Thorlabs Instrumentation
TXP5016
Operation Manual
2017
Version:
Date:
Item No.:
3.1.5
31-Jan-2017
M0009-510-102
Copyright © 2017 Thorlabs GmbH
Foreword
Contents 2
1General Information 3
31.1 Safety
51.2 Ordering Codes and Accessories
51.3 Requirements
51.3.1 Hardware Requirements
51.3.2 Software Requirements
2Getting Started 6
62.1 Parts List
62.2 Installing Software
3Operating Elements TXP5016 10
4First Steps 11
114.1 Network Configuration
5Operating Instruction 15
155.1 Installing and Removing Modules
155.2 Global Interlock
6Maintenance and Service 18
196.1 Replacing the Line Fuse
196.2 Replacing the Internal Fuses
206.3 Troubleshooting
216.4 The TXP5000 Series Administrator
236.4.1 Connect the TXP5016 via RS232
256.4.2 Connect the TXP5016 via LAN
266.4.3 Device ID and Information
276.4.4 Network Configuration
296.4.5 Adjust Time and Date
306.4.6 Software Updates
336.4.7 Change Device Password
7 Appendix 34
347.1 Technical Data
357.2 Certifications and Compliances
367.3 Warranty
377.4 Copyright and Exclusion of Reliability
387.5 Thorlabs 'End of Life' Policy
397.6 Thorlabs Worldwide Contacts
© 2017 Thorlabs GmbH
We aim to develop and produce the best solution for your application
in the field of optical measurement technique. To help us to live up to
your expectations and improve our products permanently we need
your ideas and suggestions. Therefore, please let us know about
possible criticism or ideas. We and our international partners are
looking forward to hearing from you.
Thorlabs GmbH
Warning
Sections marked by this symbol explain dangers that might result in
personal injury or death. Always read the associated information
carefully, before performing the indicated procedure.
Please read these advices carefully!
This manual also contains "NOTES" and "HINTS" written in this form.
Attention
Paragraphs preceeded by this symbol explain hazards that could
damage the instrument and the connected equipment or may cause
loss of data.
Note
2
© 2017 Thorlabs GmbH
1 General Information
3
1 General Information
The TXP5016 16 channel Test an Measurement Platform chassis is designed to accommodate
up to 16 TXP modules. These modules are controlled by an external PC, connected via the
Ethernet interface of the TXP5016. It has a wide range power supply compatible with line
voltages between 100...240VAC, 50-60Hz.
·Small footprint with 16 module slots
·Hosts any TXP Series module
·Intelligent modules - memory / processor capacity where needed (real time apps)
·Configurable module pooling for complex measurement solutions
·Programming Interface
USB interface with LabVIEW®/ LabWindows/CVI® and C drivers
Enhanced macro function capabilities
·Remote control via Ethernet connection
·Mainframe configuration via RS232 or TCP/IP connection
1.1 Safety
Attention
All statements regarding safety of operation and technical data in this instruction manual
will only apply when the unit is operated correctly as it was designed for.
Prior to applying power to the TXP5016, make sure that the protective conductor of the 3
conductor mains power cord is correctly connected to the protective earth ground
contact of the socket outlet! Improper grounding can cause electric shock with damages
to your health or even death!
All modules must only be operated with proper shielded connection cables.
The TXP5016 must not be operated in explosion endangered environments!
Do not remove covers! Do not obstruct the air ventilation slots in the housing!
Do not open the cabinet, there are no parts serviceable by the operator inside!
Refer servicing to qualified personnel!
Only with written consent from Thorlabs GmbH may changes to single components be
made or components not supplied by Thorlabs GmbH be used.
This precision device is only serviceable if properly packed into the complete original
packaging. If necessary, ask for a replacement package prior to return.
Attention
The following statement applies to the products covered in this manual, unless
otherwise specified herein. The statement for other products will appear in the
accompanying documentation.
This equipment has been tested and found to comply with the limits for a Class Adigital
device, pursuant to part 15 of the FCC Rules and meets all requirements of the Canadian
Interference-Causing Equipment Standard ICES-003 for digital apparatus. These limits
are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own expense.
© 2017 Thorlabs GmbH4
TXP5016
Thorlabs GmbH is not responsible for any radio television interference caused by
modifications of this equipment or the substitution or attachment of connecting cables
and equipment other than those specified by Thorlabs GmbH. The correction of
interference caused by such unauthorized modification, substitution or attachment will
be the responsibility of the user.
The use of shielded I/O cables is required when connecting this equipment to any and all
optional peripheral or host devices. Failure to do so may violate FCC and ICES rules.
Attention
Mobile telephones, cellular phones or other radio transmitters are not to be used within
the range of three meters of this unit since the electromagnetic field intensity may then
exceed the maximum allowed disturbance values according to IEC 61326-1.
This product has been tested and found to comply with the limits according to
IEC 61326-1 for using connection cables shorter than 3 meters (9.8 feet).
© 2017 Thorlabs GmbH
1 General Information
5
1.2 Ordering Codes and Accessories
Ordering code:
TXP5016 16 Channel Ethernet T&M Mainframe
Accessories:
TXP5000C Blind module to cover empty module slots (for TXP5004 and TXP5016)
1.3 Requirements
These are the requirements to the PC intended to be used for remote operation of the
TXP5016.
1.3.1 Hardware Requirements
CPU: 1 GHz or higher
RAM: 256 MB
Graphic card Min. 32 MB memory
Hard disc Min 100 MB free storage space
Interface Ethernet 10/100 Mbit/s, RJ45 port.
For the administration tool a serial RS232C port is required, this can be a USB-
to-Serial converter as well.
1.3.2 Software Requirements
The TXP5016 software is compatible with the following operating systems:
·Windows®7 (32-bit, 64-bit)
·Windows®8.x (32-bit, 64-bit)
For operation of the TXP5016, also an NI-VISA (version 5.4.1 or higher) is required. This NI-
VISA engines comes with the Thorlabs GmbH TXP5016 installation software package, but can
be downloaded also from National Instruments' website www.ni.com.
© 2017 Thorlabs GmbH6
TXP5016
2 Getting Started
2.1 Parts List
Inspect the shipping container for damage.
If the shipping container seems to be damaged, keep it until you have inspected the contents
and you have inspected the TXP5016 mechanically and electrically.
Verify that you have received the following items within the package:
TXP5016
1. 16 Slot Chassis with Ethernet Control
2. Front Cover Plates TXP5000C for all unused slots
3. Patch cable, 2.0 m, Cat. 5e, RJ45
4. Cross-over patch cable, 2.0 m, Cat. 5e, RJ45
5. TXP5016 interlock plug
6. Operation Manual
7. Power Cord
2.2 Installing Software
Attention
Exit all running applications on your PC as the installer may require a reboot of your PC
during installation!
The TXP software package contains:
·NI VISA Runtime 5.4.1
·USB Drivers for TXP5001AD and TXP5004 and module slots
·Control software for TXP modules
·TXP Administration Tools
Below the software installation to a Windows 7®64 bit operating system is described.
Download the ZIP archive from our website:
https://www.thorlabs.com/software_pages/ViewSoftwarePage.cfm?Code=TXP5000
and unpack the archive. Then execute the setup.exe:
A user account control warning comes up:
© 2017 Thorlabs GmbH
2 Getting Started
7
Allow the installation. Then follow the the screenshots below:
© 2017 Thorlabs GmbH8
