Toastmaster®

A Middleby Company

OWNER'S OPERATING

&INSTALLATION

MANUAL

MECHANICAL SLOT TOASTERS

Models 1D3,1D22B & 1BB5

Toastmaster®• 1400 Toastmaster Drive• Elgin, IL 60120 • (708)741-3300

A Middleby Company

Middleby Corp 24 Hour Service Hotline 1-800-238-8444

Part No. 3102564

P3/93

Toastmaster

NO QUIBBLE LIMITED WARRANTY

TOASTMASTER, HEREINAFTER REFERRED TO AS THE SELLER, WARRANTS EQUIPMENT

MANUFACTURED BY IT TO BE FREE FROM DEFECTS IN MATERIAL AND WORKMANSHIP

WHICH IT IS RESPONSIBLE. THE SELLER'S OBLIGATION UNDER THIS WARRANTY SHALL BE

LIMITED TO REPLACING OR REPAIRING AT SELLER'S OPTION, WITHOUT CHARGE, ANY

FOUND TO BE DEFECTIVE AND ANY LABOR AND MATERIAL EXPENSE INCURRED BY

IN REPLACING OR REPAIRING SUCH PART. SUCH WARRANTY SHALL BE LIMITED TO THE

ORIGINAL PURCHASER ONLY AND SHALL BE EFFECTIVE FOR A PERIOD OF ONE YEAR

DATE OF ORIGINAL INSTALLATION, OR 18 MONTHS FROM DATE OF PURCHASE,

IS EARLIER; PROVIDED THAT TERMS OF PAYMENT HAVE BEEN FULLY MET.

The warranty period for Accu

Miser griddles shall be

months from the date of installation or

months from the date of purchase, whichever is earlier.

Normal maintenance functions and customer abuse are not covered by thisno quibble warranty.

Seller shall be responsible only for repairs or replacements of defective parts performed by Seller's

authorized service personnel. Authorized service agencies are located in principal cities througho

ut the

contiguous United States, Alaska and Hawaii. This no quibble warranty is only valid in the

United

States. Outside of the United States, warranty labor will only be performed during normal working hours.

Overtime and/or premium labor charges are the responsibility of the Buyer.

The foregoing warranty is exclusive and in lieu of all other warranties, expressed or implied.

There are no implied warranties of merchantability or of fitness for a particular purpose.

The foregoing shall be Seller's sole and exclusive obligation and Buyer's sole and exclusive remedy for

any action including breach of contract or negligence. In no event shall Seller be liable for a sum in

excess of the purchase price of the item. Seller shall not be liable for any prospective or lost profits of

Buyer.

This warranty is effective on Toastmaster equipment sold on, or after August1,1995.

Toastmaster • 1400 Toastmaster Dr. •Elgin, IL 60120-9272 • (708) 741 -3300 • FAX(708) 741 -0015

Middleby Corp 24 Hour Service Hotline 1-800-238-8444

IN CASE OF FIRE

De-energize toaster at disconnect switch. This will cut off power to the heating elements allowing

toaster to cool. This reduces the flash point temperature making it easier to stop the fire.

CAUTION:

Do not attempt to fight a grease fire by playing the nozzle of the fire extinguisher directly on the

burning grease. The force will cause the burning grease to be sprayed to adjoining equipment

making it difficult to contain the fire. Only use a fire extinguisher filled with CO;, which is for liquids

and oils and suitable for electric powered equipment.

WARNING

DO NOT pick up the toaster by sticking fingers into toaster slots and grasping the heating elements.

Damage to the heating elements and electrical shock can result.

RETAIN THIS MANUAL FOR FUTURE REFERENCE

This manual provides detailed information for installation and operation of your new Simplicity Toaster.

It also contains some information to assist the operator in diagnosing problems in the event of a

malfunction. This manual is an important tool for the operator and should be kept readily available.

FOR YOUR SAFETY

DO NOT STORE OR USE GASOLINE OR OTHER

FLAMMABLE VAPORS OR LIQUIDS IN THE VICINITY OF

THIS OR ANY OTHER APPLIANCE

NOTICE

Using any parts other than

genuine Toastmaster factory

supplied parts relieves the

manufacturer of all liability.

NOTICE

Toastmaster (Manufacturer) reserves the

right to change specifications and product

design without notice. Such revisions do

not entitle the buyer to corresponding

changes, Improvements, additions or

replacements for previously purchased

equipment.

TABLE OF CONTENTS

SECTION 1

DESCRIPTION

A Component Location

B Component Function

C Toaster Specifications

D Toaster Dimension Drawings

5-6

SECTION 2

INSTALLATION

A Inspect For Shipping Damage

B Unpacking Toaster

C Electrical Connection

D Checking the Installation

SECTION 3

OPERATION

A Location and Function of Controls

B Operating Procedure

C Operating Hints and Cautions

D Operating Capacity

E Cleaning

SECTION 4

PARTS LIST

Model 1D3 & 1 D2-2 Exploded Drawing

14-15

Model 1D22B& 1D3B Exploded Drawing

16-17

Model 1BB5 Exploded Drawing

18-19

SECTION 5

ELECTRICAL SCHEMATIC

Model 1D3 Schematic

Model 1D22B Schematic

Model 1BB5 Schematic

iii

Toastmaster Model 1D3, 1D22B and 1BB5 Toasters are:

•Equipped with heating elements to provide uniform heat for even toasting.

