INSTRUCTIONS FOR USE

Forearm crutch, version with foldable cuff

Product code: FS 933L

1. Characteristics

The forearm crutch consists of aluminium leg and of durable, plastic

and ergonomic handgrip. The leg with rubber tip possesses height

adjustment in the upper and lower part of the crutch. Owing to

foldable cuff, it is possible to perform simple activities without the

need to set the crutch aside.

a. Handgrip

b. Foldable cuff

c. Upper height adjustment – locking pin

d. Lower height adjustment – locking pin

e. Rubber tip

2. Application

The forearm crutch is ancillary equipment which is used to increase the

area of support in case of patients with reduced mobility. It is also

recommended to patients who need help and support while walking

and it can also be used for gait re-education as an aid in keeping

balance after the injuries of lower limbs or trunk.

Contraindications: coordination and balance disorders, advanced

rheumatic changes, injuries and dysfunctions of upper limbs which may

hinder the user to support on the crutch.

3. Adjustment

To adjust the crutch, press the metal pin and select appropriate

position of the inner tube. Lock the position of the tubes relative to

each other with the use of metal pin. The crutch is adjustable in 2.5 cm

increments.

•To set the proper length of the crutch, stand upright and bent

upper limb in elbow joint at the angle of 20°.

•The crutch should be adjusted individually to the user so that the

handgrip is at hip joint level and the cuff is at the height of upper

part of the forearm.

•Before use, ensure that the crutch is stable and the locking pin

fully protrudes through adjustment hole of the crutch.

•It is recommended to use two crutches simultaneously.

NOTE! In case of doubts concerning the technique of moving with the

use of crutches, consult a person who has appropriate knowledge or

qualifications.

4. Technical data

Type:double adjustable

Colour: silver-grey

Maximum capacity:90 kg

Size M:

Height adjustment: 95-118 cm (126 cm)

Height to the handgrip: 71-93.5 cm

Crutch weight: 0.57 kg

Size L:

Height adjustment: 107-130 cm (138 cm)

Height to the handgrip: 83-106 cm

Crutch weight: 0.65 kg

5. Notes

Timago International Group does not bear responsibility of improper

use of the product, failure to comply safety regulations and misuse.

6. Cleaning and maintenance

•Clean the crutch using only water and mild detergents, dry

thoroughly.

•Do not use: strong detergents, abrasive agents, bleach, petrol nor

solvents (it may cause frame damage, visible defects, and in

consequence – loss of warranty rights).

•It is recommended to check rubber tip regularly. Replace worn tip

immediately.

7. Storage and transport conditions

Device should not be exposed to direct sunlight, water or moisture.

8. Warranty information

All products distributed by our company are covered by a warranty, the

terms of which are described in the warranty card available on our

website. Please contact the retailer from whom you purchased the

product. Please, keep in mind that for warranty purposes, the proof of

purchase (receipt or invoice) should be retained

9. Labels

Reference

number

Manufacturer

LOT number

Manufacture date

Serial number

Medical device

Note

Please read the

instruction

The manufacturer checked for compliance with

essential medical devices requirements.

Our complete line of products is available from our distributors.

Learn more at: www.timago.com. Thank you for choosing Timago!

Timago International Group

Spółka z o.o. i Spółka – Spółka komandytowa

ul. Karpacka 24/12

43-316 Bielsko-Biała, Polska

T.: +48 33 499 50 00

F.: +48 33 499 50 11

E.: info@timago.com

Rev. II, date 20.05.2021
