Toro 71223 Manuel utilisateur

Operator’s Manual

Domestic English (EN)

Form No. 3323–311

Wheel Horse

16-38 XL Lawn Tractor

71223—200000001 & Up

The Toro Company – 1999

Introduction

Thank you for purchasing a Toro product.

All of us at Toro want you to be completely satisfied

with your new product, so feel free to contact your

local Authorized Service Dealer for help with service,

genuine replacement parts, or other information you

may require.

Whenever you contact your Authorized Service

Dealer or the factory, always know the model and

serial numbers of your product. These numbers will

help the Service Dealer or Service Representative

provide exact information about your specific

product. You will find the model and serial number

plate located in a unique place on the product as

shown below.

1. Modeland Serial Number Plate (under the seat)

For your convenience, write the product model and

serial numbers in the space below.

Model No:

Serial No.

Read this manual carefully to learn how to operate

and maintain your product correctly. Reading this

manual will help you and others avoid personal injury

and damage to the product. Although we design,

produce and market safe, state-of-the-art products,

you are responsible for using the product properly

and safely. You are also responsible for training

persons, who you allow to use the product, about safe

operation.

The warning system in this manual identifies

potential hazards and has special safety messages that

help you and others avoid personal injury, even death.

DANGER, WARNING and CAUTION are signal

words used to identify the level of hazard. However,

regardless of the hazard, be extremely careful.

DANGER signals an extreme hazard that will cause

serious injury or death if the recommended

precautions are not followed.

WARNING signals a hazard that may cause serious

injury or death if the recommended precautions are

not followed.

CAUTION signals a hazard that may cause minor or

moderate injury if the recommended precautions are

not followed.

Two other words are also used to highlight

information. “Important” calls attention to special

mechanical information and “Note” emphasizes

general information worthy of special attention.

The left and right side of the machine is determined

by sitting on the seat in the normal operator’s

position.

The engine exhaust from this product

contains chemicals known to the State of

California to cause cancer, birth defects,

or other reproductive harm.

IMPORTANT: This engine is not equipped

with a spark arrester muffler. It is a violation

of California Public Resource Code Section

4442 to use or operate this engine on any

forest–covered, brush–covered or

grass–covered land. Other states or federal

areas may have similar laws.

Contents

Page

Safety 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Safe Operating Practices 2. . . . . . . . . . . . . .

Toro Riding Mower Safety 4. . . . . . . . . . . .

Slope Chart 5. . . . . . . . . . . . . . . . . . . . . . . . .

Safety and Instruction Decals 7. . . . . . . . . . .

Gasoline and Oil 9. . . . . . . . . . . . . . . . . . . . . . . .

Recommended Gasoline 9. . . . . . . . . . . . . . .

Stabilizer/Conditioner 10. . . . . . . . . . . . . . . .

Filling the Fuel Tank 10. . . . . . . . . . . . . . . . .

Check Engine Oil Level 10. . . . . . . . . . . . . . .

Operation 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Think Safety First 11. . . . . . . . . . . . . . . . . . .

Controls 11. . . . . . . . . . . . . . . . . . . . . . . . . . .

Parking Brake 11. . . . . . . . . . . . . . . . . . . . . . .

Positioning the Seat 12. . . . . . . . . . . . . . . . . .

Headlights 12. . . . . . . . . . . . . . . . . . . . . . . . .

Using the Blade Control (PTO) 12. . . . . . . . .

Setting the Height-of-Cut 12. . . . . . . . . . . . . .

Starting and Stopping the Engine 13. . . . . . .

The Safety System 14. . . . . . . . . . . . . . . . . . .

Operating-in-Reverse 14. . . . . . . . . . . . . . . . .

Driving Forward or Backward 16. . . . . . . . . .

Selecting Ground Speeds 16. . . . . . . . . . . . . .

Stopping the Machine 16. . . . . . . . . . . . . . . .

Side Discharge or Mulch Grass 17. . . . . . . . .

Page

Installing the Discharge Cover 17. . . . . . . . . .

Tips for Mowing Grass 18. . . . . . . . . . . . . . .

Maintenance 19. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Service Interval Chart 19. . . . . . . . . . . . . . . .

Greasing and Lubrication 20. . . . . . . . . . . . . .

