Textron LF-128 Mode d’emploi

TURF CARE AND SPECIALTY PRODUCTS

BOB-CAT • BUNTON • CUSHMAN • JACOBSEN • RANSOMES • RYAN

WARNING: If incorrectly used this machine can cause severe injury. Those who use

and maintain this machine should be trained in its proper use, warned of its dangers

and should read the entire manual before attempting to set up, operate, adjust or ser-

vice the machine.

Litho in U.S.A. 1199 Part No. 2811252

Safety &

Operation

Manual

LF-128™

Fairway Mower

Kubota D1105-EB

Diesel Engine

2WD Model 67818

4WD Model 67819

CONTENTS

Proposition 65 Warning

Diesel engine exhaust and some of its

constituents are known to the State of

California to cause cancer, birth

defects, and other reproductive harm

All information in this publication is based on information available at time of approval for printing. Textron Turf Care And

Specialty Products reserves the right to make changes at any time without notice and without incurring any obligation.

CONTENTS

SAFETY

1.1 Operating Safety . . . . . . . . . . . . . . . . . . . . . 3

1.2 Important Safety Notes . . . . . . . . . . . . . . . . .4

DECALS

CONTROLS

3.1 Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

3.2 Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

3.3 Control Panel . . . . . . . . . . . . . . . . . . . . . . . .10

3.4 Operator Alerts . . . . . . . . . . . . . . . . . . . . . .11

OPERATION

4.1 Daily Inspection . . . . . . . . . . . . . . . . . . . . . 12

4.2 Operator Back-up System . . . . . . . . . . . . . 12

4.3 Operating Procedures . . . . . . . . . . . . . . . . 13

4.4 Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

4.5 Stopping / Parking . . . . . . . . . . . . . . . . . . . 14

4.6 To Drive / Transport . . . . . . . . . . . . . . . . . . 15

4.7 Mowing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

4.8 Towing / Trailering . . . . . . . . . . . . . . . . . . . 16

4.9 Hillside Operation . . . . . . . . . . . . . . . . . . . . 16

4.10 Wing Stops . . . . . . . . . . . . . . . . . . . . . . . . . 17

4.11 Daily Maintenance . . . . . . . . . . . . . . . . . . . 17

NOTES

SAFETY 1

1 SAFETY

1.1 OPERATING SAFETY ______________________________________________________

1. Safety is dependent upon the awareness, concern and

prudence of those who operate or service the equip-

ment. Never allow minors to operate any equipment.

2. It is your responsibility to read this manual and all

publications associated with this equipment (Parts &

Maintenance manual, engine manual, accessories and

attachments). If the operator can not read English it is

the owner’s responsibility to explain the material

contained in this manual to them.

3. Learn the proper use of the machine, the location and

purpose of all the controls and gauges before you

operate the equipment. Working with unfamiliar

equipment can lead to accidents.

4. Never allow anyone to operate or service the machine

or its attachments without proper training and

instructions; or while under the influence of alcohol or

drugs.

5. Wear all the necessary protective clothing and

personal safety devices to protect your head, eyes,

ears hands and feet. Operate the machine only in

daylight or in good artificial light.

6. Inspect the area where the equipment will be used.

Pick up all the debris you can find before operating.

Beware of overhead obstructions (low tree limbs,

electrical wires, etc.) and also underground obstacles

(sprinklers, pipes, tree roots, etc.) Enter a new area

cautiously. Stay alert for hidden hazards.

7. Never direct discharge of material toward bystanders,

nor allow anyone near the machine while in operation.

The owner/operator can prevent and is responsible for

injuries inflicted to themselves, to bystanders and

damage to property.

8. Never operate equipment that is not in perfect working

order or is without decals, guards, shields, discharge

deflectors or other protective devices securely fastened

in place.

9. Never disconnect or bypass any switch.

10. Carbon monoxide in the exhaust fumes can be fatal

when inhaled. Never operate the engine without proper

ventilation.

11. Fuel is highly flammable, handle with care.

12. Keep the engine clean. Allow the engine to cool before

storing and always remove the ignition key.

13. Disengage all drives and engage parking brake before

starting the engine (motor). Start the engine only when

sitting in operator’s seat, never while standing beside

the unit.

14. Equipment must comply with the latest federal, state,

and local requirements when driven or transported on

public roads.

15. Never use your hands to search for oil leaks. Hydraulic

fluid under pressure can penetrate the skin and cause

serious injury.

