Topeak DeFender M1 Manuel utilisateur

(Rear)

(Front)

DeFenderM1

Tool required: 4 mm Allen key

RecommendedTorque

2-4 Nm (17-35 in. lbs)

4mm

Allenkey

Press to

install / release

Press to

install / release

Fits ø19.6 - ø26 mm

DeFenderM1fitsmoststandard

frontforks.However,itwillnot

fitforks withacrownthickness

over60mm(2.36")and isnot

designedtobeusedwiththe1.5"

headsetstandard.

Fits ø 27.7~ ø35 mm

User'sGuide

DeFenderM1/M2

Prepare to Ride

CAUTION

WheninstallingDeFenderM1with

suspensionforks,makesurenopartof

theforkcomesincontactwiththe

DeFenderM1during itstravellength.

Otherwisedamagetoyourbikeor

DeFenderM1may occuranditmayalso

causebodilyinjury.

BackviewBackview

DeFenderM1

IMPORTANT NOTES

Fits ø 27.7~ ø35mmFits ø19.6 ~ ø26mm

Wedge

Set

thickness 60mm

M-TC9617-18-GB 11/09

SLIP JOINT CLAMP FITS ø25.4~ø31.2 mm and ø30.8~34.9 mm

WARRANTY

Topeak productsare availableonly fromprofessionalbicycleshops.

Pleasecontactyournearest Topeakauthorizedbicycledealerforanyquestions.Forcustomersinthe USA,call:1-800-250-3068,Website:www.topeak.com

2-yearWarranty:Allmechanicalcomponentsagainstmanufacturerdefectsonly.

WarrantyClaimRequirements

Toobtainwarrantyservice,youmusthaveyouroriginalsalesreceipt.Itemsreturnedwithoutasalesreceiptwillassumethatthewarrantybeginsonthedateofmanufacture.

Allwarrantieswillbevoidiftheproductisdamagedduetousercrash,abuse,systemalteration,modification,orusedinanywaynotintendedas describedinthisoperating

manual.

*Thespecificationsanddesignaresubjecttochangewithoutnotice.

ANGLE ADJUSTMENT

RecommendedTorque:

2-4 N.m (17~35 in. lbs.)

4mm

Allen key 4mm

Allen key

Toothed Nut Angle Adjusting Bolt

ø25,4~ø31,2 mm ø30,8~34,9 mm

Alwayskeepthequickrelease

leverintheproperclosed

positionwhenDeFenderM2

ismountedonbike.

Adjusttheangleof

DeFenderM2by

looseningtheangle

adjustingboltsand

retighteningthe

boltsoncethe

correctangleis

achieved. Donot

loosentheangle

adjustingboltmore

than6

counterclockwise

rotationsorthe

toothednut

assemblywillbe

disassembledand

maybedamaged.

WARNING

DeFenderM2

Tool required: 4 mm Allen key

WARNING

Whenadjustingtheangleof

DeFenderM2, makesurethe

spacebetweenDeFenderM2

andthetireislargerthanwheel

travelofthe bike.Incorrect

anglemaycausedamageto

DeFenderM2, yourbike,or

potentiallycausebodilyharm.

For Rear Suspension Bike

Prepare to Ride

User'sGuide

DeFenderM1/M2
