Toro 117-9449 Manuel utilisateur

FormNo.3363-186RevB

CEKit

2010andAfterGroundsmaster®5900/5910TractionUnit

ModelNo.117-9449

InstallationInstructions

InstalltheHoodLatch

Partsneededforthisprocedure:

1LatchKey

1Latch

1LatchBracket

3CarriageScrew

3FlangeNut

Procedure

1.Parkthemachineonalevelsurface,lowerthedecks,

engagetheparkingbrakeandturntheengineoff.

Removethekeyfromtheignitionswitch.

2.Unlatchandraisethehood.

3.Removetheplugfromthesquareholeintheright

sideofthehood.Discardtheplug.

4.Removethelockingnutfromthelatchassembly

(Figure1).

5.Installthelockinglatchthroughthesquareholein

therightsideofthehood(Figure1).Thecatch

mustbepositionedinsidethehoodandpointing

downward.

Figure1

1.Latchkey4.Carriagescrew

2.Latch5.Flangenut

3.Latchbracket

6.Installthelockingnutontothelatchtosecureitto

thehood.

7.Locatethe(3)holesintherightsideoftheradiator

support(Figure1).Mountthelatchbrackettothe

radiatorsupportwith(3)carriagescrewsandange

nuts.PositionthelatchbracketasshowninFigure1.

8.Closethehoodslowlytoseeiflatchcatches.If

itdoesnot,loosenthescrewssecuringthelatch

brackettotheradiatorsupportandadjustthebracket

asnecessary.Tightenthescrewsandverifythelatch

catches.

9.Usethekeytolock/unlocklatch.Storethekeyina

convenientandmemorableplace.

InstalltheSidePanelHardware

Partsneededforthisprocedure:

4Screw(5/16x3/4inch)

4Pushnut(5/16inch)

1Hexnut(5/16inch)Forassemblingpushnutonly

Procedure

1.Removetheexistinghardwaresecuringtheside

paneltothemachineanddiscard(Figure2).Remove

thesidepanel.

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.Toro.com.OriginalInstructions(EN)

PrintedintheUSA.

AllRightsReserved

g011939

Figure2

1.Hood3.Screw(5/16x3/4inch)

2.Sidepanel

2.Installthescrew(5/16x3/4inch)tothesidepanel

andturnovertoinstallthepushnutontothebolt

(Figure3).

g011940

123

Figure3

1.Retainedfastener3.Machine

2.Sidepanel

3.Installthehexnut(5/16inch)overthescrewand

pushnut(5/16inch)andtightentoattenthepush

nutontoscrew(Figure3).

4.Removethehexnutandrepeattheactiononto

attenallremainingpushnutsonthesidepanel.

Removethehexnutwhennishedanddiscard.

Installthesidepanelwiththeretainedfastenerto

themachine(Figure4).

123

g011941

Figure4

Important:Thefastenersonthecoversofthis

machinearedesignedtoremainonthecover

afterremoval.Loosenallofthefastenerson

eachcoverafewturnssothatthecoverisloose

butstillattached,thengobackandloosenthem

untilthecovercomesfree.Thiswillpreventyou

fromaccidentallystrippingtheboltsfreeofthe

retainers.

InstalltheSpeedLimiter

Partsneededforthisprocedure:

1Spacerplate

1Stopplate

2Plasticplug

Procedure

1.Carefullypuncturethedecalmaterialonthe

consolepaneltoexposetheexistingholesinfront

oftheenginespeedselectorandenginespeed

increment/decrementswitches(Figure5).

Figure5

1.Spacerplate3.Plasticplugs

2.Stopplate

2.Positionthespacerplateontotheconsolepanelso

theholesalignwiththeholesintheconsoleandthe

back(straight)edgeofthespacerplatealignswith

theswitchbase(Figure5).

Note:Donotinstalltheplasticplugsuntilthe

spacerandstopplatesarepositionedunderthe

switches.

3.Whilealigningthemountingholes,positionthestop

plateontothespacerplate.Thestopplateshouldbe

positionedundertheswitches(Figure5).

4.Securetheplatestotheconsolewiththeplasticplugs

(Figure5).