•Automatic pop-up type toasters

•Equipped with an operating lever, color selection knob and manual release lever for eachpair of toaster

slots.

•Equipped with wide slots. The Model 1 D22B bun toaster is equipped with extra wide slots.

•Timer controlled.

•Equipped with a crumb tray.

Figure 1-1

SECTION 1 -DESCRIPTION

A. Component Location

Data Plate Located At

Rear Of Toasters

Slots

Model 1D3 Has A Heating

Element on Both Sides of Each Slot.

Operating Controls (See

Operation Section 3)

Crumb

Tray

36 "

Cord

Plug

Model 1D3

36"

Cord

&Plug

Crumb

Tray

Operating

Controls

(See

Operation

Section 3)

Slots

Model

BBS

Has A Heating

Element on Both

Sides of Each Slot

Slots

Model 1D22B

Has A Heating Element

On Only One Side Of

Each Slot.

Operating

Controls

(See

Operation

Section 3)

Crumb

Tray

Cord

Plug

Figure 1

Component Location

SECTION 1 -DESCRIPTION

B. Component Function

1. Slots

a. Model 1D3 Toaster has four slots for toasting one to four slices of bread. The width of the toasting

slots will accommodate "Texas Size" bread, frozen waffles, English muffins and many other food

items. A heating element is located on both sides of each slot for a total of 8 elements.

b. Model 1 BBS Toaster has two slots for toasting one or two slices of bread. The width of the toasting

slots will accommodate "Texas Size" bread, frozen waffles, English muffins and many other food

items. A heating element is located on both sides of each slot for a total of 4 elements.

c. Model 1 D22B is a bun toaster which has four extra wide slots for toasting one to four buns. The

toaster is equipped with an element on only one side of each of four slots for a total of four elements.

This allows toasting of buns on one side only.

2. Operating Controls

(Refer to Operation Section 3)

3. Crumb Tray

The crumb tray is located in the bottom of the toaster under all slots. The crumb tray is removed for

cleaning by pulling straight out from the front of the toaster.

SECTION 1 -DESCRIPTION

SPECIFICATION CHART

Model1D3 Model 1BB5 Model 1D22B

Overall Dimensions

Width 11-5/8"(292mm) 6-1/2"(165mm) 11-5/8"(292mm)

xXx

Depth 13"(330mm) 12-9/16" (319mm) 13"(330mm)

xXx

Height 8-3/4"(222mm) 8-3/4"(222mm) 8-3/4"(222mm)

Toasting Slot Dimensions

Width 1-1/8"(29mm) wide 1-1/8"(29mm) wide 1-9/16"(40mm) wide

xxx

Length 5-1/4"(133mm) long 5-1/4"(133mm) long 5-1/4"(133mm) long

Approximate Net Weight 20 Ibs (9.1 kg) 13 Ibs (5.9 kg) 20 Ibs (9.1 kg)

Approximate Shipping Weight 25 IDS (11.3 kg) 15 Ibs (6.8 kg) 25 Ibs (11.3 kg)

Construction Formed & Welded Sheet Steel

Finish Chrome Steel

Capacity 4slices/load, 2slices/ load 4bun halves/load

250 slices/hour 125 slices/hour 250/hour

Cord 36" (914mm) 36" (914mm) 36" (914mm)

Plug: Current NEMA6-15P NEMA5-15P NEMA5-20P

(208V& 240V) (120V) (120V)

Non-Current

NEMA14-20P NEMA6-15P NEMA6-15P

(120/208 V, 115/230 V (208V,230V& 240V) (208V,230V& 240V)

& 120/240V)

NEMA 14-20P

(120V, 120/208V,

115/230 V&120/240V)

Electrical: Current 208V(12.5Amp) 120V, 10.83 Amp 120V, 16.0 Amp,

240V(10.83 Amp), 2Pole,3Wire 2Pole,3 Wire

2Pole,3 Wire

Non-Current

120/208 V, 120/240V, 208V(6.25 Amp), 120/208V, 120/240V,

10.83Amp/line, 240V(5.42 Amp), 8.0 Amp/line

3Pole,4 Wire 2Pole,3 Wire

208V, 4.62 Amp

240V, 4.0 Amp

2Pole,3 Wire

NOTICE

Toastmaster (Manufacturer) reserves the right to change specifications and product design

without notice. Such revisions do not entitle the buyer to corresponding changes, improve-

ments, additions or replacements for previously purchased equipment.

C. Toaster Specifications:

SECTION 1 -DESCRIPTION

D. Model 1D3 and 1D22B Toaster Dimension Drawings

1D3 and/or 1D22B mounted on 1D3CS Stand

1D3 TOD View

1D3 or 1D22BFront View 1D3 or 1D22BSide View

1D3 and/or 1D22B Dimension Drawings

1D22B

Top View

SECTION 1 -DESCRIPTION

D (continued). Model 1BB5 Toaster Dimension Drawing

Top View

Front View Side View

1BB5 Dimension Drawing
