FACP «TIRAS PRIME 8L»
QuickStart Setup Guide
Figure 1 –Main module with control and indication panel:
1. MiniUSB socket; 2. Display; 3. Keypad.
Setup by means of «tLoader PRIME»application
1. Disconnect FACP main and alternative power (if connected).
2. Connect FACP to PC with USB-miniUSB cable (fig. 1, pos. 1).
3. Run the «tLoader PRIME»application and setup main settings:
3.1 Zone types:
-automatic detectors:
•without verification
•verification Type A
•verification Type B
•verification Type C
-manual call points;
-input.
3.2 Outputs:
-assign required zones to sounders
-assign required zones to relays
3.3 Device assigning: Using M-Z(f) –if you need to increase numbers of zones, using M-Z(f)
module.
3.4 Users –configuring user options:
-add user;
-remove user;
-name, access code, authorities.
3.5 Scripts –creating the scripts for outputs operations
3.6 General settings:
-Delays for outputs activation
-Reset time
-Restart sounders with new fire
-Grounding control
-Day/Night mode (alert mode depending on the time of the day)
4. Press the button “Loading settings in device”.
5. Disconnect USB-miniUSB cable from FACP.
6. Connect FACP main and alternative power.
7. Set up actual time and date:
-press the button on FACP panel (fig.1, pos. 3);
-enter access code (default - 1111);
-by means of arrows and select menu item «10: Time and date»;
-enter time and day in the following format “HH:MM DD/MM/YY”, (where HH are hours, MM
are minutes, DD are days, MM are months, YY are years);
-press buttons to confirm changes and to exit from menu.
Setup by means of FACP controls
1. Press the button on FACP panel (fig.1, pos. 3) and enter the 3rd level access code (default –
1234).
2. Using arrows and select required menu item. Press buttons to confirm changes and
to exit from menu
2.1 Zones:
-automatic detectors:
•without verification
•verification Type A
•verification Type B
•verification Type C
-manual call points
-input
2.2 Outputs:
-assign required zones to sounders
-assign required zones to relays
2.3 Delays
-Delay of FT output (sec)
-Delay of main power fault detection (min)
2.4 System options:
-Grounding control
-Always siren (Restart sounders with new fire)
-Using M-Z(f) –if you need to increase numbers of zones, using M-Z(f) module
-Reset time
3. Set up actual time and date:
-press the button on FACP panel and enter the 2nd level access code (default –1111);
-by means of arrows and select menu «10: Time and date»;
-enter time and day in the following format “HH:MM DD/MM/YY”, (where HH are hours, MM
are minutes, DD are days, MM are months, YY are years);
-press buttons to confirm changes and to exit from menu item.
4. If required, you can setup Day/Night mode (alert mode depending on the time of the day):
-press the button on FACP panel and enter the 2nd level access code (default –1111).
-using arrows and select menu item «5: Day night»:
•State: on/off
•Enter the “Day” and “Night” time in the following format “HH:MM”, (where HH are
hours, MM are minutes);
Factory settings
Option
Value
Zone type:
Zone1 –Zone7
Zone8
Automatic detectors, without verification
Manual call points
Outputs:
Sounder1
Sounder2
Relay1
Relay2
Assigned zones: 1,2,3,4
Assigned zones: 5,6,7,8
Assigned zones: 1,2,3,4
Assigned zones: 5,6,7,8
Using M-Z(f)
Off
Users:
Administrator
User
Installer
Authority –Administrator, Access code –1111
Authority –User, Access code –1
Authority –Installer, Access code –1234
General settings:
Delays:
Delay of FT output (sec)
Delay of main power fault detection (min)
Reset time (sec.)
Restart sounders with new fire (always siren)
Grounding control
Day/Night mode
0
5
10
On
Off
Off
