TOA SPEAKER SYSTEM

PERSONAL MONITOR SPEAKER

SYSTEM

SM-60

GENERAL DESCRIPTION

The TOA SM-60 is a full-range, small monitor speaker is made of cast aluminum, so that it can withstand the

system with power handling, up to 70 watts of pink noise roughest use. With an accessory bracket, the SM-60 is

and an input impedance of 16 ohms. Its sealed box mountable on microphone stands, microphone stand

enclosure houses two full-range cone speakers (5-inch,

shafts (1.10" Max.), plates and walls.

12cm) with high efficiency and durability. The enclosure

SPECIFICATIONS Enclosure:

Speakers:

Power Handling

Continuous

Pink noise:

Continuous

Program:

Impedance:

Sensitivity

Sealed type

Two 5-inch (12cm) full-range

cone speakers

70 watts of band limited pink

noise (50Hz to 20kHz)

200 watts

16 ohms

90dB (1W/1m)

ARCHITECT’S AND

The speaker shall be a full-range, small speaker

ENGINEER’S

system with power handling, up to 70 watts of

SPECIFICATIONS

pink noise; and an input impedance of 16 ohms.

Its sealed box enclosure shall house two full-

range cone speakers (5-inch, 12cm) with high

efficiency and durability. The enclosure shall be

made of cast aluminum, so that it can withstand

the roughest use. With an accessory bracket, the

speaker system shall be mountable on micro-

phone stands, microphone stand shafts, plates

and walls. In addition to the various specifica-

Frequency

Response:

110Hz~16kHz

Material (Finish): Front Grill...Perforated metal

(Black)

Body. . . . . .

Cast aluminum

(Black)

Connectors: Locking 1/4" phone jacks

Dimensions:

12.8 (W) x 6.7 (H) x 5.5 (D) inches

325 (W) x 170 (H) x 140 (D) mm

Weight:

Approx. 10.6 Ibs (4.8 kg)

*No performance degradation should not appear after 24-hour testing.

*Specifications subject to change without notice.

tions stated above, the speaker system shall

meet the following overall performance and

specifications criteria: sensitivity of 90dB

(1W/1m); frequency response of 110Hz to

16kHz; front grill of perforated metal (black);

body of cast aluminum (metallic black); connec-

tors of locking 1/4" phone jacks; dimensions of

6.7" high, 5.5" deep, 12.8" wide; weight of 10.6

Ibs (4.8 kg). The speaker system shall be a TOA

Model SM-60.

CHARACTERISTIC

DIAGRAMS

FREQUENCY RESPONSE (1W/1m) IMPEDANCE CHARACTERISTIC

Frequency (Hz)

HARMONIC DISTORTION (1W/1m)

Frequency (Hz) Frequency (Hz)

POLAR RESPO

HORIZONTAL

SCALE IS 10dB PER DIVISION SCALE IS 10dB PER DIVISION

500Hz

1kHz

2kHz

4kHz

32

16

8

020 50

100

200 500

1000

2000 5000 10000 20000

Hz

Frequency (Hz)

DIRECTIONAL FREQUENCY RESPONSE (1W/1m)

80

60 10 20 50 100 200 500 1000

2000

5000

10000

20000

Hz

VERTICAL

500Hz

1kHz

2kHz

4kHz

PrintedinJapan833-64-501-0B
