Toa HLS46S-8 Manuel utilisateur

PROFESSIONAL SOUND SYSTEM

Instruction Manual

Low Frequency Loudspeaker Model HLS46S-8

APPEARANCE

GENERAL DESCRIPTION

The HLS46S-8 is a 460 (18 in.) low-frequency loud-

speaker designed for professional applications in high

level sound reinforce ent environ ents where high

efficiency, supper low frequency range, and faithful

reproduction are required, such as studios, theaters,

concert halls, auditoriu s, discos, and in live sound

reinforce ent applications. The HLS46S-8 offers excep-

tionally high power handling capacity, ultra linearity in

supper low frequency range, and a unifor frequency

response fro 20 Hz to 3,000 Hz. A crossover frequency

of 1,000 Hz or lower is reco ended to obtain s ooth-

est overall syste response. The loudspeaker e ploys a

low- ass 100 (4 in.) dia eter voice coil of edge-

wound copper-clad alu inu ribbon on an alu inu

coil for , which operates in a flux density of 13,600

gauss. The voice coil is driven by a powerful ferrite

agnet, which is supported by a rugged diecast alu i-

nu fra e. The cone suspension is ade of exception-

ally high co pliance cloth surround, da ped.

FEATURES

1. S ooth, extended supper low frequency response

2. High power handling capacity : 600 watts continuous

pink noise (AES Standard)

3. High efficiency and ultra linearity in super low range

4. Low distortion

5. Voice coil of edgewound copper-clad alu inu

ribbon, with an alu inu coil for

6. Powerful ferrite agnet structure

7. Rigid diecast alu inu construction

Specifications

SPECIFICATIONS

Nominal Diameter 460 (18 in.)

Nominal Impedance 8 oh s

Power Handling1 600 W continuous pink noise

Sensitivity

98 dB (1W/1 )

Frequency Range 20 Hz to 3,000 Hz

Highest Recommended Crossover Frequency 1,000 Hz

Effective Piston Diameter 400 (16 in.)

Displacement Limit (p-p) 40 (1.6 in.)

Minimum Impedance 7.0 oh s ±10% (25°C)

Voice Coil Diameter 100 (4 in.)

Voice Coil Material Edgewound copper-clad alu i-

nu ribbon

Voice Coil Winding Depth 30 (1.2 in.)

Top-plate Thickness 12 (0.47 in.)

Bl Factor 17.4 N/A

Effective Moving Mass 0145 kg

Flux Density 13,600 gauss

Polarity

Positive voltage on plus (RED) ter inal gives

forward diaphrag otion.

Note

1. AES Standard (60 to 600 Hz)

2. Sensitivity is based on a band-li ited (100 to 800 Hz)

pink noise signal.

3. Specifications are subject to change without notice.

THIELE-SMALL PARAMETERS

fs 30 Hz

Re 5.5 oh s

Qts

0.41

Qms 2.5

Qes

0.49

Vas

430

lit.

(15.2

ft3)

0.126

(195

in2)

Xmax 10.3 (0.41 in.)

1294

(79.0

in3)

(half space) 2.4%

Pe (Max) 600 W continuous pink noise

MOUNTING DATA

Overall Diameter: 464 (18.3 in.)

Bolt Pattern Diameter 440 (173 in.)

Baffle Cutout Diameter

Front Mount : 422 (16.6 in.)

Rear Mount : 420 (16.5 in.)

Depth 202 (7.95 in.)

Loudspeaker Volume 8 lit (0.28 ft

)

Weight 16.5 kg (36.4 Ib.)

Standard Accessories

Mounting screws, washers and nuts : each 8

Instruction anual : 1

Warranty card : 1

Frequency Response

Measured in an anechoic environ ent at 1 watt

and 1 eter under the condition that speaker unit

is ounted in a 200-liter sealed box. The i pedance

agnitude curve is easured in free-air.

Measured at 60 watts (-10 dB power), 1 eter.

Frequency Response and Impedance Curve

Distortion Response

TOA Corporation

KOBE, JAPAN

133-01-318-20

Model HLS46S-8

TOA

(AES Standard 600W)

TOA