Tire Pressure 20. . . . . . . . . . . . . . . . . . . . . . . .

Brake 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Wiring Diagram 22. . . . . . . . . . . . . . . . . . . . .

Fuse 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Headlights 23. . . . . . . . . . . . . . . . . . . . . . . . .

Battery 24. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Spark Plug 26. . . . . . . . . . . . . . . . . . . . . . . . .

Fuel Tank 27. . . . . . . . . . . . . . . . . . . . . . . . . .

Fuel Filter 28. . . . . . . . . . . . . . . . . . . . . . . . . .

Air Cleaner 28. . . . . . . . . . . . . . . . . . . . . . . . .

Engine Oil 30. . . . . . . . . . . . . . . . . . . . . . . . .

Cutting Blade 31. . . . . . . . . . . . . . . . . . . . . . .

Removing the Mower 33. . . . . . . . . . . . . . . . .

Installing the Mower 35. . . . . . . . . . . . . . . . .

Blade Drive Belt 37. . . . . . . . . . . . . . . . . . . . .

Side-to-Side Mower Leveling 38. . . . . . . . . .

Front-to-Rear Blade Slope 38. . . . . . . . . . . . .

Washing Underside of Mower 40. . . . . . . . . .

Cleaning and Storage 41. . . . . . . . . . . . . . . . .

Troubleshooting 43. . . . . . . . . . . . . . . . . . . . . . . . .

          

          

         

   

          

        

          

  

Safety

This machine meets or exceeds the B71.1–1998

specifications of the American National Standards

Institute, in effect at the time of production.

However, improper use or maintenance by the

operator or owner can result in injury. To reduce

the potential for injury, comply with these safety

instructions and always pay attention to the safety

alert symbol, which means CAUTION,

WARNING, or DANGER—“personal safety

instruction.” Failure to comply with the

instruction may result in personal injury or death.

Safe Operating Practices

The following instructions are from ANSI standard

B71.1—1998.

This product is capable of amputating hands and feet

and throwing objects. Always follow all safety

instructions to avoid serious injury or death.

General Operation

•Read, understand, and follow all instructions in

the operator’s manual and on the machine before

starting.

•Allow only responsible adults who are familiar

with the instructions to operate the machine.

•Clear the area of objects such as rocks, toys,

wire, etc., which could be picked up and thrown

by the blade.

•Be sure the area is clear of other people before

mowing. Stop the machine if anyone enters the

area.

•Never carry passengers.

•Do not mow in reverse unless absolutely

necessary. Always look down and behind before

and while backing.

•Be aware of the mower discharge direction and

do not point it at anyone. Do not operate the

mower without either the entire grass catcher or

the guard in place.

•Slow down before turning.

•Never leave a running machine unattended.

Always turn off blades, set parking brake, stop

engine, and remove keys before dismounting.

•Turn off blades when not mowing.

•Stop the engine before removing the grass

catcher or unclogging the chute.

•Mow only in daylight or good artificial light.

•Do not operate the machine while under the

influence of alcohol or drugs.

•Watch for traffic when operating near or crossing

roadways.

•Use extra care when loading or unloading the

machine into a trailer or truck.

•Always wear safety goggles or safety glasses

with side shields when operating mower.

•Data indicates that operators, age 60 years and

above, are involved in a large percentage of

riding mower–related injuries. These operators

should evaluate their ability to operate the riding

mower safely enough to protect themselves and

others from serious injury.

Safety

Slope Operation

Slopes are a major factor related to loss-of-control

and tip-over accidents, which can result in severe

injury or death. All slopes require extra caution. If

you cannot back up the slope or if you feel uneasy on

it, do not mow it.

•Mow up and down slopes, not across.

•Remove obstacles such as rocks, tree limbs, etc.

•Watch for holes, ruts or bumps. Uneven terrain

could overturn the machine. Tall grass can hide

obstacles.

•Use slow speed. Choose a low gear so that you

will not have to stop or shift while on the slope.

•Follow Toro’s recommendations for wheel

weight or counterweights to improve stability.

•Use extra care with grass catchers or other

attachments. These can change the stability of

the machine.

•Keep all movement on slopes slow and gradual.

Do not make sudden changes in speed or

direction.

