Timex IConnect Premium Active Manuel utilisateur

iConnect Premium Active By Timex™

00725c-Premium Active

USER GUIDE…..……..……..……..……..…….. 1

05L096001 5.18.20

iConnect Premium Active

User Manual

Important Safety Instructions And Warnings

1. To prevent risk of fire, chemical burn, electrolyte leak, and/or injury from the unit’s

internal Lithium-polymer battery:

a. Do not attempt to remove the case back or exterior shell of the unit, or to remove

its non-user-replaceable battery.

b. Do not leave the unit exposed to a heat source or in a high-temperature location

(such as in the sun or in an unattended vehicle). To prevent damage, store the unit

out of direct sunlight.

c. Do not puncture or incinerate the unit.

d. When storing the unit for an extended time, keep it in the 32°F to 77°F (0°C to 25°C)

temperature range.

e. Charge the unit only within the 50°F to 113°F (10°C to 45°C) temperature range.

f. Do not operate the unit outside the -14 to 104°F (-10°C to 40°C) temperature range.

g. Contact your local waste disposal department to properly recycle or dispose of the

unit or its battery.

2. Use only the charging cable supplied with this product.

3. This unit is not a medical device and is not recommended for use by persons with

serious heart conditions. Always consult your physician before beginning or modifying

an exercise program.

4. Do not attempt to read the unit’s display while moving: this is unsafe and distracting,

and could result in an accident or collision. Read the display only when you can safely do

so. See instructions for details.

1. Product Specifications

➢Model: M05L

➢CPU RTL8762C ARM Cortex-M0 53MHz

➢Memory: RAM 256KB+ ROM 128Mb

➢Capacitive touch screen 1.3” 240*240 TFT full touch

➢Bluetooth version 5.0

➢Functions: Notifications, Heart Rate Monitor, Sleep, Activity, Weather, Relax, Sport

➢Battery Lithium-ion 3.7V/170mAh

2. Product Details

(1) Power on: When the watch is off, press and hold the touch screen for 5 seconds to turn it

on, and the main Time of Day (TOD) page of the watch will be displayed.

(2) Touch screen operation: Swipe to the left to the menu page, or to the right to the

function list, then tap the function icon to enter the corresponding feature.

(3) Turn on screen: When the watch is on, touch anywhere on the display area to light up

screen. If the “Turn wrist to wake” feature is enabled in the app, the watch screen can be

activated by turning the wrist.

(4) Shutdown: Enter “Setting” of menu page and tap on “Shutdown”. Tap “OK” to shut down

the watch. Or tap on “Shut down” icon in function list and tap “OK” to shutdown the watch.

3. Features and Functions

3.1 Basic Functions

Touch Screen Display:

(1) Press and hold the time of day screen to enter dial switching mode. Dial options can be

viewed by sliding left and right. Tap on desired dial option to confirm switching to that dial.

(2) Drag the screen right to display function list -> Daily activity, Heart rate, Messages,

Workouts, Sleep, Weather, Relax, Music, Timer, Brightness, Change dial, System and

Shutdown. Tap on the item to enter the corresponding function (the list can be dragged up

and down)

(3) Drag the screen down to enter the Shortcut mode where brightness adjustment, Do not

disturb mode, shutdown and system information are available.

(4) Drag the screen up to show stored messages.

(5) Drag the screen to left to enter the icon main menu page and navigate by dragging the

screen left and right. Tap on each functional icon to enter the corresponding function. Drag

the screen right in sub-menu to return to the previous level.

3.2 Custom Watch Faces

4. Getting Connected

4.1 The iConnect By Timex 2 App

Download and install the " iConnect By Timex 2" App from Apple APP Store or Google

Play Store; iPhone with IOS 10.0 or higher and Android phone with Android 6.0 or higher is

recommended.

4.2 Connection and Synchronize Data

4.2.1 For Android:

Open iConnect By Timex 2 - left slide menu bar –Pair my watch - select the corresponding

device icon - search for the corresponding Bluetooth address pairing.

Click OK and Click Pair to pair watch as below.

