Pro Spotter
Operations and Maintenance Manual
For Commercial Use Only
Model No. TE011-G03-U
NOTES
Getting Started
Introduction............................................................................................................1
Warranty.................................................................................................................2
Grounding Instructions..........................................................................................3
Important Safety Instructions................................................................................4
TechnicalSpecifications........................................................................................6
Operating Instructions
Key Features..........................................................................................................7
Operation...............................................................................................................7
Transport and Storage.........................................................................................12
Maintenance.........................................................................................................13
Troubleshooting...................................................................................................14
CONTENTS
1
INTRODUCTION
Your new Tornado unit is a high quality, precision-made product. All parts used
in the manufacturing of this unit have passed rigid quality control standards
prior to assembly. Please safeguard the original receipt/invoice given at the time
of purchase. If you experience any problems with your unit during the warranty
period, the original receipt/invoice will act as proof of purchase.
Upon receipt, inspect outer box for exterior damage. Unpack all internal
parts, ensure no hidden damage is found.
Each unit is tested and thoroughly inspected prior to shipping. If damage is
discovered, immediately notify the transportation company that delivered your
machine and request an inspection. As a manufacturer, we are unable to act upon
any claim for concealed damage and you must originate the claim. Be sure
to keep the carton, packing inserts, and carrier’s receipt until the inspector has
verified your claim.
Protect the environment
Please dispose of packaging
materials in an environmentally
safe way according to local waste
disposal regulations.
Always remember to recycle.
2
For warranty information go to www.
tornadovac.com
Within 30 days, to activate the warranty, go to;
https://tornadovac.com/services/warranty-registration-
form.aspx
Prior to operating the this unit, read and understand completely this
owner’s manual paying special attention to warning labels. These labels
indicate a potentially hazardous situation that could result in death or
serious injury if not avoided. Use only as described in this manual.
There are no owner serviceable parts inside this machine. Removal of
screws and accessing internal components will void all warranty claims.
Personal Protection Equipment (PPE) should be worn during the operation
of this machine. Chemicals can remain airborne for some time after
application and therefore safety glasses and masks are recommended.
Gloves should be worn any time chemicals are handled.
WARRANTY
3
This appliance must be grounded. If it should electrically malfunction, grounding
provides a path of least resistance for the current to reduce the risk of electric
shock. This machine is equipped with a cord having an equipment grounding
conductor and grounding plug. The plug must be inserted into an appropriate
outlet that is properly installed and grounded in accordance with all local codes
and ordinances.
Improper connection of the equipment grounding conductor
can result in a risk of electric shock. Check with a qualified
electrician or service person if you are in doubt as to whether
the outlet is properly grounded. Do not modify the plug
provided with the appliance. If the plug will not fit the outlet,
have the proper outlet installed by a qualified electrician. DO
NOT REMOVE THE GROUNDING PIN FOR ANY REASON.
This appliance is for use on a nominal 115-volt circuit and has a grounding plug
that appears as shown below.
GROUNDING INSTRUCTION
4
Your new Tornado unit is a high quality, precision-made product. All parts used in the manufacturing
of this unit have passed rigid quality control standards prior to assembly. Please safeguard the original
receipt / invoice. If you experience any problems with your unit during the warranty period, the original
receipt / invoice will act as proof of purchase. Contact Tornado for any warranty inquiries.
IMPORTANT SAFETY INSTRUCTIONS
READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE USING THIS UNIT
Read and understand this owner’s manual and all labels on the unit before operating. Safety is a
combination of common sense,staying alert and knowing how your unit works. Use this unit only as
described in this manual. Use only manufacturer’s recommended attachments. To reduce the risk of
personal injury or damage to your unit use only Tornado recommended accessories.
WARNING To avoid fire, DO NOT use with a flammable or combustible liquid or floor cleaner.
WARNING To avoid electric shock, DO NOT expose to rain. Store Indoors.
To reduce risk of fire, electric shock, or injury:
• Do not use outdoors or on wet surfaces.
• Do not leave unit unattended when plugged in. Turn off the switch and unplug the electrical cord
when not in use and before servicing.
• Do not allow to be used as a toy. Close attention is necessary when used near children.
• Use only as described in this manual. Use only manufacturer’s recommended attachments.
• Do not use with damaged cord or plug. If unit is not working as it should, has been dropped,
damaged, left outdoors, or dropped into water, return it to a service center before using.
• Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull a cord around sharp
edges or corners. Do not run the unit over cord. Keep cord away from heated surfaces.
• Do not use extension cords or outlets with inadequate current carrying capacity.
• Turn off all controls before unplugging.
• Do not handle plug or unit with wet hands.
• Do not put any objects into openings. Do not use with any opening blocked, keep free of dust, lint,
hair, and anything that may reduce airflow.
• Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts.
• Do not pick up anything that is burning or smoking, such as cigarettes, matches or hot ashes.
• Use extra care when cleaning on stairs. Do not use to pick up flammable or combustible liquids such
as gasoline, or use in areas where they may be present.
• Store your unit indoors in a cool, dry area.
• Do not unplug by pulling on cord. To unplug, grasp the plug, NOT THE CORD.
• Follow these guidelines to ensure operator safety and to maintain equipment in running order.
• Make sure the machine is plugged into an electrical outlet with the same voltage rating as shown on
the nameplate of the machine.
• Do not attempt to plug a 115 volt machine into a 230 volt outlet or a 230 volt machine into a 115 outlet.
• Replace a damaged cord immediately.
• If an extension cord is necessary, use a three conductor grounding cord-12 gauge wire or heavier to
prevent motor burnout and over-heating of wires
• Do not expose the machine to freezing temperatures.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
IMPORTANT SAFETY INSTRUCTIONS
5
Flammability Warning
NEVER fill unit with flammable chemicals. Do NOT use in an area where
flammable fumes are present
State of California Proposition 65 Warnings
WARNING: This product contains one or more chemicals known to the state
of California to cause cancer.
WARNING: This product contains one or more chemicals known to the state
of California to cause birth defects or other reproductive harm.
Chemical Warning
Straight bleach should never be used solely in this unit. When sodium
hypochlorite, a component found in bleach, dissolves in water, two
substances form which play a role in both disinfection and oxidation.
Manufacturer’s recommendations must be followed for the chemical being
used to ensure the proper balance is achieved that will disinfect and not
oxidize the metal components found in this machine. It is recommended
to flush the entire system thoroughly with clean water after use and prior to
storage. Store unit dry and empty for prolonged periods following a system
flush. Use only water-based chemicals to clean machine.
Intended Use
Do NOT modify this unit in any way or adapt it for any other use. Modification
of this unit in any way will void all warranties and could create safety hazards.
IMPORTANT SAFETY INSTRUCTIONS
6
Model TE011-G03-U
Input Voltage 115 VAC
Plug Type US
Cord 15’ with on-board storage
GPM .05 with Atomizer Nozzle/.25 with fan nozzle/.25 Extraction
Amps Pre Spray Mode 1A/Extraction Mode 8.9A
Solution Tank 3.5 Gal/13.2 l
Recovery Tank 2.5 Gal/9.5 l
Dimensions 23” x 11” x 23” / 58.5cm x 28cm x 58.5 cm
Weight 41 lbs./18.5 kg
Waterlift 89”/226 cm
CFM/CMM 104/3
Solution Pressure 55 p.s.i./3.8 BAR
Pre Spray Hose 35’ with quick disconnect
Pre Spray Wand 18”
*Variance dependent on user application method
TECHNICAL SPECIFICATIONS
7
• Do not break off or pull out the ground prong on the plug.
• Do not attempt to repair a warranted machine unless instructed to do so by an authorized
shop or the factory.
• Do not use any replacement parts except those specified on the parts list. Proper
performance of the machine could be affected if substitutions are made.
• Use defoamer at all times to prevent damaging the vacuum motor.
• Do not use water in excess of 140° F (60° C).
• Failure to comply with the above warning instructions will void the warranty.
When using as an extractor
• Do not use the machine for totally dry vacuuming. This machine is not fitted with a fine dust
filter.
• Do not use citrus-based cleaners in this machine.
• Do not use cleaning chemicals in this machine except those recommended for commercial
extraction equipment.
• The use of any chemical with abrasive additives voids the warranty.
• Use defoamer at all times to prevent damaging the vacuum motor.
• Do not use water in excess of 140° F (60° C).
OPERATION
KEY FEATURES
Vacuum Hose
Attachment
Spray Tip (included
both an atomizer
and fan spray tip)
Wand Hose
Wand
Upholstery Tool
Upholstery
ToolStorage
