Textron Jacobsen DS312 Supplément

WARNING: If incorrectly used this machine can cause severe injury. Those who use

and maintain this machine should be trained in its proper use, warned of its dangers

and should read the entire manual before attempting to set up, operate, adjust or

service the machine.

ASSEMBLY & OPERATIONS

MANUAL-FRONT MOUNTED

SPRAYER & ADAPTER

4128423 REV A

MODEL:

73-70675 DRIFTLESS SPRAYER DS312

CALIFORNIA

Proposition 65 Warning

Diesel engine exhaust and some of

its constituents are known to the State

of California to cause cancer, birth

defects and other reproductive harm.

Californie Proposition 65

Avertissement

Les échappements des moteurs diesel

et certains de leurs composés sont

reconnus par l’Etat de Californie pour

être cancérigènes, provoquer des

défauts congénitaux et d’autres dangers

en matière de reproduction.

ADVERTENCIA

AVERTISSEMENT

WARNING

The engine exhaust from this product

contains chemicals known to the State

of California to cause cancer, birth

defects or other reproductive harm.

California Advertencia

de la Proposicion 65

El estado de California hace saber que

los gases de escape de los motores

diesel y algunos de sus componentes

producen cáncer, defectos de

nacimiento y otros daños en el

proceso de reproducción humana.

L’

mission du moteur de ce mat

riel

contient des produits chimiques que

l’Etat de Californie consid

tre

canc

rig

nes, provoquer des d

fauts

cong

nitaux et d’autres dangers en

mati

re de reproduction.

El estado de California hace saber

que los gases de escape de este

producto contienen productos

quÍmicos que producen cáncer,

defectos de nacimiento y otros daños

en el proceso de reproducción

humana.

DRIFTLESS

SPRAYER

IMPORTANTMESSAGE

Thank you for purchasing this Jacobsen product. You have purchased a world class product, one of the best

designed and built anywhere.

This product comes with an Owner/Operator's Manual. The useful life and good service you receive from this

product depends to a large extent on how well you read and understand this manual. Treat this product properly

and adjust it as instructed, and it will give you many years of reliable service.

See a Jacobsen dealer for any service or parts needed. Jacobsen service ensures that you continue to receive

the best results possible from Jacobsen products. You can trust Jacobsen replacement parts because they are

manufactured with the same high precision and quality as the original parts.

Jacobsen designs and builds its equipment to serve many years in a safe and productive manner. For longest

life, use this product only as directed in the manual, keep it in good repair and follow safety warnings and

instructions. You'll always be glad you did.

Jacobsen, a Textron Company

One Bob Cat Lane

Johnson Creek, WI 53038-0469

1-2004

TABLE OF CONTENTS FIGURES PAGE

SAFETY ......................................................................................................................................................... 2

GENERAL SPRAYING INFORMATION ..................................................................................................... 3, 4

GENERAL MAINTENANCE ........................................................................................................................... 5

ASSEMBLY ................................................................................................................................................. 6-9

OPERATION ................................................................................................................................................ 10

PARTS SECTION .........................................................................................................................................11

CASTER FRAME PARTS .................................. FIGURE 1 ................................................................. 12, 13

WING FRAME PARTS ....................................... FIGURE 2 ................................................................. 14, 15

ELECTRICAL..................................................... FIGURE 3 ................................................................. 16, 17

PLUMBING ........................................................ FIGURE 4 ................................................................. 18, 19

ASSEMBLY-FM MOUNT .................................... FIGURE 5 ................................................................. 20, 21

INSTALLATION SHEET ..................................... FIGURE 6 ................................................................. 22, 23

CASTER WHEEL ASSEMBLY ........................... FIGURE 7 ................................................................. 24, 25

NOZZLE BODIES .............................................. FIGURE 8 ....................................................................... 26

DRIFTLESS

SPRAYER

SAFETY

GENERALSAFETY

Many people die or suffer serious injury in job related accidents every year due to carelessness. Know

your machinery and be aware of potential hazards. Put safety first in all your operations.

Review all instructions and procedures outlined in this manual annually. Every operator must familiarize

themselves with the operating instructions of the sprayer.

Operational Safety

• Shut down sprayer and power unit and wait for all parts to stop before adjusting, cleaning, or

lubricating the power unit or sprayer.

• Before spraying a field, familiarize yourself with any rocks, debris, trees, ditches or gullies that may be

potentially dangerous. Plan the spraying route to avoid these hazards. When spraying, use individual

section controls to reduce the amount of double spraying.

• Keep sprayer boom width in mind at all times. When turning, exercise caution and avoid any

obstacles or other persons.

