User Guide
Kasa Smart Wi-Fi Plug Mini
HS103
© 2020 TP-Link 1910012836 REV3.0.0
Contents
About This Guide ···················································· 1
Introduction ······························································· 2
Appearance ······························································· 3
Set Up Your Smart Wi-Fi Plug Mini ················ 4
Main Device Controls··········································· 5
Congure Your Smart Wi-Fi Plug Mini ········· 6
Create Scenes························································11
Discover Kasa·························································12
1
About This Guide
This guide provides a brief introduction to Kasa Smart Wi-Fi Plug Mini and the Kasa Smart app, as well as regulatory information.
Please note that features of Kasa Smart Wi-Fi Plug Mini may vary slightly depending on the model and software version you have, and on your location,
language and internet service provider. All images, steps, and descriptions in this guide are only examples and may not reect your actual experience.
Conventions
In this guide, the following convention is used:
Convention Description
Teal Key information appears in teal, including management page text such as menus, items, buttons and so on.
Underline Hyperlinks are in teal and underlined. You can click to redirect to a website.
More Info
• Operating temperature, storage temperature, and other specications can be found on the product page at https://www.tp-link.com.
• Our Technical Support and troubleshooting information can be found at https://www.tp-link.com/support/.
• A TP-Link Community is provided for you to discuss our products at https://community.tp-link.com.
2
Introduction
Kasa Smart Wi-Fi Plug Mini is a compact home device that turns your typical electrical wall outlet into a controllable, customizable and multi-functional
outlet, enabling you to easily control your lights and household electronic devices via Kasa Smart app on your iOS or Android devices, no matter where
you nd yourself.
Control from Anywhere Compact Design No Hub Required Home Automation
• Control from Anywhere- Manages plugged-in electronics from anywhere with the Kasa Smart app.
• Compact Design- Allows two plugs to be stacked in one wall outlet.
• No Hub Required- Connects to your home’s Wi-Fi network. No need for a hub or extra equipment.
• Home Automation- Set multiple schedules, create scenes and groups, and simulate occupancy while away with away mode.
Supported Load Types:
Heater: ≤1500 W Toaster: ≤850 W
Humidier: ≤260 W Tower Fan: ≤50 W
Iron: ≤1500 W
3
Appearance
Smart Wi-Fi Plug Mini has a control button to turn on/o devices plugged in, and LED to show you the current status. For detailed information, see the
explanation below:
*HS103 (US version) is used for demonstration in this guide.
Press to turn the socket ON or OFF.
Press and hold (for 5 seconds) until the LED ashes amber and blue alternately to
initiate the app conguring process (SoftAP).
Press and hold (for 10 seconds) until the LED ashes amber rapidly to factory reset
the Smart Plug Mini.
Flashing amber and blue: App conguring process (SoftAP) initiated.
Flashing blue rapidly: Connecting to the network.
Solid blue: Connected to the network.
Flashing amber rapidly: Factory reset.
Solid amber: Initializing, rebooting, or no network connection.
O: The Smart Plug Mini is switched OFF.
4
Set Up Your Smart Wi-Fi Plug Mini
Follow the steps below to set up your smart plug via Kasa Smart app.
1. Install Kasa Smart app
Get the Kasa Smart app from Google Play or
the Apple App Store, or scan the QR code
below to download it.
2. Log in or sign up with TP-Link ID
Open the Kasa Smart app and log in with
your TP-Link ID. If you don’t have an account,
create one rst.
3. Add Device
Tap the button in the Kasa Smart app,
select Add a Device >Smart Plugs > Smart
Plug Lite / Mini and then follow step-by-step
app instructions to complete the setup.
5
Main Device Controls
After you successfully set up your smart plug, you will see the home page of the Kasa Smart app. Here you can view and manage all devices that you've
added to Kasa. Tap a smart plug to control and manage it.
Home Page Device Status
6
Congure Your Smart Wi-Fi Plug Mini
Set Schedule
You can set schedules for your smart plug to turn on/o automatically to simplify your daily rountine.
1. Tap on the Device Status Page. 2. Tap the + icon and select the time and
frequency for your smart plug to turn on or o
automatically.
3. You can also choose to turn your plug on or
o at Sunrise or Sunset, which is based on the
your location.
7
Set Away Mode
You can set Away Mode for your smart plug to turn on/o automatically at random intervals while you are away to make the appearance that someone
is at home.
2. Set the time period during which your smart
plug will turn on/off automatically and select
the repeating frequency.
1. Tap on the Device Status page.
8
Set Timer
Set the countdown timer and your smart plug will automatically be turned on/o after the time ends.
2. Set the time period after which your smart
plug will turn on or o automatically.
1. Tap on the Device Status page.
