FormNo.3362-343RevA

50cmMulching/RearBaggingLawnMower

ModelNo.29641—SerialNo.290000001andUp

Operator'sManual

Introduction

Readthisinformationcarefullytolearnhowtooperate

andmaintainyourproductproperlyandtoavoidinjury

andproductdamage.Youareresponsibleforoperating

theproductproperlyandsafely.

YoumaycontactTorodirectlyatwww.Toro.comfor

productandaccessoryinformation,helpndinga

dealer,ortoregisteryourproduct.

Wheneveryouneedservice,genuineToroparts,or

additionalinformation,contactanAuthorizedService

DealerorToroCustomerServiceandhavethemodel

andserialnumbersofyourproductready.Figure1

identiesthelocationofthemodelandserialnumbers

ontheproduct.Writethenumbersinthespace

provided.

Figure1

1.Modelandserialnumberplate

ModelNo.

SerialNo.

Thismanualidentiespotentialhazardsandhas

safetymessagesidentiedbythesafetyalertsymbol

(Figure2),whichsignalsahazardthatmaycauseserious

injuryordeathifyoudonotfollowtherecommended

precautions.

Figure2

1.Safetyalertsymbol

Thismanualusestwowordstohighlightinformation.

Importantcallsattentiontospecialmechanical

informationandNoteemphasizesgeneralinformation

worthyofspecialattention.

Formodelswithstatedenginehorsepower,thegross

horsepoweroftheenginewaslaboratoryratedbythe

enginemanufacturerinaccordancewithSAEJ1940.

Asconguredtomeetsafety,emission,andoperating

requirements,theactualenginehorsepoweronthisclass

oflawnmowerwillbesignicantlylower.

Donottamperwiththeenginecontrolsoralterthe

governorspeed;doingsomaycreateanunsafecondition

resultinginpersonalinjury.

Safety

Improperlyusingormaintainingthismowercan

resultininjury.Toreducethepotentialforinjury,

complywiththesesafetyinstructions.

Torodesignedandtestedthismowerforreasonablysafe

service;however,failuretocomplywiththefollowing

instructionsmayresultinpersonalinjury.

Toensuremaximumsafety,bestperformance,and

togainknowledgeoftheproduct,itisessential

thatyouandanyotheroperatorofthemowerread

andunderstandthecontentsofthismanualbefore

theengineiseverstarted.Payparticularattention

tothesafetyalertsymbol(Figure2)whichmeans

Caution,Warning,orDanger—“personalsafety

instruction.”Readandunderstandtheinstruction

becauseithastodowithsafety.Failuretocomply

withtheinstructionmayresultinpersonalinjury.

GeneralLawnMowerSafety

ThefollowinginstructionshavebeenadaptedfromEN

836.

Thiscuttingmachineiscapableofamputatinghands

andfeetandthrowingobjects.Failuretoobservethe

followingsafetyinstructionscouldresultinserious

injuryordeath.

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.Toro.com.OriginalInstructions(EN)

PrintedintheUSA

AllRightsReserved

Training

•Readtheinstructionscarefully.Befamiliarwiththe

controlsandtheproperuseoftheequipment.

•Neverallowchildrenorpeopleunfamiliarwiththese

instructionstousethemower.Localregulationscan

restricttheageoftheoperator.

•Keepinmindthattheoperatororuserisresponsible

foraccidentsorhazardsoccurringtootherpeopleor

theirproperty.

•Understandexplanationsforallpictogramsusedon

themowerorintheinstructions.

Gasoline

WARNING-Gasolineishighlyammable.Takethe

followingprecautions.

•Storefuelincontainersspecicallydesignedforthis

purpose.

•Refueloutdoorsonlyanddonotsmokewhile

refueling.

•Addfuelbeforestartingtheengine.Neverremove

thecapofthefueltankoraddgasolinewhilethe

engineisrunningorwhentheengineishot.

•Ifgasolineisspilled,donotattempttostartthe

enginebutmovethemowerawayfromtheareaof

spillageandavoidcreatinganysourceofignition

untilgasolinevaporshavedissipated.

•Replaceallfueltankandcontainercapssecurely.

Preparation

•Whilemowing,alwayswearsubstantialfootwearand

longtrousers.Donotoperatetheequipmentwhen

barefootorwearingopensandals.

