Toshiba 352/452 Manuel utilisateur
User Guide
Basic Fax Features
Toshiba America Business Solutions, Inc. © 2006
Training and Dealer Development
Page 1
BASIC FAX FEATURES
Sending a FAX
Preparation for Transmission
Setting Originals
Setting the Transmission Conditions
Specifying the Remote Fax
Sending Originals
Receiving a FAX
Reception Modes
Reception Settings
Sending a FAX
Preparation for Transmission
Switching to the FAX Mode
1. Press the FAX button on the control panel to select the
Fax function.
yBe sure to switch over to the Fax mode before
carrying out Fax operations.
yIf you leave the digital copier for about 45 seconds,
it automatically returns to the copy mode.
yYou can also switch to the Fax mode when the
digital copier is in the energy-saving mode.
Page 2
Sending a FAX (Cont’d.)
Setting Originals
When Setting Originals on the Glass
NOTE: Originals are sent in the order they are placed on the original glass in both the
memory TX and direct TX modes.
1. Raise the Reversing Automatic Document Feeder, place
the original (A) with its face down on the glass. Raise it
60 degrees or more to detect the original.
2. Align the original against the left inner corner of
the glass.
yDifferent size originals can also be sent in one
transmission.
yWhen LD, LG, LT-R, ST, COMP, A3, A4-R, A5,
B4, B5 or FOLIO originals are placed as shown in the
figure on the right, the pre-entered sender information
is printed in the shaded position shown (B) in the
figure and sent to the remote Fax.
yWhen LT, ST-R, A4, A5-R or B5-R originals are
placed as shown in the figure on the right, the pre-
entered sender information is printed in the shaded
position shown (C) in the figure and sent to the
remote Fax.
3. Lower the Reversing Automatic Document Feeder slowly.
Page 3
Sending a FAX (Cont’d.)
Setting Originals
When Using the Reversing Automatic Document Feeder
NOTE: When the originals are placed on the Reversing Automatic Document Feeder, the
uppermost page is first scanned and sent.
1. After aligning the edges of originals, place them
with their face up and slide the guides to the width
of the originals.
yYou cannot mix A series format (A3, A4, A5)
and B series format (B4, B5) or LT series and
COMP. LT/A4 size originals are rotated 90oso
that they are sent as LT-R/ A4-R originals.
yIf a mixture of LD and LG, A3 and A4, or B4
and B5 originals are placed, they are sent in their
original sizes.
yWhen LD, LG, LT-R, COMP, A3 and B4, A4-R,
B5 originals are placed as shown in the figure on the
right, the pre-entered sender information is printed in
the shaded position shown (A) in the figure and sent
to the remote Fax.
yWhen LT, ST-R, A4, A5-R or B5-R originals
are placed as shown in the figure on the right, the
pre-entered sender information is printed in the
shaded position shown (B) in the figure and sent to
the remote Fax.
Page 4
Sending a FAX (Cont’d.)
Setting the Transmission Conditions
Originals can be sent using different transmission conditions (resolution, image quality mode,
exposure, transmission mode, original size, ECM, quality TX, Line, SUB/SEP/SID, PWD,
subject and body). Settings for the subject and body are available only when using a function
of the Internet Fax. If you change the transmission conditions, the new settings are valid for
one transmission only. They are returned to the default settings after transmission.
1. Place the original(s).
2. Press the FAX button on the control panel.
3. Press the ADDRESS button to enter the address menu,
and then press the OPTION button.
4. Press the desired buttons. Press the Prev or Next button to
switch the screens. The highlighted buttons in the screens
on the right are the default settings.
5. Press the ENTER button to complete the setting.
6. Specify the remote Fax and press the START button.
TIPS: When one remote Fax is specified by the address book,
and the OPTION button is selected, the contents of
the address setting will be reflected to the OPTION.
The settings of the TX type, ECM, quality TX, line
select, SUB/ SEP and SID/PWD selected in the
OPTION have priority.
Page 5
Sending a FAX (Cont’d.)
Specifying the Remote Fax
Direct Entry with Digital Keys
1. Place the original(s).
2. Press the FAX button on the control panel
3. Key in the remote Fax number.
4. If you make a mistake, press the CLEAR button on the
control panel or the BACK SPACE button in the address
menu and correct the mistake.
yCLEAR button: Press this button to clear all values
you have entered.
yBACK SPACE button: Press this button to delete each
value you have.
