Topcom Cocoon 95 DUO Manuel utilisateur

COCOON 95

COCOON 95 DUO

HANDLEIDING

MODE D’EMPLOI

USER GUIDE

BEDIENUNGSANLEITUNG

V.1

Coc95_eur.book Page 1 Monday, January 5, 2004 10:07 AM

!! Important !!

To use ‘Caller ID’ (display caller), this service has to be activated on your phone line. Normally you need a

separate subscription from your telephone company to activate this function. If you don’t have the Caller ID

function on your phone line, the incoming telephone numbers will NOT be shown on the display of your

telephone.

!! Belangrijk !!

Om de ‘Nummerweergave’ te kunnen gebruiken, moet deze dienst geactiveerd zijn op uw telefoonlijn. Om

deze dienst te activeren, hebt U hiervoor meestal een apart abonnement van uw telefoonmaatschappij nodig.

Indien U geen nummerweergavefunctie hebt op uw telefoonlijn, zullen de inkomende telefoonnummers NIET

op de display van uw toestel verschijnen.

!! Important !!

Pour utiliser la fonction ‘Caller ID/Clip’ (affichage de l’appelant), ce service doit être activé sur votre ligne

téléphonique. Généralement, vous avez besoin d’un abonnement séparé de votre compagnie de téléphone

pour activer cette fonction. Si vous n’avez pas la fonction ‘Caller ID - Affichage Appelant’ sur votre ligne

téléphonique, les numéros de téléphone entrants n’apparaîtront PAS sur l’écran de votre téléphone.

!! Wichtig!!

Zur Verwendung der ‘Rufnummernanzeige’ muss dieser Dienst erst für Ihre Telefonleitung freigegeben

werden. Zur Aktivierung dieser Dienstleistung benötigen Sie meistens ein separates Abonnement Ihrer

Telefongesellschaft.Wenn Sie für Ihre Telefonleitung keine Rufnummernanzeigefunktion haben, erscheinen

die eingehenden Telefonnummern NICHT im Display Ihres Gerätes.

GB The features described in this manual are published with reservation to modifications.

NL De in deze handleiding beschreven mogelijkheden worden gepubliceerd onder voorbehoud

van wijzigingen.

FLes possibilités décrites dans ce manuel sont publiées sous réserve de modifications.

DDie in dieser Bedienungsanleitung umschriebenen Möglichkeiten, werden vorbehaltlich

Änderungen publiziert.

This product is in compliance with the essential requirements and other relevant provisions of the R&TTE directive 1999/5/EC.

The Declaration of conformity can be found on :

http://www.topcom.net/support/cedeclarations.php

Coc95_eur.book Page 2 Monday, January 5, 2004 10:07 AM

Topcom Cocoon 95 3

Topcom Cocoon 95

ENGLISH

1 BUTTONS 5

1.1 BASE COCOON 95 5

1.2 CHARGER COCOON 95 6

2 INSTALLATION 7

3 BATTERY EMPTY INDICATION 9

4 TELEPHONE OPERATION 9

4.1 OUTGOING CALLS 9

4.2 INCOMING CALLS 9

4.3 LAST NUMBER REDIAL 9

4.4 ROGRAMMING MEMORY NUMBERS 10

4.5 CALLING A MEMORY NUMBER 10

4.6 BABYCALL 10

4.7 MUTE FUNCTION 10

4.8 SETTING THE VOLUME 10

4.9 PAGING 11

4.10 HANDSET LOCK 11

4.11 KEYPAD LOCK 11

4.12 OUT OF RANGE WARNING 11

4.13 FLASH BUTTON (R) 11

4.14 ACTIVATE/DEACTIVATE KEY TONES 12

4.15 SETTING THE RING MELODY 12

4.16 SETTING THE RING VOLUME 12

4.17 AUTOMATIC ANSWERING 12

4.18 DEFAULT SETTINGS (RESET) 12

4.19 PROGRAMMING THE PIN CODE 13

4.20 SETTING THE DISPLAY CONTRAST 13

5 CALLER-ID FUNCTION (CLIP) 13

5.1 NEW CALLS 13

5.2 CONSULTING THE CALL LIST 13

5.3 CALLING A NUMBER FROM THE CALL LIST 14

5.4 ERASING A NUMBER FROM THE CALL LIST 14

6 CALL TRANSFER (FOR DUO VERSION ONLY!) 14

6.1 CHECKING THE HANDSET NUMBER 14

6.2 CALL TRANSFER TO ANOTHER HANDSET 14

7 TECHNICAL DATA 15

8 TROUBLESHOOTING 15

9 TOPCOM WARRANTY 16

Coc95_eur.book Page 3 Monday, January 5, 2004 10:07 AM

4 Topcom Cocoon 95

Topcom Cocoon 95

SAFETY INSTRUCTIONS

•Only use the charger plug supplied. Model: G090020E31. Do not use other chargers, as

this may damage the battery cells.