•Thoroughlyinspecttheareawheretheequipmentis

tobeusedandremoveallstones,sticks,wires,bones

andotherforeignobjects.

•Beforeusing,alwaysvisuallyinspecttoseethat

guards,andsafetydevices,suchasdeectorsand/or

grasscatchers,areinplaceandworkingcorrectly.

•Beforeusing,alwaysvisuallyinspecttoseethatthe

blades,bladeboltsandcutterassemblyarenotworn

ordamaged.Replacewornordamagedbladesand

boltsinsetstopreservebalance.

Starting

•Disengageallbladeanddriveclutchesandshiftinto

neutralbeforestartingtheengine.

•Donottiltmowerwhenstartingtheengineor

switchingonthemotor,unlessthemowerhastobe

tiltedforstarting.Inthiscase,donottiltitmorethan

absolutelynecessaryandliftonlythepart,whichis

awayfromtheoperator.

•Starttheengineorswitchonthemotorcarefully

accordingtoinstructionsandwithfeetwellaway

fromtheblade(s)andnotinfrontofthedischarge

chute.

Operation

•Nevermowwhilepeople,especiallychildren,orpets

arenearby.

•Mowonlyindaylightoringoodarticiallight.

•Stayalertforholesintheterrainandotherhidden

hazards.

•Donotputhandsorfeetnearorunderrotatingparts.

Keepclearofthedischargeopeningatalltimes.

•Neverpickuporcarryalawnmowerwhilethe

engineisrunning.

•Useextremecautionwhenreversingorpullinga

pedestriancontrolledlawnmowertowardsyou.

•Walk,neverrun.

•Slopes:

–Donotmowexcessivelysteepslopes.

–Exerciseextremecautionwhenonslopes.

–Mowacrossthefaceofslopes,neverupand

downandexerciseextremecautionwhen

changingdirectiononslopes.

–Alwaysbesureofyourfootingonslopes.

•Uselowthrottlesettingswhenengagingthe

traction-clutch,especiallyinhighgears.Reduce

speedonslopesandinsharpturnstoprevent

overturningorlossofcontrol.

•Stopthebladeifthelawnmowerhastobetiltedfor

transportationwhencrossingsurfacesotherthan

grassandwhentransportingthelawnmowertoand

fromtheareatobemowed.

•Donotoperatetheengineinaconnedspacewhere

dangerouscarbonmonoxidefumescancollect.

•Stoptheengine

–wheneveryouleavethelawnmower.

–beforerefueling.

–beforeremovingthegrasscatcher.

–beforemakingheightadjustmentunless

adjustmentcanbemadefromtheoperator’s

position.

•Stoptheengineanddisconnectthespark-plugwire.

–beforeclearingblockagesoruncloggingchute.

–beforechecking,cleaningorworkingonthelawn

mower.

–afterstrikingaforeignobject,inspectthelawn

mowerfordamageandmakerepairsbefore

restartingandoperatingthelawnmower.

–iflawnmowerstartstovibrateabnormally(check

immediately).

•Watchoutfortrafcwhencrossingornearroadways.

MaintenanceandStorage

•Keepallnuts,boltsandscrewstighttobesurethe

equipmentisinsafeworkingcondition.

•Donotusepressurecleaningequipmentonmachine.

•Neverstoretheequipmentwithgasolineinthetank

andinsideabuildingwherefumescanreachanopen

ameorspark.

•Allowtheenginetocoolbeforestoringinany

enclosure.

•Toreducetherehazard,keeptheengine,silencer,

batterycompartmentandgasolinestoragearefreeof

grass,leaves,orexcessivegrease.

•Checkgrasscatchercomponentsandthedischarge

guardfrequentlyandreplacewithmanufacturer’s

recommendedparts,whennecessary.

•Replacewornordamagedpartsforsafety.

•Replacefaultysilencers.

•Ifthefueltankhastobedrained,dothisout-doors.

•Donotchangetheenginegovernorsettingsor

overspeedtheengine.Operatinganengineat

excessivespeedcanincreasethehazardofpersonal

injury.

•Onmultibladedlawnmowers,takecareasrotating

oneblademaycauseotherstorotate.