4.2.1.2 For IOS:

Connect step 1: Open “iConnect By Timex 2”- left slide menu bar –Pair my watch - select

the corresponding device icon - search for the corresponding Bluetooth pairing

Connect step 2: Now the Bluetooth menu interface displays iConnect Premium Active

connected successfully as pictured below:

There will be “Connected” and icon shown on the right of the Bluetooth name of the

watch after connected successfully.

4.2.2 Synchronizing Data

Pair your watch with " iConnect By Timex 2" App. Press " " to sync data. Your

data will be shown on App accordingly.

Notice：

Turning off the Bluetooth function on your phone will interrupt synchronization features

between your phone and watch. Please keep Bluetooth turned on.

It is recommended to allow the “Location Services”on your phone to the iConnect by Timex

2 App. This will enable the Weather feature as well other functions.

4.2.3 Step History

In the App tap on the tile “Today’s Steps” or “Activity data” to enter the “Step History”

page. You can adjust your daily step goal by tapping on the “set up” located at the top

right corner. The step count recorded per day and the accumulated step count will be

shown under Step History.

4.2.4 Adding Friends

Add friends to compete in daily activity with each other.

Enter the “My Friend” in the Navigation menu. Tap on the “add friend” icon at the

top right corner to enter the “Add friend” page. Type the email address of desired

friend and search. The users with the name you searched will be listed. Tap on the

“Add friend” button to add the friend.

5.2.4 Leaderboard

Shows the ranking among added friends by daily activity.

4.3 Main Features

4.3.1 Daily Activity

(1) The watch will display the user's total number of steps, walked distance, calories burned

on the current day, and the data will be cleared at midnight every day.

(2) Tap on the “Daily Activity” icon in the main menu to check your activity info. The screen

will be turned off automatically after the watch is idle for more than 10 seconds.

4.3.2 Heart rate

(1) Heart rate measurement: The watch will measure the user's heart rate under the heart

rate measurement interface. After the test is completed, the vibration will display the result.

(2) Heart rate measurement: slide to the left on the main interface and click the heart rate

static icon to switch to the heart rate measurement interface. Once the interface is entered,

the measurement will start. "- -" is shown on screen when the watch starts the measurement.

The measurement can take up to 40 seconds. If no value is displayed, please return to menu

and re-enter the heart rate measurement interface and try again.

4.3.3 Sleep

(1) The watch will display the user's sleep time of the previous night. The default sleep

measuring period is from 21:30 of current day to 12:00 of next day.

(2) Drag the TOD (time of day) screen to the right side. Tap on the Sleep icon to enter the

sleep interface. “Monitoring……” on the screen indicating the watch is still measuring the

sleeping time. Once the watch detects valid activity after sleep, the sleeping time counting

will stop and the measured sleep time of the previous night will be displayed on the screen.

4.3.4 Message

After pairing the watch to the phone, notifications from your phone will be sent to your

watch. It is necessary to switch on the message sending feature in the App in advance in the

“Notification Settings” page.

4.3.5 Workouts

In workouts mode: Tap on the icon to enter Workouts sub-menu which includes Walking,

Running, Climbing, Riding, Basketball, Elliptical, Yoga.

After entering the Workouts, choose a desired workout mode. The workout tracking will start

automatically once tapping on the desired workout mode. You can always pause the tracking

by tapping on the “pause” icon at the bottom right corner of the screen. After pausing, you

can resume the tracking by tapping on the “play” icon at the bottom right corner or stop the

tracking by tapping on the “stop” icon at the bottom left corner.

Please note that the watch supports 4 hours of workout tracking.

4.3.6 Timer

Tap on the Timer icon to enter the stopwatch interface.

For counting-up timer, ensure the correct icon on top side has been tapped. Start the time

counting by tapping the “play” icon at the bottom right corner of the screen. Tap on the

“pause” icon at the bottom right corner of the screen during counting to pause the Timer.

Then, tap the “play” button at the bottom right corner to resume counting or tap the “reset”

icon at the bottom left corner to reset the Timer. The watch supports time counting up to

99hrs 59mins 59sec.

For counting-down timer, ensure the correct icon on top side has been tapped. Drag the hour,

minute and second section of the screen up and down to adjust the starting time. Tap on the

“play” icon at the bottom right corner to start the time counting down. Pause, resume and

reset the counting-down timer by similar operation as described in counting-up timer.