Assembly Safety

• Clear large area to fold booms out in field position.

• A minimum of two people should be available for assembly of large equipment, especially when lifting

or exertion is required.

• Always use clean tools of the proper size and specification to match the hardware and specific job.

Transport Safety

• Never transport sprayers with castor wheels on the ground faster than 16 km/h (10 mph).

• Reduce speed on rough terrain.

• For all sprayers ensure that booms are folded and/or locked securely for transport.

Minimize Chemical Drift

The Windfoil sprayer has been designed in wind tunnels to control air flow around and behind the

sprayer to minimize drift, allowing safe spraying in windy conditions.

Drift can blow off a field after it has been sprayed, especially in high winds. Reasonable caution should be

taken, in order to spray effectively and safely.

For maximum drift control, keep curtain in contact with the canopy to ensure a seal to it. Drift

control of the Windfoil is less effective when the wind blows the curtain off the turf canopy,

breaking the seal between the curtain and the turf.

DRIFTLESS

SPRAYER GENERAL SPRAYING INFORMATION

Application Tips

Always use clean, filtered water in the sprayer tank.

Check the flow rate from all nozzles using the capacity calibration technique. See Calibration section for

tables and instructions. Adjust the sprayer pressure to get the proper flow rate.

Wilger Hose Connector Bodies

Diaphragm check valves close at 15 psi to prevent excessive dripping.

Table 1: Application rate for Spraying Systems TP Nozzle at 10 inch spacing

Calibration

As a tip wears, the spray pattern distorts, output volumes usually increase, and the droplet characteristics

change. Recalibration may correct for output changes, but cannot correct for spray pattern changes or

the drop size generated. To calibrate and operate the sprayer at the desired pressure. Collect the output

from each nozzle for 60 seconds, using an accurate measuring cup. Record the output from each nozzle.

Replace nozzles that are more than 5% above or below the average reading, or have a visibly distorted

pattern.

Actual sprayer speed, as determined from the following tables, will differ from the sprayer speedometer

readings because of wheel slippage. Run a speed test in the field to be sprayed, and have the sprayer

tank half full. The sprayer must be at full speed before starting the test run. To determine the speed

discrepancy, mark off a distance as found on one of the tables. Run the power unit over this distance,

carefully noting the speedometer reading and recording the time to cover the distance. The actual speed

traveled can be found for the specific distance and time to travel, using the table.

Liquid Capacity

Press

Number bars

800067 2.07

2.76

4.14

2.07

2.76

4.14

80015 2.07

2.76

4.14

2.07

2.76

4.14

2.07

2.76

4.14

2.07

2.76

4.14

2.07

2.76

4.14

2.07

2.76

4.14

2.07

2.76

4.14

Tip

8001

8002

8003

8004

8005

8006

8008

U.S. GALLONS PER ACRE U.S. GALLONS/1000 SQ. FT.

Press 1 nozzle 2.5 3 4 5 7 2.5 3 4 5 7

psi gpm mph mph mph mph mph mph mph mph mph mph

30 0.06 14.3 11.9 8.9 7.1 5.1 0.33 0.27 0.20 0.16 0.12

40 0.07 15.9 13.3 9.9 8.0 5.7 0.37 0.30 0.23 0.18 0.13

60 0.08 19.0 15.8 11.9 9.5 6.8 0.44 0.36 0.27 0.22 0.16

30 0.09 21.4 17.8 13.4 10.7 7.6 0.49 0.41 0.31 0.25 0.18

40 0.10 23.8 19.8 14.9 11.9 8.5 0.55 0.45 0.34 0.27 0.19

60 0.12 28.5 23.8 17.8 14.3 10.2 0.65 0.55 0.41 0.33 0.23

30 0.13 30.9 25.7 19.3 15.4 11.0 0.71 0.59 0.44 0.35 0.25

40 0.15 35.6 29.7 22.3 17.8 12.7 0.82 0.68 0.51 0.41 0.29

60 0.18 42.8 35.6 26.7 21.4 15.3 0.98 0.82 0.61 0.49 0.35

30 0.17 40.4 33.7 25.2 20.2 14.4 0.93 0.77 0.58 0.46 0.33

40 0.20 47.5 39.6 29.7 23.8 17.0 1.09 0.91 0.68 0.55 0.39

60 0.25 59.4 49.5 37.1 29.7 21.2 1.36 1.14 0.85 0.68 0.49

30 0.26 61.8 51.5 38.6 30.9 22.1 1.42 1.18 0.89 0.71 0.51

40 0.30 71.3 59.4 44.6 35.6 25.5 1.64 1.36 1.02 0.82 0.58

60 0.37 87.9 73.3 54.9 44.0 31.4 2.02 1.68 1.26 1.01 0.72

30 0.35 83.2 69.3 52.0 41.6 29.7 1.91 1.59 1.19 0.95 0.68

40 0.40 95.0 79.2 59.4 47.5 33.9 2.18 1.82 1.36 1.09 0.78

60 0.49 116 97 73 58 42 2.67 2.23 1.67 1.34 0.95

30 0.43 102 85 64 51 36 2.35 1.95 1.47 1.17 0.84

40 0.50 119 99 74 59 42 2.73 2.27 1.70 1.36 0.97

60 0.61 145 121 91 72 52 3.33 2.77 2.08 1.66 1.19

30 0.52 124 103 77 62 44 2.84 2.36 1.77 1.42 1.01

40 0.60 143 119 89 71 51 3.27 2.73 2.05 1.64 1.17

60 0.74 176 147 110 88 63 4.04 3.36 2.52 2.02 1.44

30 0.69 164 137 102 82 59 3.76 3.14 2.35 1.88 1.34

40 0.80 190 158 119 95 68 4.36 3.64 2.73 2.18 1.56

60 0.98 233 194 146 116 83 5.35 4.45 3.34 2.67 1.91

DRIFTLESS

SPRAYER

GENERAL SPRAYING INFORMATION

After the nozzles have been individually checked and matched, the sprayer should be calibrated to

determine the correct speed for the desired application volume. Refer to Table 1, for typical application

rates for different nozzles. Note nozzles listed are Spraying Systems nozzles.

Note: Tip pressure is usually less than the pressure at the pump. Losses occur in valves, hoses, etc.

Always check the flow by the above calibration method.

Table 2: Time in Seconds to Travel Distance of: Table 3: Time in Seconds to Travel a Distance of:

mph 10

(ft) 25

(ft) 50

(ft) 100

(ft) 200

(ft)

1.5

2.5

6.8 17.0 34.1 68.2 136

4.5 11.4 22.7 45.5 90.9

3.4 8.5 17.0 34.1 68.2

2.7 6.8 13.6 27.3 54.5

2.3 5.7 11.4 22.7 45.5

1.7 4.3 8.5 17.0 34.1

1.4 3.4 6.8 13.6 27.3

6 1.1 2.8 5.7 11.4 22.7

mph 10

(m) 25

(m) 50

(m) 100

(m) 200

(m)

1 36.0 90.0 180 360 720

1.5 24.0 60.0 120 240 480

2 18.0 45.0 90.0 180 360

2.5 14.4 36.0 72.0 144 288

3 12.0 30.0 60.0 120 240

4 9.0 22.5 45.0 90.0 180

5 7.2 18.0 36.0 72.0 144

6 6.0 15.0 30.0 60.0 120

DRIFTLESS

SPRAYER GENERAL MAINTENANCE

Cleaning

Sprayers need to be cleaned to prevent corrosion, cross contamination of chemicals and crop injury.

Trace amounts of one chemical can react with another or carry over to the next spraying and cause crop

damage, especially with pesticides. Long exposures with even small amounts of some chemicals can

damage sprayer components either by corrosion or deposits of gums, etc. If you spray crops that are very

susceptible to injury from the last chemical used, such as vegetables, turf, and ornamentals clean the unit

especially well.

Always try to end the day with an empty tank; avoid contamination of water supplies and injury to plants

or animals. Do not make puddles that might be accessible to children, pets, farm animals, or wildlife.

Flush with clean water, preferably after each day’s operation. However, if you plan to use the same

material over several days, most chemicals may be kept in the tank overnight; the label usually indicates

which may not. Rinse the outside of the sprayer. Surfactants combined with chemicals, when they are

compatible, will provide some cleaning action in the sprayer. Spray the rinse over the application area.

Some chemical combinations (especially if oil is used) may produce a putty type paste (buttering out) in

the sprayer tank and components; flushing with water after each load may prevent an accumulation. If

water alone does not dissolve and remove the buildup, add a low flammable solvent. Allow paste to

dissolve, then agitate and flush. Flush with detergent and finally with clean water. Check with your

chemical agent.

Whenever pesticides are changed, or before sprayer storage, clean sprayers thoroughly with a cleaning

solution. The solution used depends on the chemical to be removed from the sprayer. Check the

chemical label for cleaning instructions.

First, flush with water, then add the cleaning solution to the tank and thoroughly agitate before flushing.

Always flush with clean water to remove the cleaning solution. Remove nozzle tips and screens; clean

them in a strong detergent solution or kerosene, using a soft brush such as an old toothbrush. Never use

a metal probe to clean the orifice of a spray tip!

Follow the same safety precautions during cleaning as for applications. Use respirator, rubber gloves, or

other protective gear as may be directed by label instructions.

Sunshine

Many plastic sprayer parts are degraded by ultra violet light, especially the nozzle flow indicators. Store

the sprayer in the shade to extend the length of service.

Winterizing

After the sprayer is thoroughly cleaned, put 2 to 5 gallons of rust inhibitor or antifreeze in the tank prior to

the final flushing to help prevent corrosion. As the water is pumped from the sprayer, the antifreeze will

leave a protective coating on the inside of the tank, pump, and plumbing. Remove nozzle tips, screens

and no drip valves and store them in a can of light oil such as diesel fuel or kerosene to prevent

corrosion. Close nozzle openings with tape to prevent dirt, insects, mice, or other contaminants from

entering.

During the final cleaning, completely check the sprayer. Look at the hoses, clamps, connections, nozzle

tips, and screens for needed replacements. Store the sprayer in a reasonably clean and dry building.

DRIFTLESS

SPRAYER

ASSEMBLY

Description of Parts

Throughout this manual, parts or assemblies that perform a specific function carry an identifying name.

The following lists names used in this manual, along with a description of their appearance and function.

For further detail please refer to the general and plumbing assemblies located in the appendix.

Airfoil: The white plastic piece mounted above the spray boom that runs the entire length of the boom.

The airfoil stabilizes air flow over the spray boom.

Shroud:The large plastic body covering the sprayer. This enclosure houses the air cavity in which the

actual spraying is accomplished.

Curtain:The curtain is composed of fabric hanging down from the shroud edge. The curtain seals the air

inside the shroud.

Wing: The movable ends of the boom. The wing section breaks away from the center boom section

when the spray boom hits a large object. The wings break away to protect the object being

contacted, and the sprayer itself.

Center Frame:

The Center Frame supports the solution tank, supply pump, line strainer. The FM3500ST model

also includes the wing breakaway mechanisms and lift supports. The Center Frame attaches to

each spray boom section via float mechanisms.

Mount Adapter:

Adapts the Center Frame to fit your specific power unit.

First Checks

Your Front Mounted sprayer comes complete in one crate. The crate should include the following items:

1. Center spray section

2. Left and Right wing spray boom sections

3. Center castor frame

4. Center frame

5. Two Castor Wheel Assemblies

6. Assorted parts bag

7. Mount adapter

Look for the factory packing list attached to the shipping crate. Double check that this list has been

completely filled out and that you have all the items indicated by the list. If there are any problems

encountered please contact your dealer or the factory via the number indicated on the packing list.

DRIFTLESS

SPRAYER ASSEMBLY

Mount Adapter Attachment

Remove the Mount Adapter and associated hardware from the crate. Refer to Mount Adapter Drawing

(#12285) in the Appendix for help in identifying these parts.

1. Remove appropriate accessories from your power unit to allow your Rogers mount adapter to be

attached.

2. Refer to Specific Mount Adapter instructions for directions.

3. Refer to Mount Adapter drawing for proper orientation of Mount Adapter and attaching hardware.

4. Attach Mount Adapter to power unit.

5. Double check installation to ensure all connections are solid and that any float mechanisms are free

to operate through the entire operating range.

Tank and Boom Pull Attachment

1. Using the 1½” square u-bolts supplied attach the tank mount to the back of the 1½” tubing farthest

away from the power unit with the tank numbers facing away from the power unit. Attach the ¾”

hose with the supplied gear clamp.

2. Using the 1½” square u-bolts supplied attach the boom pull upright tubes on the appropriate sides

(refer to part 48 on drawing 12686).

3. On the right boom pull upright tube attach the eyebolt with two pulleys using the ¼” nut supplied in

the parts bag. On the left boom pull upright tube attach the eyebolt with one pulley.

4. The boom pull upright tubes contain the stand legs and a d-ring necessary for storage purposes.

Center Frame Attachment

1. Remove Center Frame from crate.

2. Place Center Frame in front of Mount Adapter. The pump and line strainer face away from the power

unit.

3. The Center Frame attaches to the Mount Adapter with 1 1/2" square U-bolts and 3/8" nylock nuts.

Refer to Mount Adapter drawing where appropriate.

Center Caster Frame Attachment

1. Remove Center Caster Frame from the crate. The Center Caster Frame includes the center boom

section.

2. Locate the two Caster Wheel Assemblies.

3. Place a Caster Wheel Assembly in each of the wheel bushings of the Center Caster Frame placing

the caster wheel spacers on the top of the bushings. The bushings are located to the extreme left and

right of the front of the Caster Frame.

4. Place the Lynch Pin into end of the caster wheel shaft.

5. Attach the Center Caster Frame to the Center frame via a 1" diameter by 6" long pin. A cotter pin is

provided to hold the 6" long pin in place.

DRIFTLESS

SPRAYER

Wing Attachment

1. Place the left and right wings to the sides of the Center Frame. The wheels of the wings will locate to

the outer rear of the sprayer and face toward the power unit.

2. Release the breakaway mechanism of the Center Frame. You may find it beneficial to strike the end

of the Breakaway Arm with a rubber mallet.

3. Loosen the Guide ring that is on the Breakaway Arm.

4. Remove the 1/4" bolts holding the Wing Pivot U-Clamp to the wing.

5. Remove the Wing Pivot U-Clamps from the wing.

6. Place the Wing Pivot U-Clamps onto the Breakaway Arm.

7. Reattach the Wing to the U-Clamps.

8. Ensure that the U-Clamp is pressed up against the inside of the Breakaway Arm.

9. Tighten the 1/4" bolts holding the Wing Pivot U-Clamp to the Breakaway Arm.

10. Lock the Guide Ring into position tight against the Wing Pivot U-Clamp closest to the power unit.

Lock with the Guide Ring set screw.

11. Locate the two ropes and handles. Run the longest rope through the left wing rope cleat and the

shorter rope through the right rope cleat and then both ropes through the half moon ring located on

the Three Valve Mount.

12. Run the longest rope to the right upright tube that has two pulley’s on it and place the rope through

one of the pulleys, then run the rope directly across to the left upright tube, through the pulley and

down to the left wing rope pull tab. Run the shortest rope to the right upright tube, through the pulley

and down to the right wing rope pull tab.

13. Tie a tight knot in the very end of the rope. Pull rope back out of the Rope Tab until the knot is tight

against the Rope Tab.

Plumbing Hookup

1. Locate the Three Valve Mount that holds the On/Off control valves for each spray section and the

pressure regulating valve. Attach the cross plate supplied in the parts bag to the Three Valve Mount

with ¼” square u-bolts. Attach Mount to upright on the Center frame with 1 1/2" square U-bolts.

2. Adjust height of controls to suit your power unit and user preference. Use the supplied tie straps to

secure the hoses in the appropriate place.

3. Attach the Universal Mount Bracket and Nozzle Flow Indicator for the Center Boom Section using the

¼” x 2" lg bolts supplied to the support on the solution tank.

4. Locate the three 1/2" hoses from the Center Boom Section. Cut to desired length and hook the end of

each hose to the hose barbs on the nozzle flow indicator. To avoid confusion, ensure that the position

that each hose exits the shroud of the spray boom corresponds with the position it is installed on the

nozzle flow indicator. Plastic, crimp type hose clamps are located in the parts box.

5. Attach wing supply hoses to the appropriate wings placing the supply hose underneath the

breakaway arm. Attach the center nozzle flow indicator supply hose and also the bypass hose to the

top of the solution tank. Use the plastic crimp type hose clamps to secure to hose barbs.

ASSEMBLY

Ce manuel convient aux modèles suivants

Table des matières

Manuels Pistolet à peinture populaires d'autres marques

SNOWJOE

SNOWJOE Sunjoe 24V-GS-LTW-RM Manuel utilisateur

Graco

Graco 246737 Manuel d'utilisation et d'entretien

Binks

Binks SV100 Manuel utilisateur

Fimco

Fimco LG-4-3-1 Manuel utilisateur

AG SPRAY

AG SPRAY FS-ATV-25BL Manuel utilisateur

Nordson

Nordson MicroMax 2 Manuel utilisateur

Bonide

Bonide 051 Manuel d'utilisation

zogics

zogics Z-DAS Manuel utilisateur

KISANKRAFT

KISANKRAFT KK-KBS-165 Manuel utilisateur

Matrix

Matrix SG 650 Manuel utilisateur

Anest Iwata

Anest Iwata SGA-3 Guide de démarrage rapide

paasche

paasche VV Fiche technique

Carlisle

Carlisle DeVilbiss JGA-510 Manuel utilisateur

Gardena

Gardena 11120 Manuel utilisateur

Conrad

Conrad Hobby Airbrush K3 Manuel utilisateur

wiwa

wiwa 14025 R/F Manuel utilisateur

Graco

Graco EM 390 Manuel d'utilisation

DeVilbiss

DeVilbiss LUNA2i Manuel utilisateur