•Becarefulduringadjustmentofthelawnmowerto

prevententrapmentofthengersbetweenmoving

bladesandxedpartsofthelawnmower.

•Toensurethebestperformanceandsafety,

purchaseonlygenuineTororeplacementparts

andaccessories.Donotuse

will t

partsand

accessories;theymaycauseasafetyhazard.

SoundPressure

Thisunithasamaximumsoundpressurelevelatthe

operator’searof87dBA,basedonmeasurementsof

identicalmachinesperEN836andISO11201.

SoundPower

Thisunithasaguaranteedsoundpowerlevelof98dBA,

basedonmeasurementsofidenticalmachinesperISO

11094.

Vibration,Hand/arm

Thisunitdoesnotexceedahand/armvibrationlevelof

3.5m/s2,basedonmeasurementsofidenticalmachines

perEN836andEN1033.

SafetyandInstructional

Decals

Important:Safetyandinstructiondecalsare

locatednearareasofpotentialdanger.Replace

damageddecals.

112-8760

1.Thrownobjecthazard—keepbystandersasafedistance

fromthemachine.

2.Cutting/dismembermentofhandorfoot—stayawayfrom

movingparts.

117-4143

1.Warning—readtheOperator’sManual.

2.Thrownobjecthazard—keepbystandersasafedistance

fromthemachine.

3.Cutting/dismembermenthazardofhandorfoot,mower

blade—disconnectthesparkplugwireandreadthe

instructionsbeforeservicingorperformingmaintenance.

4.Cutting/dismembermenthazardofhandorfoot,mower

blade—stayawayfrommovingpartsandkeepallguards

andshieldsinplace.

5.Cutting/dismembermenthazardofhandorfoot,mower

blade—donotmowupanddownslopes,onlymowacross;

stopthemowerandengine,pickupdebrisbeforeoperating;

lookbehindanddownwhenreversing.

Setup

Important:Removeanddiscardtheprotective

plasticsheetthatcoverstheengine.

1.UnfoldingtheHandle

Procedure

Foldingorunfoldingthehandleimproperlycan

damagethecables,causinganunsafeoperating

condition.

•Donotdamagethecableswhenfoldingor

unfoldingthehandle.

•Ifacableisdamaged,contactanAuthorized

ServiceDealer.

1.Removethehandleknobsfromthemowerhousing

(Figure3).

Important:Routethecablestotheoutsideof

thehandleasyouinstallthehandle.

Figure3

1.Handleknob(2)

2.Movethehandletotheoperatingposition.

3.Installandtightenthehandleknobsthatyou

removedinstep1(Figure3).

2.FillingtheEnginewithOil

Procedure

Yourmowerdoesnotcomewithoilintheengine,butit

doescomewithabottleofoil.

1.Removethedipstick(Figure4).

Figure4

2.Slowlypouroilintotheoillltubeuntiltheoillevel

reachestheFulllineonthedipstick(Figure4).Do

notoverll.(Max.ll:20oz.(0.59l),type:SAE30

detergentoilwithanAPIserviceclassicationofSF,

SG,SH,SJ,SL,orhigher.)

Note:Ifyouoverlltheengine,poursomeoilout

ofitasdirectedinChangingtheEngineOil.

3.Installthedipsticksecurely.

Important:

Change the engine oil after the r st

5 operating hour s

;changeityearlythereafter.

RefertoChangingtheEngineOil.

ProductOverview

Figure5

1.Sparkplug6.Bladecontrolbar

2.Airlter7.Self-propeldrivebar

3.Fueltankcap8.Grassbag

4.Oilll/Dipstick9.Cuttingheightlevers(4)

5.Recoilstarthandle

Figure6

1.Reardischargedeector

Operation

Attachments/Accessories

AselectionofToroapprovedattachmentsand

accessoriesareavailableforusewiththemachineto

enhanceandexpanditscapabilities.Contactyour

AuthorizedServiceDealerorDistributororgoto

www.Toro.comforalistofallapprovedattachments

andaccessories.

FillingtheFuelTank

Gasolineisextremelyammableandexplosive.

Areorexplosionfromgasolinecanburnyou

andothers.

•Topreventastaticchargefromignitingthe

gasoline,placethecontainerand/ormower

directlyonthegroundbeforelling,notina

vehicleoronanobject.

