Topeak NINJA CO2+ Manuel utilisateur

User's Guide

NINJA CO2

/ NINJA CO2

HOW TO USE MICRO AIRBOOSTER

WARNING

• Accepts all 16g threaded CO2cartridges.

• Recommended to use Topeak 16g threaded CO2cartridges.

• Please read all instructions before ﬁrst use.

• Periodically check that components are still securely

fastened to your bike.

• Compatible with Ninja Cage series.

• If using the Micro AirBooster inﬂator continuously, make sure to wait 20 seconds in between cartridges for the

rubber grommet inside the inﬂation head to return to its original position. Otherwise, a gas leak may occur and

prevent proper inﬂation.

• Tighten the CO2cartridge before using CO2inﬂation function. Failure to do so will cause improper operation and

may cause injury.

• DO NOT remove CO2cartridge if it is still charged with gas. Completely discharge the CO2cartridge before removal.

• When opening the CO2cartridge, point the inﬂator head away from yourself and others.

• DO NOT use Micro AirBooster Inﬂator if any part is cracked or broken.

• DO NOT expose the CO2cartridge to heat, or store at temperatures above 120˚F (49˚C), or store in enclosed vehicles.

• Make sure to wear gloves when inﬂating to avoid injury.

• The barrel and CO2cartridge may become extremely cold/ frosty when the CO2gas is expelled.

• DO NOT try to unscrew the Micro AirBooster inﬂation head until it has warmed suﬀiciently to touch.

• Keep out of reach of children.

Presta Valve

Thread-in CO2cartridge. Loosen valve core before inﬂation.

1 2

Start and regulate CO2ﬂow by pushing

inﬂation head onto valve stem.

Install and thread-in inﬂation head

to Schrader valve.

Schrader Valve

Thread-in CO2cartridge. Start and regulate CO2ﬂow by pushing

inﬂation head onto valve stem.

1 2 3

After each inﬂation, make sure

all CO

gas has been discharged

by pushing the Micro AirBooster

inﬂation head several times.

Micro AirBooster16g Topeak

Threaded CO2

Cartridge x 2

CO2Cartridge

Engagement

Inﬂation Head

To avoid possible personal

injury and damage to bike

and /or tool, ensure to

disengage CO2inﬂator

properly after use by

unthreading inﬂation head

in correct direction.

NOTE

Tire Lever

NINJA CO2+ NINJA CO2

YES NO

Compatible

with Ninja

Cage series.

Unscrew with

T15 tool.

User's Guide

NINJA CO2

/ NINJA CO2

MICRO AIRBOOSTER PARTS REPLACEMENTCO2CARTRIDGE TIRE LEVER

(NINJA CO2+)

SPARE PARTS

2-year Warranty: All mechanical components against

manufacturer defects only.

Warranty Claim Requirements

To obtain warranty service, you must have your original

sales receipt. Items returned without a sales receipt will

assume that the warranty begins on the date of

manufacture. All warranties will be void if the product is

damaged due to user crash, abuse, system alteration,

modiﬁcation, or used in any way not intended as

described in this manual.

* The speciﬁcations and design are subject to change

without notice.

Please contact your Topeak dealer with any questions.

For USA customer service, call: 1-800-250-3068

www.topeak.com

WARRANTY

The valve head o-ring is subject to wear and may

cause air leakage over time. Periodically inspect

and replace o-ring if needed.

16g Threaded CO2cartridge

Art no. TCOT-2 (2 pcs)

TCOT-5 (5 pcs)

O-ring

Replacement Kit

Art no. TRK-HR01

PUSH

RELEASE

RELEASE RELEASE

PUSH

Tire Lever

Art no. TRK-T086

Micro AirBooster

Art no. TMB-1

HOW TO INSTALL ON BIKE WITH OTHER CAGE (NINJA CO2 only)

CAGE

COMPATIBILITY

Ninja CO2 is only

compatible with

cages that have a

distance of 42 mm

or less between

lower mounting

bolt hole centerline

and bottom of

bottle cage

42 mm

INSTALL

T15

NINJA T ROAD

Art no. TNJ-TR

NINJA T MOUNTAIN

Art no. TNJ-TM

NINJA POUCH ROAD

Art no. TNJ-PR