AdjusttheCuttingDeck

PositionSwitches

NoPartsRequired

Procedure

1.Parkthemachineonahardlevelsurfaceandengage

theparkingbrake.

2.Raiseallthreedeckssothattheoutermost(highest)

cuttingbladetipcircleofeachdeckisnohigherthan

36cmabovetheoor.Placeajackstandunder

eachdecktopreventthemfromfallingiftheyare

accidentallylowered.

3.Turntheengineoff.

4.Toadjustthewingdeckswitch,proceedasfollows;

A.Loosenthefastenerssecuringthesensorplateto

theliftarm(Figure6).

Figure6

1.Sensorplatemounting

fasteners

3.Positionswitch

2.Sensorplate

B.TurntheignitionkeytotheRUNposition.

Important:Thedeckswilllowerifthelift

switchisactuatedwhentheoperatorisin

theseatandtheignitionkeyisintheRUN

position.

C.WhileusingtheHigh/LowRangediagnostic

screenontheInfoCenter,rotatethesensor

platejustuntiltheappropriaterightorleft

DeckDowninputreadsOFF.Refertothe

Groundsmaster5900ServiceManualfor

informationonInfoCenteroperation.

Thisisthepointintheraisesequenceofthedeck

wherethedeckpositionswitchwillshutoffthe

deckmotor.

D.Tightenthesensorplatemountingfasteners.

E.Repeattheprocedureontheotherwingdeck

switch.

5.Toadjustthefrontdeckswitch,proceedasfollows;

A.Loosenthefastenerssecuringtheswitchbracket

totheframe(Figure7).

Figure7

1.Positionswitchmounting

fasteners

3.Positionswitch

2.Positionswitchmounting

bracket

4.Sensorplate

B.TurntheignitionkeytotheRUNposition.

Important:Thedeckswilllowerifthelift

switchisactuatedwhentheoperatorisin

theseatandtheignitionkeyisintheRUN

position.

C.WhileusingtheHigh/LowRangediagnostic

screenontheInfoCenter,movetheposition

switchbracketjustuntilthefrontDeckDown

inputreadsOFF .RefertotheGroundsmaster

5900ServiceManualforinformationon

InfoCenteroperation.

Thisisthepointintheraisesequenceofthedeck

wherethedeckpositionswitchwillshutoffthe

deckmotor.

D.Tightentheswitchbracketmountingfasteners.

Gapbetweensensingplateandswitchtarget

shouldbemaintainedat0.100inches(+/-0.030

inches).

Note:Theuseofsafetyglassesisrecommended

duringthenextstep.

6.Operatingeachdeckindividually,verifythecorrect

operationoftheswitchbyraisingthedeckwith

thePTOengagedandobservingthattheblade

disengagesbeforetheouterbladetipofthedeck

exceeds39cm.

InstallBeltCoverHardware

Partsneededforthisprocedure:

11Thrustwasher

11Pushnut(5/16inch)

Procedure

1.Removetheboltsecuringthebeltcovertothedeck

andremovethebeltcovers.

2.Installtheexistingboltintothededicatedholeinthe

beltcover.Installthethrustwasherandpushnut

fromunderneathtotheexistingbolttoretainitto

thebeltcoverasshowninFigure8.

g011942

Figure8

1.Bolt(existing)3.Pushnut(5/16inch)

2.Thrustwasher

3.Installthebeltcovertothedeck.Usetheretained

bolttosecureittothedeck.

4.Repeatforallthebeltcoverhardware.

InstalltheDecals

Partsneededforthisprocedure:

1CEComplianceDecal

1CEWarningDecal

1ProductionYearDecal(includedintractionunitloose

parts)

Procedure

1.Thoroughlycleantheareawhereyouwillinstallthe

decal(Figure9).

G009446

Figure9

1.CEcompliancedecal(Part

No.117–2761)

3.CEWarningdecal(Part

No.117–2766,applyover

existingdecal)

2.Productionyeardecal

(includedintractionunit

looseparts)

2.Dampentheareawithwaterormildlysoapywater.

3.Peelthebackingfromthedecalsandinstallthe

decalsatthelocationsshowninFigure9.

4.Squeegeeacrossthesurfaceofeachdecal,starting

atthecenterandworkingtowardtheedges,using

overlappingstrokes.

Notes:
