Independent password: can use password which irrelevant with the card to
open the door
User modification password: Users can revise the door password
Search speed: charge to open the door time less than 0.1 S.
Output short circuit protection: electric lock or alarm output circuit within 100
μS when shut down automatically output
Wiegand output: With Wiegand output interface，Wg26 card number or Wg4
buttons output
Usable keyboard delete card number: After card is lost, usable keyboard
delete card，Thoroughly eliminate safety lapses
The demolition alarm: Illegal dismantling machine, built-in alarm sound
buzzer
The bell button and interface: key and circuit segregation, external any the
doorbell.
3. Technical parameters
Work Voltage: DC9-28V
Static Current: ≤30mA
Reading Range: 3～8cm
Capacity: 2000 users
Ambient Temperature: -25～60 Degree
Ambient Humidity: 10%～90%
Electricity lock output: ≤3A
Alarm output: ≤20A
Output short circuit protection time; ≤100μS
Open time; 0 ~ 99 seconds (adjustable)
Size; 120 *56*18mm
4. Administrator operation
Restore factory settings:
Disconnect the power of the mechine,press “#” key ,at the same time conntect the
power for it,after the sound of “beep ”,then loosen” # “key. It means initialization of
machine successfully.
Note: restore factory Settings will not delete a user data
Enter administrator operation status:
Press * Administrator password # Administrator the default password: 999999
4.1 Modify administrator password:
Press 0 The new password # Repeat the new password #
Note: the administrator password for 6 ~ 8 random Numbers, please take
good care.
4.2 Add user:
4.2.1 Continuous increase card:
Press 1 Reading card ,Reading card , … #
4.2.2 Designated card No increase:
