Toshiba CAMILEO P20 Manuel utilisateur
User’s Manual
CAMILEO p20
Introduction
Welcome and thank you for choosing a TOSHIBA product.
For your convenience, your TOSHIBA product is furnished with two
guides:
a) a Quick Start Guide, and
b) this comprehensive PDF User’s Manual.
Contents
Section 1 Getting to Know Your Camcorder........................................ 6
Overview ................................................................................ 6
Check the Components........................................................ 6
Safety Instructions................................................................ 7
System Requirements .......................................................... 7
Front View ............................................................................. 8
Rear View............................................................................... 8
Side View ............................................................................... 9
Bottom View .......................................................................... 9
Section 2 Getting Started..................................................................... 10
Loading the Battery ............................................................ 10
Inserting and Removing an SD Card (Optional)............... 10
Turning the Camcorder On and Getting Started .............. 11
Turning the Camcorder Off ................................................ 11
Section 3 Record Mode........................................................................ 12
Button Function .................................................................. 12
LCD Monitor Information.................................................... 13
Video Recording.................................................................. 15
Photo Recording ................................................................. 16
Taking Close up Photos/Videos......................................... 16
Using Digital Zoom ............................................................. 16
Options for Menu ................................................................ 17
Operations .......................................................................... 17
Video Setting ....................................................................... 18
Photo Setting....................................................................... 22
Effects .................................................................................. 25
Delete ................................................................................... 27
Contents
Section 4 Playback Mode..................................................................... 29
Button Function .................................................................. 29
LCD Monitor Information.................................................... 30
Operations for Playback Mode ......................................... 32
Video Playback.................................................................... 33
Photo Playback ................................................................... 33
Delete File in Playback Mode............................................. 33
Section 5 Setting Your Camcorder .................................................... 34
Setup Menu.......................................................................... 34
Section 6 Viewing Photos and Videos on TV..................................... 37
Connecting to a High-Denition 16:9(Wide) TV ............... 37
Connecting to a non-high-denition 4:3 TV ..................... 37
Section 7 Viewing Video & Photo on PC ............................................ 38
Installing Bundled Software............................................... 38
Transferring Photos or Videos to a Computer ................. 38
Section 8 Uploading Files to Internet ................................................. 39
5
EN
Contents
Section 9 Specications ..................................................................... 42
Section 10 Troubleshooting ................................................................ 43
Section 11 Other Information .............................................................. 44
TOSHIBA Support ............................................................... 44
Operating Environment Conditions .................................. 44
Regulatory Information ...................................................... 44
Additional Information........................................................ 46
About the battery pack ....................................................... 46
6
EN
Section 1
Getting to Know Your Camcorder
Overview
The camcorder with 5 Mega Pixel sensor can take H.264 videos. By way of using H.264 technology,
more videos can be taken within certain amount of memory. High quality images with up to 16 mega-
pixels can also be delivered smoothly. With a color LCD monitor, users can compose images and
examine them easily.
The camcorder features 3” LCD touch panel which is an ideal platform for you to operate your
camcorder. The menu options are accessible with your nger. With the touch panel, you can select the
options directly and quickly.
The camcorder also features video recording at HD resolution of 1920x1080. You can also connect it
to an HDTV via an HDMI cable, and easily playback the recorded high-denition videos on the wide
screen HDTV.
Moreover, the camcorder has an advanced uploading feature. With the exclusive built-in CAMILEO
UPLOADER application, you can upload the videos or photos captured by the camcorder to Internet
more effortlessly.
ISO sensitivity and color balance can either be adjusted automatically or changed manually. A 16x
digital zoom helps you to control over the videos and photos you take.
The varied effect options, such as Time Lapse and Slow Motion, make recording more fun.
The built-in memory allows you to take photos and to record videos without a memory card. The
memory card slot allows users to increase the storage capacity.
Note
Partial memory of the built-in memory is used for the camcorder’s Firmware code.•
Install the bundled software application for viewing the videos correctly on a PC.•
Check the Components
Unpack the package and make sure all standard accessories listed are included:
Note
Pleaseremovethelensprotectlmonlensbeforeuse.
Camcorder
Quick Start
Guide
*preinstalled in camcorder device
USB Cable
CD-ROM
(Software &
User’s Manual)
AV Cable
Cleaning Cloth
HDMI Cable
Strap
AC-Adaptor
Pouch
Lithiunm-ion
Rechargeable
Battery*
Tripod
MAGIX DVD
(Video Deluxe
Trial Version)
(Optional)
Warranty
Leaet
7
EN
Safety Instructions
Do not drop, puncture or disassemble the camcorder; otherwise the warranty will be voided.1.
Avoid all contact with water, and dry hands before using.2.
Do not expose the camcorder to high temperature or leave it in direct sunlight. Doing so may3.
damage the camcorder.
Use the camcorder with care. Avoid pressing hard on the camcorder body.4.
For your own safety, avoid using the camcorder when there is a storm or lightning.5.
Do not use batteries of different specications. Doing so may lead to the potential for serious 6.
damage.
Remove the battery during long periods between usage, as a deteriorated battery may affect the7.
functionality of the camcorder.
Remove the battery if it shows signs of leaking or distortion.8.
Use only the accessories supplied by the manufacturer.9.
Keep the camcorder out of the reach of infants.10.
Risk of explosion if battery is replaced by an incorrect type.11.
Dispose of used batteries according to the instructions.12.
System Requirements
Microsoft Windows XP/Vista/7•
Intel Pentium 4, 2.4GHz or above•
512 MB RAM•
CD-ROM Drive•
1 GB free HDD space•
Available USB port•
16-bit Color Display•
Note
The LCD screen is manufactured using extremely high-precision technology. However, some
tiny black and/or bright dots (white, red, blue or green) may appear on the LCD screen. These
dots are a normal result of the manufacturing process, and do not affect the recording.
8
EN
Front View
Rear View
Photo button
Video Button
Tele Button
HDMI Port
TV Port
Mini USB 2.0 Port
Wide Button
Pause Button
SD card Cover
Lens
Light
Macro Switch
LCD Touch Panel
Microphone
9
EN
Side View
Bottom View
Tripod Socket Strap Hook
Power Button Battery Cover
Speaker
Playback Button
Internet Button
10
EN
Section 2
Getting Started
Loading the Battery
Before using the camcorder, users must load the Lithium-ion
rechargeable battery come within the package.
Insert the battery according to the correct polarity marks (+1.
or -).
Close the battery cover rmly.2.
Note
Please take out the battery from the camcorder and remove the•
insulator on the battery connection before use.
Inserting and Removing an SD Card (Optional)
The camcorder comes with an internal memory which allows you
to store photos and videos. You can expand the memory capacity
by using an optional SD memory card.
Insert the memory card into the slot. Please refer to the gure 1.
on the right side.
To remove an installed SD card, press the card inwards to2.
release it.
When the card pops out, gently remove it from its slot.3.
Recommended memory capacity: 1GB or above.4.
Note
When a memory card is tted, videos/photos are saved on the card rather than on the built-in •
memory.
Protecting Data on an SD Card: SD Card is read-•
only when it is locked. No photos or videos can be
recorded when the SD card is locked. Make sure the
lock is on the writeable position before recording any
media.
REMOVE
Writeable
position
Write-Protected
Position