•Fillthetankoutdoorswhentheengineis

cold.Wipeupspills.

•Donothandlegasolinewhensmokingor

aroundanopenameorsparks.

•Storegasolineinanapprovedfuelcontainer,

outofthereachofchildren.

Fillthefueltankwithfreshunleadedregulargasoline

fromamajorname-brandservicestation(Figure7).

Important:Toreducestartingproblems,add

fuelstabilizertothefuelallseason,mixingitwith

gasolinelessthan30daysold.

Figure7

CheckingtheEngineOilLevel

ServiceInterval:Beforeeachuseordaily

1.Removethedipstick,wipeitclean,andfullyinstall

thedipstick(Figure8).

Figure8

2.Removethedipstickandchecktheoillevel

(Figure8).IftheoillevelisbelowtheAddmarkon

thedipstick,slowlypouroilintotheoillltubeto

raisetheoilleveltotheFullmarkonthedipstick.

Donotoverll.(Max.ll:20oz.(0.59l),type:SAE

30detergentoilwithanAPIserviceclassicationof

SF,SG,SH,SJ,SL,orhigher.)

Note:Ifyouoverlltheengine,poursomeoilout

ofitasdirectedinChangingtheEngineOil.

3.Installthedipstick.

AdjustingtheCuttingHeight

Adjustingthecuttingheightmaybringyouinto

contactwiththemovingblade,causingserious

injury.

•Stoptheengineandwaitforallmovingparts

tostop.

•Donotputyourngersunderthehousing

whenadjustingthecuttingheight.

Iftheenginehasbeenrunning,themuferwill

behotandcanseverelyburnyou.Keepaway

fromthehotmufer.

Adjustthecuttingheightasdesired.Setallfourwheels

tothesameheight.

Note:Toraisethemower,moveallthecuttingheight

leversforward;tolowerthemower,movetheallthe

cuttingheightleversrearward(Figure9).

Figure9

1.Raisethemower2.Lowerthemower

Note:Thecuttingheightsettingsare1inch(25mm);

1-1/2inch(38mm);2inches(51mm);2-1/2inches

(64mm);3inches(76mm);3-1/2inches(89mm);and

4inches(102mm).

StartingtheEngine

1.Holdthebladecontrolbar(Figure10)againstthe

handle.

Figure10

1.Bladecontrolbar

2.Pullrecoilstarthandle(Figure11).

Figure11

Note:Ifthemowerdoesnotstartafterseveral

attempts,contactanAuthorizedServiceDealer.

UsingtheSelf-propelDrive

Tooperatetheself-propeldrive,squeezetheself-propel

drivebar(Figure12)towardthehandleandholdit.

Figure12

1.Self-propeldrivebar

Todisengagetheself-propeldrive,releasetheself-propel

drivebar.

Note:Themaximumself-propelgroundspeedisxed.

Toreducethegroundspeed,increasethespacebetween

theself-propeldrivebarandthehandle.

StoppingtheEngine

ServiceInterval:Beforeeachuseordaily

Tostoptheengine,releasethebladecontrolbar

(Figure13).

Important:Whenyoureleasethebladecontrol

bar,boththeengineandbladeshouldstopwithin

3seconds.Iftheydonotstopproperly,stopusing

yourmowerimmediatelyandcontactanAuthorized

ServiceDealer.

Figure13

MulchingtheClippings

Yourmowercomesfromthefactoryreadytomulchthe

grassandleafclippingsbackintothelawn.

Ifthegrassbagisonthemower,removeit(referto

RemovingtheGrassBag)beforemulchingtheclippings.

BaggingtheClippings

Usethegrassbagwhenyouwanttocollectgrassand

leafclippingsfromthelawn.

Aworngrassbagcouldallowsmallstones

andothersimilardebristobethrowninthe

operator’sorbystander’sdirectionandresultin

seriouspersonalinjuryordeathtotheoperator

orbystanders.

Checkthegrassbagfrequently.Ifitis

damaged,installanewTororeplacementbag.

Thebladeissharp;contactingthebladecan

resultinseriouspersonalinjury.

Stoptheengineandwaitforallmovingpartsto

stopbeforeleavingtheoperatingposition.

InstallingtheGrassBag

1.Liftupthereardeector(Figure14).

Figure14

1.Reardeector

2.Insertthegrassbaghandleontothenotchesonthe

handlebrackets(Figure14).

RemovingtheGrassBag

1.Liftupthereardeector(Figure14).

2.Liftthegrassbaghandleoutfromthenotchesonthe

handlebracketsandremovethebagfromthemower.

3.Closethereardeector.

DischargingtheClippings

Usetherear-dischargedeectorforcuttingverytall

grass.

InstallingtheRear-DischargeDeector

1.Ifthebagisonthemower,removeit.

2.Liftupthereardeectorandholdit(Figure15).

Figure15

3.Insertthetabontherear-dischargedeectorintothe

right-handslotinthereardeector(Figure16).

Figure16

4.Inserttherodontherear-dischargedeectorinto

thenotchesonthemower(Figure17).

Figure17

RemovingtheRear-DischargeDeector

Toremovetherear-dischargedeector,reversethesteps

above.

OperatingTips

GeneralMowingTips

•Cleartheareaofsticks,stones,wire,branches,and

otherdebristhatthebladecouldhit.

•Avoidstrikingsolidobjectswiththeblade.Never

deliberatelymowoveranyobject.

•Ifthemowerstrikesanobjectorstartstovibrate,

immediatelystoptheengine,disconnectthewire

fromthesparkplug,andexaminethemowerfor

damage.

•Forbestperformance,installanewbladebeforethe

cuttingseasonbegins.

•ReplacethebladewhennecessarywithaToro

replacementblade.

CuttingGrass

•Cutonlyaboutathirdofthegrassbladeatatime.

Donotcutbelowthe2inch(51mm)settingunless

thegrassissparseoritislatefallwhengrassgrowth

beginstoslowdown.RefertoAdjustingtheCutting

Height.

•Whencuttinggrassover6inches(15cm)tall,mow

atthehighestcuttingheightsettingandwalkslower;

thenmowagainatalowersettingforthebestlawn

appearance.Ifthegrassistoolong,themowermay

plugandcausetheenginetostall.

•Mowonlydrygrassorleaves.Wetgrassandleaves

tendtoclumpontheyardandcancausethemower

toplugortheenginetostall.

Wetgrassorleavescancauseseriousinjuryif

youslipandcontacttheblade.Mowonlyindry

conditions.

•Alternatethemowingdirection.Thishelpsdisperse

theclippingsoverthelawnforevenfertilization.

•Ifthenishedlawnappearanceisunsatisfactory,try

oneormoreofthefollowing:

–Replacethebladeorhaveitsharpened.

–Walkataslowerpacewhilemowing.

–Raisethecuttingheightonyourmower.

–Cutthegrassmorefrequently.

–Overlapcuttingswathsinsteadofcuttingafull

swathwitheachpass.

–Setthecuttingheightonthefrontwheelsone

notchlowerthantherearwheels.Forexample,

setthefrontwheelsat2inches(51mm)andthe

rearwheelsat2-1/2inches(64mm).

CuttingLeaves

•Aftercuttingthelawn,ensurethathalfofthelawn

showsthroughthecutleafcover.Youmayneedto

makemorethanonepassovertheleaves.

•Iftherearemorethan5inches(13cm)ofleaves

onthelawn,setthefrontcuttingheightoneortwo

notcheshigherthantherearcuttingheight.

•Slowdownyourmowingspeedifthemowerdoes

notcuttheleavesnelyenough.

Maintenance

Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.

RecommendedMaintenanceSchedule(s)

MaintenanceService

IntervalMaintenanceProcedure

Aftertherst5hours•Changetheengineoil.

Beforeeachuseordaily

•Checktheengineoillevel.

•Ensurethattheenginestopswithin3secondsafterreleasingthebladecontrolbar.

•Cleangrassclippingsanddirtfromunderthemower.

Every25hours•Replacetheairlter;replaceitmorefrequentlyindustyoperatingconditions.

Beforestorage•Emptythefueltankbeforerepairsasdirectedandbeforeannualstorage.

Yearly

•Changetheengineoil.

•Replacethebladeorhaveitsharpened(morefrequentlyiftheedgedullsquickly).