•Only insert rechargeable batteries of the same type. Never use ordinary, non-

rechargeable batteries. Insert rechargeable batteries so they connect to the right poles

(indicated in the battery compartment of the handset).

•Do not touch the charger and plug contacts with sharp or metal objects.

•The operation of some medical devices may be affected.

•The handset may cause an unpleasant buzzing sound in hearing aids.

•Do not place the basic unit in a damp room or at a distance of less than 1.5 m away from

a water source. Keep water away from the handset.

•Do not use the telephone in environments where there is a risk of explosions.

•Dispose of the batteries and maintain the telephone in an environment-friendly manner.

•As this telephone cannot be used in case of a power cut, you should use a mains-

independent telephone for emergency calls, e.g. a mobile phone.

•This telephone uses rechargable batteries.You have to dispose of the batteries in an

environment friendly manner according to your country regulations.

CLEANING

Clean the telephone with a slightly damp cloth or with an anti-static cloth. Never use

cleaning agents or abrasive solvents.

This product has a CT1 or CT1+ radio transceiver. Depending on the transceiver,

the product can be used in following countries:

CT1: Holland, Portugal, Denmark, Norway, Sweden and Finland

CT1+: Belgium, Germany and France

The type of radio transceiver is mentioned on the packaging!

NiMH

The CE symbol indicates that the unit complies with the essential requirements of the

R&TTE directive.

Coc95_eur.book Page 4 Monday, January 5, 2004 10:07 AM

Topcom Cocoon 95 5

Topcom Cocoon 95

ENGLISH

1 BUTTONS

1.1 BASE COCOON 95

1Numerical buttons

2Line button

3Redial button

4Flash button R

5Memory button

6Paging button (to retrieve the handset)

7Mute button

8Set button

9Paging/Line indicator (LED)

10 Charge indicator (LED)

11 Button

12 Button

13 INT Button

Coc95_eur.book Page 5 Monday, January 5, 2004 10:07 AM

6 Topcom Cocoon 95

Topcom Cocoon 95

1.2 CHARGER COCOON 95

1Numerical buttons

2Line button

3Redial button

4Flash button R

5Memory button

6Mute button

7Set button

8Charge indicator (LED)

9 Button

10 Button

11 INT Button

Coc95_eur.book Page 6 Monday, January 5, 2004 10:07 AM

Topcom Cocoon 95 7

Topcom Cocoon 95

ENGLISH

2 INSTALLATION

TEL

arger

ocoon 95

Power cable

Telephone cord

Base Cocoon 95

Coc95_eur.book Page 7 Monday, January 5, 2004 10:07 AM

8 Topcom Cocoon 95

Topcom Cocoon 95

•Plug one end of the phone cable into the phone unit and the other end into the telephone

line wall socket.

•Connect the small plug of the AC adaptor to the phone and the other end of the adapter

cable to the electric socket.

•Insert 3 rechargeable batteries (AAA) inside the battery compartment of the handset.

Put the handset on the base unit. The red Charge LED will burn.

Charge the handset for a period of 24 hours before using the handset for the first time. To

extend the battery life time, decharge the batteries completely from time to time. As soon as

the handset emits a warning tone, you have to put it back on the base unit.

back view of handset

Cover

Rechargeable

Batteries

Coc95_eur.book Page 8 Monday, January 5, 2004 10:07 AM

Topcom Cocoon 95 9

Topcom Cocoon 95

ENGLISH

3 BATTERY EMPTY INDICATION

When the battery is empty, the handset no longer carries out operations. When a battery is

completely empty and you have put the handset on the base unit for a short period of time,

the Battery symbol will appear to be fully charged but this is actually not the case. The battery

capacity will decrease rapidly. We advise you to put the handset on the base unit for the entire

night so that it can be recharged thoroughly.

•Full battery

•Empty battery

When you are in the middle of a conversation and the battery is almost empty, the handset

will emit a warning signal every 8 seconds. After 2 minutes the handset will be deactivated.

Place the handset on the base unit to charge (the keypad upwards).

4 TELEPHONE OPERATION

4.1 OUTGOING CALLS

4.1.1 Making a phone call

•Press the Line button . You will hear the dial tone.

•Enter the desired telephone number.

•Press the Line button when you want to terminate the call.

4.1.2 Call setup with dial preparation

•Enter the desired telephone number. An incorrect number can be corrected by means of

the Mute button . When you haven’t pressed a button for 20 seconds, the number

you’ve already entered will disappear and the handset returns to standby mode.

•Press the Line button . The number will be dialled automatically.

•Press the Line button when you want to terminate the call.

4.2 INCOMING CALLS

•When a call comes in, only the handset will start to ring. The PHONE symbol blinks

on the display.

•Press the Line button to answer the incoming call.

•When you pick up the handset from the base unit you are immediately connected to the

caller. You do not need to press the Line button . This function has to be programmed

before it can be used (see "4.17 Automatic answering").

4.3 LAST NUMBER REDIAL

•Press the Redial button . The last number dialled appears on the display.

