INSTRUCTIONS FOR USE

3-function folding walker

Product code: JMC-C 3222

1. Characteristics

3-function folding walker is made of transverse reinforced aluminium

frame. The walker is equipped with front legs with rubber tips and with

legs with solid wheels 5’’ in diameter. It fulfils 2 functions: the rigid and

the reciprocating. Owing to the latter one, it is possible to move the

sides alternatively without the need to lift the walker. The walker

possesses locking clips which are used to switch the functions, wide

area of support as well as stable and long range of walking. Soft and

foamed handgrips provide proper stabilization and comfortable use.

Owing to adjustable legs, the height of the walker can be adjusted

according to user’s height. Folded walker takes little space, and thus,

can be easily stored and transported.

Elements of the walker:

a. Handgrip

b. Frame folding clip

c. Rigid function

d. Reciprocating function

e. Height adjustment

f. Anti-sliding rubber tip

g. Wheels 5’’ in diameter

2. Application

3-function walker is ancillary equipment designed for people with

reduced mobility who need stable support and help while walking. It is

also recommended to the elderly as an aid in keeping balance,

improving walking comfort and ensuring safety from falling. The use of

the walker affects positively on the return to activity of the people with

lower limbs diseases and with locomotion or tilting to erect position

problems.

3. Assembly

Unfolding and folding

•Before folding the walker, mount legs with tips or with wheels.

•To unfold the walker, pull the sides apart to the maximum

position until the handgrips are locked.

•To fold the walker, press the plastic element located in the middle

on the transverse frame and fold the sides.

Height adjustment

•The height should be set on such a level that the user, who is

leaning against the handgrips, stands upright, as far as he or she is

able to, with his or her shoulders in rest position and with slightly

bent elbows. It is inadvisable to hang on the walker with all the

body weight.

•To adjust the height of legs, press the metal pin, select

appropriate height of the leg, and lock the position of the legs

relative to each other. The legs are adjustable in 2.5 cm

increments.

Note! The pins must be set on the same level in each leg.

Selection of functions

•Rigid function – remove locking clips from the upper horizontal

element which reinforces the frame, and place them into the

openings which are located on the same height level but on the

vertical element of the frame.

•Reciprocating function – place the locking clips again into the

mounting openings on the horizontal element.

•Legs with tips or with wheels can be mounted regardless of

chosen function.

4. Technical data

Overall width with tips

Overall width with wheels

55 cm

60 cm

Inner width 46 cm

Overall depth with tips

Overall depth with wheels

47 cm

51 cm

Height adjustment 78-96 cm

Weight 2.4 kg

Maximum capacity 136 kg

5. Notes

Timago International Group does not bear responsibility of improper

use of the walker, failure to comply safety regulations and misuse.

6. Maintenance

Reviews

Systematically make a visual inspection of all the joining components

(latch, hinge) of the product including:

•the condition of height adjustment pins

•stability and look of the frame

•the condition of tubes (if cracks)

Cleaning

•Clean the frame of the walker with damp cloth using only water

and mild detergents. Dry thoroughly.

•Do not use for cleaning: strong polishing and abrasive agents,

strong detergents, bleach, petrol or solvents (it may cause frame

damage, visible defects and in consequence - loss of warranty

rights).

•Remove impurities from moving parts of the walker (hinges,

clamping screws, locks).

7. Storage and transport conditions

Device should not be exposed to direct sunlight, water or moisture.

8. Warranty information

All products distributed by our company are covered by a warranty, the

terms of which are described in the warranty card available on our

website. Please contact the retailer from whom you purchased the

product. Please, keep in mind that for warranty purposes, the proof of

purchase (receipt or invoice) should be retained

9. Labels

Reference

number

Manufacturer

LOT number

Manufacture date

Serial number

Medical device

Note

Please read the

instruction

The manufacturer checked for compliance with

essential medical devices requirements.

Our complete line of products is available from our distributors.

Learn more at: www.timago.com. Thank you for choosing Timago!

Timago International Group

Spółka z o.o. i Spółka – Spółka komandytowa

ul. Karpacka 24/12

43-316 Bielsko-Biała, Polska

T.: +48 33 499 50 00

F.: +48 33 499 50 11

E.: info@timago.com

Rev. II, date 20.05.2021
