Toa F-500WP Manuel utilisateur

Instruction Manual

F-500WP, F-500WP-L

F-600WP, F-600WP-L

SPEAKER SYSTEM

Handlin

1. The speaker system is rainproo ed or outdoor applications. However, do not dash water intentionally over unit or

the cleaning purpose as this can cause damage to the internal speaker components.

2. Do not loosen any ixing screws o this speaker or disassembly or modi ication. This impairs the speaker's rain-

proo capability, involving a risk o accidents or breakdowns.

3. Sea breezes shorten the li e o this speaker. Do not install the speaker in the seaside areas.

4. Toa can accept no responsibility or accidents or unit's breakdowns resulting rom improper installations or dis-

assemblies or modi ications per ormed or purposes other than legitimate maintenance or repair services.

Features Specifications

1. Rain- and weather-proo construction that makes the

speaker most ideal or outdoor applications.

2. 2-way, sealed speaker incorporating a woo er with

high power handling capacity and a constant-

directivity (CD) horn tweeter with a high-e iciency driv-

er.

3. Uni orm requency response within the range o 60°

horizontal × 40° vertical thanks to the CD horn.

4. Enclosure is made rom polypropylene resin that

assures high sound per ormance.

5. Designed or high e iciency, extended range and high

durability as well as or easy installation, the speaker

can be used in wide applications.

Type ...

Woofer

Tweeter

Rated power or

Power handlin capacity

F-500WP

F-500WP-L

F-600WP

F-600WP-L

Sealed type

20cm cone 30cm cone

CD horn + drive r

60W*

80W"

240W***

120W*

120W***

Output SPL

Frequency ...

Crossover ...

Ambient ...

Material ...

Color

Dimensions

(W×H×D)

Wei ht

93dB (1W/1m)

80~20000Hz

3000Hz

98dB(1W/1m)

80~20000Hz

2000HZ

-15°C ~ +50°C

Polypropylene resin

Ivory

452x282x210 mm

17.8x11.1x8.3 inches

Approx. 11 kg Approx. 9.5kg

552×392x250 mm

21.7x15.4x9.8 inches

Approx. 20kg | Approx. 17.5kg

Impedance

* Rated power input ** Continuous pink noise input *** Continuous

program input

The above specifications are subject to chan e without notice.

precautions

Important: READ RULE FOR SAFE INSTALLATION, OPERATION AND INSTRUCTIONS CAREFULLY.

Installation

1. To avoid breakdowns, we suggest that you install the

speaker in the areas where the ambient temperature is

rom -15°C to +50°C. In snowy areas, protect unit

rom the snow.

2. When installing the speaker, use the optional mounting

bracket or outdoor installation. Also, take care about

the ollowing:

(1)The bottom sur ace o the speaker has two air

vents and one drain hole. Be sure to mount the

speaker with that side down, taking care that such

holes are not blocked. (The drain hole is or drain-

age o rainwater that enters the horn.)

Air vent

(2 locations)

Drain hole

Bottom sur ace

(This side down.)

(2)As shown in the igure below, the speaker can be

positioned at any angle rom 0° (horizontal) to a 45°

downward angle. As this mounting range permits

ree drainage o rainwater rom the inside o the

speaker, do not exceed this range, nor direct the

speaker upward.

Positioning angle

Frequency response (1W/1m: 1/3 Octave Pink Noise)

TOA Corporation

KOBE, JAPAN Printed in Japan

133-01-312-20

1. Polarity

When connecting the speaker, observe the polarity

shown in the igure below.

Impedance

switching

(Only

available

F-500WP

and

F-600WP)

The speaker input impedance can be switched in 4

steps with a built-in selector. See the table below.

The impedance is actory-preset to position 3.

F-500WP

Position [1]

Position [21

Position [3]

Position [4]

100V Line

70V Line

15W

30W

60W

7.5W

15W

30W

60W

F-600WP

Position [1]

Position [2]

Position [3]

Position [4]

100V Line

70V Line

30W

60W

120W

15W

30W

60W

120W

Overload protection device

The speaker is provided with individual overload protec-

tion devices or woo er and tweeter. (When the woo er's

device is activated, the woo er's output signal level is

attenuated by about 15 dB, while the tweeter is cut o i

the tweeter's device is activated.) I the sound volume o

the woo er or tweeter suddenly decreases during use,

this indicates that the protection devices have leaped into

action. In such a case, lower the speaker input power

level once irst to wait till the protection devices automati-

cally return to the normal condition (about 2 to 20

seconds). A ter they are reset, use the speaker turning

down the volume a little more than be ore.

F-500WP, F-500WP-L

F-600WP, F-600WP-L

133-01-312-20