•RefertoyourEngineOperator’sManualforanyadditionalyearlymaintenance

procedures.

Important:Refertoyour

Engine Operator’ s Man ual

foradditionalmaintenanceprocedures.

PreparingforMaintenance

1.Stoptheengineandwaitforallmovingpartstostop.

2.Disconnectthesparkplugwirefromthesparkplug

(Figure18)beforeperforminganymaintenance

procedure.

Figure18

1.Sparkplugwire

3.Afterperformingthemaintenanceprocedure(s),

connectthesparkplugwiretothesparkplug.

Important:Beforetippingthemowertochange

theoilorreplacetheblade,allowthefueltank

torundrythroughnormalusage.Ifyoumust

tipthemowerpriortorunningoutoffuel,usea

handfuelpumptoremovethefuel.Alwaystip

themowerontoitssidewiththedipstickdown.

Tippingthemowermaycausethefueltoleak.

Gasolineisammable,explosiveandcancause

personalinjury.

Runtheenginedryorremovethegasolinewith

ahandpump;neversiphon.

ReplacingtheAirFilter

ServiceInterval:Every25hours

1.Useascrewdrivertoopentheairltercover

(Figure19).

Figure19

2.Replacetheairlter(Figure20).

Autres manuels pour 29641

Table des matières

Langues :

Autres manuels Toro Tondeuse à gazon

Toro

Toro 20959 Manuel utilisateur

Toro

Toro Titan MR 6000 Manuel utilisateur

Toro

Toro 74723 Manuel utilisateur

Toro

Toro TITAN 121-5680 Manuel utilisateur

Toro

Toro 4613 Manuel utilisateur

Toro

Toro Reelmaster 7000-D Manuel utilisateur

Toro

Toro TimeMaster 21199 Manuel utilisateur

Toro

Toro Flex-Force Power System 21356T Manuel utilisateur

Toro

Toro Recycler 21030 Manuel utilisateur

Toro

Toro Proline 30299TE Manuel utilisateur

Toro

Toro 74219 Manuel utilisateur

Toro

Toro 74176 Manuel utilisateur

Toro

Toro 74906 Manuel utilisateur

Toro

Toro REELMASTER 4500-D Manuel utilisateur

Toro

Toro Greensmaster Flex 1800 Manuel utilisateur

Toro

Toro Z Master Professional 5000 Series Manuel utilisateur

Toro

Toro TimeMaster Series Manuel utilisateur

Toro

Toro Groundsmaster 4010 Manuel utilisateur

Toro

Toro TITAN ZX 4800 Manuel utilisateur

Toro

Toro Recycler 20954 Manuel utilisateur

Toro

Toro 72098 Manuel utilisateur

Toro

Toro TITAN ZX 4800 Manuel utilisateur

Toro

Toro 22177 Manuel utilisateur

Toro

Toro TimeCutter MX5060 Manuel utilisateur

Manuels Tondeuse à gazon populaires d'autres marques

RHINO

RHINO 1958 Manuel utilisateur

Wolf Garten

Wolf Garten Compact plus 40 B Manuel utilisateur

Cub Cadet

Cub Cadet LTX 1045 Manuel utilisateur

Craftsman

Craftsman 917.378461 Manuel utilisateur

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Manuel utilisateur

Challenge

Challenge CH18V2 Instructions de fonctionnement

TALEN TOOLS

TALEN TOOLS AVR HGM30 Manuel utilisateur

DEWEZE

DEWEZE ATM-725 Manuel d'utilisation

Weed Eater

Weed Eater 180083 Manuel utilisateur

Husqvarna

Husqvarna Poulan Pro PP185A42 Manuel utilisateur

Better Outdoor Products

Better Outdoor Products Quick Series Manuel utilisateur

Cub Cadet

Cub Cadet 23HP Z-Force 60 Manuel d'utilisation

MTD

MTD 795, 792, 791, 790 Manuel utilisateur

Dennis

Dennis FT 610 Manuel utilisateur

AIRFORCE

AIRFORCE F-15 Gen 3 Manuel utilisateur

MTD

MTD 126-220-000 Manuel utilisateur

Stihl

Stihl RMA 443 PV Manuel utilisateur

Yard-Man

Yard-Man 3700-0 Manuel utilisateur
