INSTRUCTIONS FOR USE

Underarm crutch

Product code: FS 925L

1. Characteristics

The underarm crutch consists of aluminium leg with rubber tip, soft

crutch pad, and adjustable handgrip. Owing to wide range of

adjustment, the crutch can be used either by short or tall patients.

Ergonomic shape and light weight make the crutch comfortable in use.

a. Handgrip

b. Crutch pad

c. Handgrip adjustment – TF system (knob)

d. Height adjustment – locking pin

e. Rubber tip

2. Application

The underarm crutch is ancillary equipment which is used in case of

lower limb injury with simultaneous injuries of wrist or elbow. It is also

recommended to patients who need help and support while walking

for gait re-education after lower limb injuries, and it can also be used

as an aid in keeping balance in case of serious dysfunctions of lower

limbs or trunk.

Contraindications: coordination and balance disorders, advanced

rheumatic changes, injuries and dysfunctions of upper limbs which may

hinder the user to support on the crutch.

3. Adjustment

The crutch should be adjusted individually to the user so that the

shoulder joints are not excessively raised, and adjust the height of the

handgrip so that your elbow is slightly bent at the angle of

approximately 30°.

•To adjust the crutch, press the metal pin and select appropriate

position of the inner tube. Lock the position of the tubes relative

to each other with the use of metal pin. The crutch is adjustable in

2.5 cm increments.

•To adjust the height of handgrip, unscrew the knob, take out the

screws and set the handgrip on the appropriate level. Put the

screws in and tighten the knob.

•When using two crutches, handgrips and locking pins must be set

at the same level. Legs of the crutch should always stand stably on

the ground.

4. Technical data

Type:double adjustable

Colour: silver

Maximum capacity:100 kg

Size S:

Height adjustment: 94-114 cm

Crutch cane: 0.73 kg

Size M:

Height adjustment: 114-134 cm

Crutch cane: 0.8 kg

Size L:

Height adjustment: 134-154 cm

Crutch cane: 0.87 kg

5. Notes

Timago International Group does not bear responsibility of improper

use of the product, failure to comply safety regulations and misuse.

6. Cleaning and maintenance

•Clean the crutch using only water and mild detergents, dry

thoroughly.

•Do not use: strong detergents, abrasive agents, bleach, petrol nor

solvents (it may cause frame damage, visible defects, and in

consequence – loss of warranty rights).

•It is recommended to check rubber tip regularly. Replace worn tip

immediately.

7. Storage and transport conditions

Device should not be exposed to direct sunlight, water or moisture.

8. Warranty information

All products distributed by our company are covered by a warranty, the

terms of which are described in the warranty card available on our

website. Please contact the retailer from whom you purchased the

product. Please, keep in mind that for warranty purposes, the proof of

purchase (receipt or invoice) should be retained

9. Labels

Reference

number

Manufacturer

LOT number

Manufacture date

Serial number

Medical device

Note

Please read the

instruction

The manufacturer checked for compliance with

essential medical devices requirements.

Our complete line of products is available from our distributors.

Learn more at: www.timago.com. Thank you for choosing Timago!

Timago International Group

Spółka z o.o. i Spółka – Spółka komandytowa

ul. Karpacka 24/12

43-316 Bielsko-Biała, Polska

T.: +48 33 499 50 00

F.: +48 33 499 50 11

E.: info@timago.com

Rev. II, date 20.05.2021