TIP: When you are dialing to an outside line via a PBX, there may be a pause before the
connection is made, causing a transmission error. To avoid this error, press the
MONITOR/PAUSE button after the number that designates an outside line to enter a
pause. This automatically enters a 3-second pause before the remote Fax number is dialed,
which reduces transmission errors. (The mark “-” is displayed as a “pause” on the screen.)
5. Press the START button.
Address Book Entry
Address book entry is the method for specifying remote Fax
numbers by pressing the remote Fax buttons which have
previously been registered. It is convenient if frequently
used destinations are registered in the address book.
1. Place the original(s).
2. Press the FAX button on the control panel.
3. Press the ADDRESS button to enter the address menu.
Each screen displays 8 destinations. To view destinations
not displayed on the screen, press the Prev or Next button
to switch the screens.
4. Press the button designating the remote Fax to which you
wish to send your transmission.
5. Press the START button.
Page 6
Sending a FAX (Cont’d.)
Specifying the Remote Fax (Cont’d.)
Group Entry
Group entry is the method of specifying remote Fax numbers by pressing the group button
which has previously been entered. It is convenient if multiple frequently used multiple
destinations are entered into a group.
1. Place the original(s).
2. Press the FAX button on the control panel.
3. Press the ADDRESS button to enter the address
menu, then Press the GROUP button. Each screen
displays 8 destinations. To view destinations not
displayed on the screen, press the Prev or Next button
to switch the screens.
4. Press the remote Fax group to send originals. If you
want to see the specified group members, press the
CONTENTS button. You can search for groups by ID
number and by group.
TIP: The Remote Faxes in the group can be confirmed in
the group number information. See the User Functions
Guide.
5. Press the START button.
Page 7
Specifying the Remote Fax (Cont’d.)
Multi-Address Transmission
The Multi-Address Transmission function allows you to send the same original to 2 or
more remote Faxes in a single operation, which can be done by combining direct, address
book and group entry. Combining with the Internet Fax is also available. This eliminates
the trouble of placing the original and then dialing the number for each destination.
Multi-address transmissions must be set in the memory TX mode.
The following shows the number of destinations that can be entered according to how the
remote Fax is specified:
yBy direct entry only: 400 destinations
yBy address book entry only: 400 destinations
yBy group entry only: 200 groups (400 destinations per a group)
yBy combining direct, address book and group entry: 400 destinations
1. Place the original(s).
2. Press the FAX button on the control panel.
3. Press the OPTION button and set the transmission conditions.
4. Specify the remote Fax numbers.
yTo continuously enter remote Fax numbers after
having specified them by means of the digital keys,
press the MULTI button, then enter the next number.
You do not need to press the MULTI button for the
address book or the group entry.
yThe selected destinations can be confirmed by
selecting the DESTINATION button.
TIPS: To cancel the remote Fax number entered with digital keys, press the CLEAR
button on the control panel.
To cancel a remote Fax specified with address book or group entry, press the
highlighted button for the remote Fax again. To cancel all specified remote Faxes,
press the ALL CLEAR button.
To cancel a remote Fax specified with direct entry, press the DESTINATION
button to enter the destination menu, and then cancel it.
5. Specify all remote Faxes, then press the START button.
Page 8
Sending a FAX (Cont’d.)
Specifying the Remote Fax (Cont’d.)
Searching by ID Number
When selecting the remote Faxes registered in the address and group by searching by the
ID number immediately displays the screen including the searched-for ID number.
1. Place the original(s).
2. Press the FAX button on the control panel.
3. Press the ADDRESS button to enter the address menu,
then the KNOWN ID button.
4. Key in the desired ID number, and press the ENTER
button. You can key in the number within the range of
1 to 1000.
5. Press the button for the remote Fax that you want to
send to.
yEach screen displays 8 destinations.
yTo view destinations not displayed on the screen,
press the Prev or Next button to switch the screens.
TIPS: To continue searching by ID number, press the KNOWN ID button.
To continue searching by address, press the SEARCH ADDRESS button.
6. Press the START button.
