) for both Username and Password

to log in.

Option ONE：Using a Web Browser

English

If the login window does not pop up, please refer to the

FAQ > Q1.

3 Conﬁgure

① Create a new username and password to log in the

web-based interface, then click Conrm.

② Select your country/region, then click Next.

Exit Next

Region

2.4GHz Host Network

5GHz Host Network

Wireless Settings

Summary

Region: Please select your country/region.

Per FCC regulations, all Wi-Fi products marketed in the U.S.

are ﬁxed to the U.S. region.

③ Select your router's 2.4GHz and 5GHz host network

and enter the password, then click Next.

Please select 2.4GHz Host network or skip this network.

SSID Signal MAC Address Security

Your router wireless name 30:B5:C1:33:99:76

Host 2.4GHz Password:

TP_LINK_123456 23:B5:C0:30:90:06

Back Other... Rescan Skip

Region

2.4GHz Host Network

5GHz Host Network

Wireless Settings

Summary

12345678

If your router does not support 5GHz wireless network,

please click Skip to continue.

④ Either keep the same SSIDs as your host network or

create new names for the extended networks, then click

Next.

Region

2.4GHz Host Network

5GHz Host Network

Wireless Settings

Summary

Extended 2.4GHz SSID: Your network name Copy Host SSID

Hide SSID broadcast

The extended 2.4GHz password is the same as your Host password.

Extended 5GHz SSID: Your network name_5G Copy Host SSID

Hide SSID broadcast

The extended 5GHz password is the same as your Host password.

Back Next

English

⑤ Verify your wireless settings and click Finish. The

Corresponding LEDs ( and ) should turn on

and stay solid, indicating successful connections.

4 Relocate

① Plug the extender into an electrical outlet about halfway

between your router (Host Network) and the Wi-Fi dead

zone.

② Wait until the LED is lit with a solid blue. If not,

relocate the extender closer to the router to achieve

a good (or better) signal quality.

Host Network Extended Network

Ideal Extender Placement

Blue: Ideal location Red: Too far away

Choose a location away from Bluetooth devices and other

household electronics, such as cordless phone, microwave,

and baby monitor, etc., to minimize signal interference.

Keep away from

Enjoy!

Both 2.4GHz and 5GHz extended networks share the

same Wi-Fi password as your host network, but may

have different wireless network names if you customize

the names during the conﬁguration.

English

1 Power on

Plug the extender into an electrical outlet near your

router, and wait until the Power LED is lit and solid blue.

2 Connect

① Press the WPS button on your router, and then press

the button on the extender.

WPS Press

The LED should change from blinking to a solid

state, indicating a successful WPS connection. If not,

please use Option ONE.

Some ISP gateways disable the WPS function by default, if

the WPS method fails, please use Option ONE.

② If you are connecting to a dual-band router, but only

or LED is on, please repeat step to

reconnect the other band.

3 Relocate

① Plug the extender into an electrical outlet about halfway

between your router (Host Network) and the Wi-Fi dead

zone.

Option TWO：Using WPS (Wi-Fi Protected Setup)

Please use Option ONE if your router does not support WPS.

English

② Wait until the LED is lit with a solid blue. If not,

relocate the extender closer to the router to achieve

a good (or better) signal quality.

Host Network Extended Network

Ideal Extender Placement

Blue: Ideal location Red: Too far away

Choose a location away from Bluetooth devices and other

household electronics, such as cordless phone, microwave,

and baby monitor, etc., to minimize signal interference.

Keep away from

Enjoy!

Both 2.4GHz and 5GHz extended networks share the

same SSID (network name) and password as your host

network.

Entertainment Adapter

The extender can be used as a wireless adapter to connect

any Ethernet-only device (such as a Blu-ray player, game

console, DVR, or smart TV) to your Wi-Fi network.

First, connect the extender to your router using Option ONE

or Option TWO, then connect the extender to your Ethernet-

only device via an Ethernet cable.

Smart TV Game Console Desktop

Router

Frequently Asked Questions (FAQ)

Q1. What do I do if I cannot access the extender’s web-

based interface?

A1. Make sure your computer is connected to the extended

network SSID or connect your computer to the extender

using an Ethernet cable.

A2. Make sure your computer is set to obtain an IP address

automatically.

English

A3. Verify that http://tplinkrepeater.net is correctly entered

in the web browser and press Enter.

Q2. What should I do when I cannot connect the

extender via WPS?

A. Some dual-band routers may be trouble connecting

to the extender via WPS. If you experience connection

issues, we recommend that you use the extender's

web-based interface.

Q3. What should I do if the LED does not change to

solid after completing Option ONE?

A1. You may have entered the incorrect Wi-Fi password of

your host network during the conﬁguration. Please log

into the extender's web-based interface to check the

password and try again.

A2. Please reset the extender and go through the

conﬁguration again.

Q4. How do I restore the extender to its factory default

settings?

A. While the extender is powered on, press and hold the

Reset button until all the LEDs turn on momentarily.

Français

Signication des boutons

Bouton DEL : Appuyez sur le bouton DEL pour allumer ou éteindre toutes les DEL.

Bouton d'alimentation : Appuyez sur le bouton Alimentation pour allumer ou éteindre l'extenseur.

Deux options de conguration facile :

　Option UNE : Par le navigateur Web

　Option DEUX : Par WPS (Wi-Fi Protected Setup)

Signication de l'éclairage de la DEL

(RE)

Bleu xe : L'extenseur est connecté au routeur et

bien placé.

Rouge xe : L'extenseur est bien connecté mais

trop loin du routeur.

Clignotante : Connexion WPS en cours.

Éteint : Aucune connexion active.

2,4 GHz/5 GHz

Fixe : L'extenseur est connecté aux deux bandes

Wi-Fi 2,4 GHz et 5 GHz de votre réseau hôte.

Éteint : Aucune connexion.

Alimentation

Marche/Arrêt : L'adaptateur est allumé/éteint.

Clignotante : L'extenseur est en cours d'initialisation.