•Avoid starting or stopping on a slope. If tires

lose traction, disengage the blades and proceed

slowly straight down the slope.

•Do not turn on slopes unless necessary, and then,

turn slowly and gradually downhill, if possible.

•Do not mow near drop-offs, ditches, or

embankments. The machine could suddenly turn

over if a wheel goes over the edge of a cliff or

ditch, or if an edge caves in.

•Do not mow on wet grass. Reduced traction

could cause sliding.

•Do not try to stabilize the machine by putting

your foot on the ground.

•Do not use a grass catcher on steep slopes.

Children

Tragic accidents can occur if the operator is not alert

to the presence of children. Children are often

attracted to the machine and the mowing activity.

Never assume that children will remain where you

last saw them.

•Keep children out of the mowing area and under

the watchful care of another responsible adult.

•Be alert and turn the machine off if children

enter the area.

•Before and while backing, look behind and down

for small children.

•Never carry children, even with the blades off.

They may fall off and be seriously injured or

interfere with safe machine operation.

•Never allow children to operate the machine.

•Use extra care when approaching blind corners,

shrubs, trees, the end of a fence or other objects

that may obscure vision.

Service

•Use extra care when handling gasoline and other

fuels. They are flammable and vapors are

explosive.

A. Use only an approved container.

B. Never remove the gas cap or add fuel when

the engine is running. Allow the engine to

cool before refueling. Do not smoke.

C. Never refuel the machine indoors.

D. Never store the machine or fuel container

inside where there is an open flame, such as

near a water heater or furnace.

•Never run a machine inside a closed area.

•Keep nuts and bolts tight, especially the blade

attachment bolts. Keep equipment in good

condition.

Safety

•Never tamper with safety devices. Check their

proper operation regularly.

•Keep the machine free of grass, leaves, or other

debris build-up. Clean up oil or fuel spillage.

Allow the machine to cool before storing.

•Stop and inspect the equipment if you strike an

object. Repair, if necessary, before restarting.

•Grass catcher components are subject to wear,

damage and deterioration, which could expose

moving parts or allow objects to be thrown.

Frequently check components and replace with

manufacturer’s recommended parts, when

necessary.

•Mower blades are sharp and can cut. Wrap the

blade(s) or wear gloves, and use extra caution

when servicing them.

•Use only genuine Toro replacement parts to

ensure that original standards are maintained.

Toro Riding Mower Safety

The following list contains safety information

specific to Toro products or other safety information

that you must know that is not included in the ANSI

standard.

POTENTIAL HAZARD

•Engine exhaust contains carbon monoxide,

which is an odorless, deadly poison.

WHAT CAN HAPPEN

•Carbon monoxide can kill you and is also

known to the State of California to cause

birth defects.

HOW TO AVOID THE HAZARD

•Do not run engine indoors or in an enclosed

area.

•Stop the engine, disconnect spark plug wire(s)

and remove key before performing any service,

repairs, maintenance or adjustments.

•Slow down before turning. Sharp turns on any

terrain may cause loss of control.

•Never leave a running machine unattended.

Always turn off blades, set parking brake, stop

engine, and remove the ignition and “Key

Choice” keys before dismounting.

•Keep hands, feet, hair and loose clothing away

from attachment discharge area, underside of

mower and any moving parts while engine is

running.

•Do not touch equipment or attachment parts

which may be hot from operation. Allow to cool

before attempting to maintain, adjust or service.

•Remove obstacles such as rocks, tree limbs, etc.

from the mowing area. Watch for holes, ruts or

bumps, as uneven terrain could overturn the

machine. Tall grass can hide obstacles.

•Battery acid is poisonous and can cause burns.

Avoid contact with skin, eyes and clothing.

Protect your face, eyes and clothing when

working with a battery.

•Battery gases can explode. Keep cigarettes,

sparks and flames away from battery.

•Use only genuine replacement parts to ensure

that original standards are maintained.

•Mow up and down slopes greater than 5°, not

across.

•Mow downhill only on slopes above 10°, never

mow uphill. If a steep slope must be ascended,

back up the hill, and drive forward down the hill,

keeping the machine in gear.

•Do not operate machine on hillsides or slopes

exceeding 15°.

•Avoid turning on slopes. If you must turn, turn

slowly and gradually downhill, if possible.

