thomann Millenium HD-50 Manuel utilisateur
HD-50
e-drum set
user manual
Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: +49 (0) 9546 9223-0
E-mail: [email protected]
Internet: www.thomann.de
28.07.2015, ID: 297858
Table of contents
1 General notes............................................................................................................................ 4
2 Safety notes............................................................................................................................... 5
3 Features....................................................................................................................................... 7
4 Scope of delivery..................................................................................................................... 8
5 Assembly..................................................................................................................................... 9
6 Installation.............................................................................................................................. 12
7 Connections and controls................................................................................................ 14
8 Operation................................................................................................................................. 17
8.1 Functions......................................................................................................................... 17
8.2 Factory settings............................................................................................................. 20
9 Technical data........................................................................................................................ 23
10 Cleaning.................................................................................................................................... 24
11 Protecting the environment........................................................................................... 25
12 Appendix.................................................................................................................................. 26
12.1 Kit list............................................................................................................................... 26
12.2 Song-style list............................................................................................................... 26
12.3 Sound list....................................................................................................................... 26
12.4 MIDI implementation................................................................................................ 29
Table of contents
HD-50
3
1 General notes
This user manual contains important information on safe operation of the device.
Read and follow all safety notes and all instructions. Save this manual for future refer‐
ence. Make sure that it is available to all persons using this device. If you sell the
device, include the manual for the next owner.
Our products are subject to a process of continuous development. We therefore
reserve the right to make changes without notice.
This section provides an overview of the symbols and signal words used in this user
manual.
Signal word Meaning
DANGER! This combination of symbol and signal word indicates
an immediate dangerous situation that will result in
death or serious injury if it is not avoided.
CAUTION! This combination of symbol and signal word indicates
a possible dangerous situation that can result in minor
injury if it is not avoided.
NOTICE! This combination of symbol and signal word indicates
a possible dangerous situation that can result in mate‐
rial and environmental damage if it is not avoided.
Warning signs Type of danger
Warning – danger zone.
Symbols and signal words
General notes
e-drum set
4
2 Safety notes
Drum modules are intended to be used for converting digital trigger signals from
drum pads to various percussion sounds. Use the unit only as described in this
manual. Any other use or use under other operating conditions is considered to be
improper and may result in personal injury or property damage. No liability will be
assumed for damages resulting from improper use.
This device may be used only by persons with sufficient physical, sensorial, and intel‐
lectual abilities and having corresponding knowledge and experience. Other persons
may use this device only if they are supervised or instructed by a person who is
responsible for their safety.
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and
are not within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the
like) from the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
CAUTION!
Possible hearing damage
With loudspeakers or headphones connected, the device can produce
volume levels that may cause temporary or permanent hearing impair‐
ment.
Do not operate the device permanently at a high volume level.
Decrease the volume level immediately if you experience ringing in
your ears or hearing impairment.
NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage,
never expose the device to any liquid or moisture. Avoid direct sunlight,
heavy dirt, and strong vibrations.
Intended use
Safety
Safety notes
HD-50
5
NOTICE!
External power supply
The device is powered by an external power supply. Before connecting
the external power supply, ensure that the input voltage (AC outlet)
matches the voltage rating of the device and that the AC outlet is pro‐
tected by a residual current circuit breaker. Failure to do so could result
in damage to the device and possibly the user.
Unplug the external power supply before electrical storms occur and
when the device is unused for long periods of time to reduce the risk of
electric shock or fire.
Safety notes
e-drum set
6
3 Features
n193 sounds
n10 preset drum kits, 1 user kit
n10 songs
nMetronome
nRecording and playback function
nFlexible assignment of pad sounds
nHeadphones, AUX IN and USB-MIDI interface
Features
HD-50
7
4 Scope of delivery
Verify before assembling the e-drum set that the entire delivery is included,
as listed below.
nBottom case with bass-drum pedal and hi-hat controller
n2 × stand tube (left-hand stand tube with snare drum support)
nDrum module with three toms
n2 × longer cymbal holders for ride and crash cymbals
nshorter hi-hat cymbal holder
n3 × cymbal (ride, crash and hi-hat)
nSnare drum support
nSnare drum
nComplete pad cabling
n9 V (DC) power supply unit
Scope of delivery
e-drum set
8
5 Assembly
Loosen the wing nuts on the holder clamps before inserting the tubes. Mount the
various elements in the specified sequence as shown in the illustration below.
1. Put the bottom case with the bass-drum pedal and the hi-hat controller (1) on
the floor. Insert the two stand tubes (2, with snare drum support) and (3) and
tighten the wing nuts on the holder clamps.
2. Insert the drum module with the three toms (4) into the stand tubes (2) and (3)
and tighten the holder clamps on the wing nuts.
3. Insert the two longer cymbal holders (5) and (6) for the ride and crash cymbals
and the shorter hi-hat holder (7) into the guides provided as shown in the illus‐
tration and tighten the wing nuts on the holder clamps.
Assembly
HD-50
9
4. Place the two ride and crash cymbals (8) and (9) onto the cymbal holders (5)
and (6) as shown in the illustration and tighten the corresponding wing nuts.
5. Place the hi-hat cymbal (10) onto the holder (7) as shown in the illustration and
tighten the corresponding wing nut.
6. Insert the longer end of the L-piece snare drum support (11) into the holder
clamp provided on the left-hand stand tube (2) and tighten the wing nut on
the holder clamp.
Assembly
e-drum set
10