•Press the Line button . The number will be dialled automatically.

•Press the Line button when you want to terminate the call.

Coc95_eur.book Page 9 Monday, January 5, 2004 10:07 AM

10 Topcom Cocoon 95

Topcom Cocoon 95

4.4 PROGRAMMING MEMORY NUMBERS

You can program 10 indirect numbers (of max. 24 digits) in the phone’s memory.

•Press the Set button , followed by the Memory button .

•Enter the memory location (0-9).

•Enter the telephone number you wish to save on this memory location.

•Press the Memory button . You will hear a confirmation tone.

Remarks:

•All memory numbers will be erased when the default settings have been reset (see "4.18

Default settings (Reset)").

•If you wish to insert a pause, press the Redial button on the location where you want

a pause.

4.5 CALLING A MEMORY NUMBER

•Press the Line button .

•Press the Memory button , followed by the number of the memory location (0-9).

•The memory number will be dialled automatically.

•Press the Line button when you want to terminate the call.

4.6 BABYCALL

This function allows you to program one specific number (memory location 0) that will be

dialled automatically no matter what key has been pressed, except for the Set button . To

activate this function, do the following:

•Press the Set button .

•Press numerical button ‘6’.

•Press numerical button ‘1’ to activate/deactivate this function.

•Press the Memory button . You hear a confirmation tone.

Default setting: not activated

Important: Memory number [0] has to be programmed for this function. This function

is not valid when “mem 0” is not programmed.

4.7 MUTE FUNCTION

It is possible to deactivate the microphone during a conversation. Now you can speak openly

without being heard by your correspondent.

•Press the Mute button during a conversation. The microphone will be deactivated.

The MUTE symbol appears on the display.

•Press the Mute button again when you want to continue the conversation.

4.8 SETTING THE VOLUME

During a conversation you can set the volume by pressing the Set button . The indication

‘Loud Hi/Lo’ appears on the display.

Coc95_eur.book Page 10 Monday, January 5, 2004 10:07 AM

Autres manuels pour Cocoon 95 DUO

Table des matières

Langues :

Autres manuels Topcom Téléphone

Topcom

Topcom EVITA Telephone Manuel utilisateur

Topcom

Topcom ULTRA SR1250 ECO Fiche d'information produit

Topcom

Topcom BUTLER 5500 Manuel utilisateur

Topcom

Topcom FIDELITY SMS Manuel utilisateur

Topcom

Topcom Axo 150 Manuel utilisateur

Topcom

Topcom SOLOGIC A831 Manuel utilisateur

Topcom

Topcom BUTLER 1410 Manuel utilisateur

Topcom

Topcom AXISS 800 Manuel utilisateur

Topcom

Topcom FIDELITY 1000 Manuel utilisateur

Topcom

Topcom BUTLER 2450 Manuel utilisateur

Topcom

Topcom TS-5611 Fiche d'information produit

Topcom

Topcom MAGIO 105 Manuel utilisateur

Topcom

Topcom ALLURE 200 Manuel utilisateur

Topcom

Topcom SOLOGIC B901 COMBO Fiche d'information produit

Topcom

Topcom ARGO Manuel utilisateur

Topcom

Topcom FIDELITY 140 Manuel utilisateur

Topcom

Topcom Butler 4502 Manuel utilisateur

Topcom

Topcom BABY VIEWER 2500 Manuel utilisateur

Topcom

Topcom ALLURE 200 Manuel utilisateur

Topcom

Topcom MAGIO 100 Manuel utilisateur

Topcom

Topcom BUTLER 565C Manuel du système

Topcom

Topcom Babytalker 1010 Manuel utilisateur

Topcom

Topcom ALLURE 270 Manuel utilisateur

Topcom

Topcom WEBTALKER 200 Manuel utilisateur

Manuels Téléphone populaires d'autres marques

GE 2-9480 Manuel utilisateur

Geemarc

Geemarc PHOTOPHONE 155 Manuel utilisateur

D-Link

D-Link DWR-720/PW Manuel utilisateur

Interquartz

Interquartz Gemini IQ333 Manuel utilisateur

SSS Siedle

SSS Siedle HT 840-0 Manuel utilisateur

Motorola

Motorola TITANIUM Manuel utilisateur

Panasonic

Panasonic ICX Manuel utilisateur

LG H870DS Manuel utilisateur

Samsung

Samsung GT-I9500 Manuel utilisateur

AT&T

AT&T Trimline 205 Manuel utilisateur

Selta

Selta zenyth 600 Manuel utilisateur

Doro

Doro AFTI 20 Manuel utilisateur

UNIQCELL

UNIQCELL A1 Manuel utilisateur

Panasonic

Panasonic KX Series Manuel utilisateur

Jabra

Jabra SP5050 - Bluetooth hands-free Speakerphone Manuel utilisateur

BT Decor 425 Manuel utilisateur

NEC

NEC SV8500 Manuel utilisateur

Teledex

Teledex PEARL Manuel utilisateur