•Do not use a grass catcher on steep slopes.

Heavy grass bags could cause loss of control or

overturn the machine.

Safety

Slope Chart

Read all safety instructions on pages 2–4.

Safety

Safety and Instruction Decals

Safety decals and instructions are easily visible to the operator and are located near

any area of potential danger. Replace any decal that is damaged or lost.

ON GRASS DEFLECTOR

AND ON

MOWER RIGHT SIDE

(Part No. 93–1122)

UNDER GRASS DEFLECTOR

(Part No. 68–3650)

ON DASH

LEFT SIDE

(Part No. 92–2461)

ON DASH

RIGHT SIDE

(Part No. 99–8139)

ON STEERING TOWER

(Part No. 92–2462)

ON MOWER LEFT SIDE

(Part No. 79–3140)

ON MOWER CENTER

(Part No. 93–6679)

ALONGSIDE MOWER LIFT BRACKETS

(Part No. 55–4300)

UNDER LEFT BELT GUIDE

(Part No. 68–3660)

Safety

ON FRAME STEP

(Part No. 99–6094)

ON SEAT

BRACKET

(Part No. 99–2985)

ON SEAT

BRACKET

(Part No. 99–5339)

UNDER HOOD

(Part No. 100–6221)

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Toro Tondeuse à gazon

Toro

Toro TimeCutter 75749 Manuel utilisateur

Toro

Toro Reelmaster 7000-D Manuel utilisateur

Toro

Toro TimeCutter SW 4200 Manuel utilisateur

Toro

Toro GrandStand 74558 Manuel utilisateur

Toro

Toro 121-7576 Manuel utilisateur

Toro

Toro eHoverPro 450 Manuel utilisateur

Toro

Toro 20955 Manuel utilisateur

Toro

Toro Greensmaster 800 Manuel utilisateur

Toro

Toro Recycler 22191 Manuel utilisateur

Toro

Toro 74730 Manuel utilisateur

Toro

Toro 4038 Manuel utilisateur

Toro

Toro Recycler SR-21OSB Manuel utilisateur

Toro

Toro Reelmaster 5100-D Manuel utilisateur

Toro

Toro Reelmaster Edge Series Manuel utilisateur

Toro

Toro Recycler 20951 Manuel utilisateur

Toro

Toro LX Series 2006 Manuel utilisateur

Toro

Toro 77505 Manuel utilisateur

Toro

Toro LX426 Manuel utilisateur

Toro

Toro eS3200DC 72V Manuel utilisateur

Toro

Toro Flex Force Power System 60V MAX 22in... Manuel utilisateur

Toro

Toro LX427 Manuel utilisateur

Toro

Toro 74901 Z Master 5000 Manuel utilisateur

Toro

Toro 74419 Manuel utilisateur

Toro

Toro 21848 Manuel utilisateur

Manuels Tondeuse à gazon populaires d'autres marques

RHINO

RHINO 1958 Manuel utilisateur

Wolf Garten

Wolf Garten Compact plus 40 B Manuel utilisateur

Cub Cadet

Cub Cadet LTX 1045 Manuel utilisateur

Craftsman

Craftsman 917.378461 Manuel utilisateur

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Manuel utilisateur

Challenge

Challenge CH18V2 Instructions de fonctionnement

TALEN TOOLS

TALEN TOOLS AVR HGM30 Manuel utilisateur

DEWEZE

DEWEZE ATM-725 Manuel d'utilisation

Weed Eater

Weed Eater 180083 Manuel utilisateur

Husqvarna

Husqvarna Poulan Pro PP185A42 Manuel utilisateur

Better Outdoor Products

Better Outdoor Products Quick Series Manuel utilisateur

Cub Cadet

Cub Cadet 23HP Z-Force 60 Manuel d'utilisation

MTD

MTD 795, 792, 791, 790 Manuel utilisateur

Dennis

Dennis FT 610 Manuel utilisateur

AIRFORCE

AIRFORCE F-15 Gen 3 Manuel utilisateur

MTD

MTD 126-220-000 Manuel utilisateur

Stihl

Stihl RMA 443 PV Manuel utilisateur

Yard-Man

Yard-Man 3700-0 Manuel utilisateur