16. Operate the machine up and down the face of the

slopes (vertically), not across the face (horizontally).

17. To prevent tipping or loss of control, do not start or

stop suddenly; reduce speed when making sharp

turns. Use caution when changing direction on slopes.

18. Always use the seat belt when operating tractors

equipped with a ROPS.

Never use a seat belt when operating tractors

without a ROPS.

19. Keep legs, arms and body inside the seating

compartment while the vehicle is in motion.

This machine is to be operated and maintained as specified in this manual and is intended for the professional

maintenance of specialized turf grasses. It is not intended for use on rough terrain or long grasses.

WARNING

EQUIPMENT OPERATED IMPROPERLY OR BY UNTRAINED PERSONNEL CAN BE DANGEROUS.

Familiarize yourself with the location and proper use of all controls. Inexperienced operator’s should receive instruction

from someone familiar with the equipment before being allowed to operate the machine.

1 SAFETY

1.2 IMPORTANT SAFETY NOTES _______________________________________________

This safety alert symbol is used to alert you to potential hazards.

DANGER - Indicates an imminently hazardous situation which, if not avoided, WILL result in death or serious injury.

WARNING - Indicates a potentially hazardous situation which, if not avoided, COULD result in death or serious injury.

CAUTION - Indicates a potentially hazardous situation which, if not avoided, MAY result in minor or moderate injury and

property damage. It may also be used to alert against unsafe practices.

For pictorial clarity, some illustrations in this manual may show shields, guards or plates open or removed. Under no

circumstances should this equipment be operated without these devices securely fastened in plac

By following all instructions in this manual, you will prolong the life of your machine and maintain its maximum efficiency.

Adjustments and maintenance should always be performed by a qualified technician.

If additional information or service is needed, contact your Authorized Textron Turf Care And Specialty Products Dealer who

is kept informed of the latest methods to service this equipment and can provide prompt and efficient service. Use of other

than original or authorized Textron Turf Care And Specialty Products parts and Accessories will void the warranty.

WARNING

The operator back-up system on this tractor prevents the tractor from starting

unless the brake pedal is engaged and mower switch is off. The system will stop

the engine if the operator leaves the seat without engaging the parking brake and

setting the mower switch off.

NEVER operate tractor unless the operator back-up system is working.

WARNING

1. Before leaving the operator’s position for any reason:

a. Return traction pedal to neutral.

b. Disengage all drives.

c. Lower all implements to the ground.

d. Engage parking brake.

e. Stop engine and remove the ignition key.

2. Keep hands, feet, and clothing away from moving parts. Wait for all

movement to stop before you clean, adjust or service the machine.

3. Keep the area of operation clear of all bystanders and pets.

4. Never carry passengers, unless a seat is provided for them.

5. Never operate mowing equipment without the discharge deflector securely

fastened in place.

DECALS 2

2 DECALS

Familiarize yourself with the decals they are critical to the safe operation of the machine.

REPLACE DAMAGED DECALS IMMEDIATELY.

To prevent burns, do not touch

muffler or muffler shield.

Temperature may exceed 150°F (66°C).

!WARNING

339237

!CAUTION

1. Read operator’s manual before operating

machine.

2. Keep shields in place and hardware

securely fastened.

3. Before you clean, adjust or repair this

equipment, disengage all drives, engage

parking brake and stop engine.

4. Keep hands, feet and clothing away from

moving parts.

5. Never carry passengers.

6. Keep bystanders away. 361854

1. No opere esta maquina sin previo

entrenamiento, instruccion y sin haber

leido el manual de operacion.

2. Tenga todas las guardas en su lugar y

plezas bien aseguradas.

3. Neutralice todas las velocidades y

apague el motor antes de vaciar los

recolectores de pasto, darie servicio,

limplar, ajustar y destrabar la maquina.

4. Mantenga las manos, los ples y ropa

suelta lejos de plezas en movimiento.

5. No deberan transportar pasajeros si no

existe un asiento para ellos.

6. Si no sabe leer ingles, pida que aiguien

le lea las calcomanias de avisos y los

manuales de instruccion y operacion.

!PRECAUCION

340623

Lower reels before emptying grass catchers.

This machine is equipped with an operator backup

(Interlock) system. The engine will quit running when the

operator leaves the seat unless the parking brake is

latched and mower switch is in the off position.

Fit ROPS before using machine on slopes greater

than 15°. Do not use on slopes greater than 23°.

Keep bystanders away.

!WARNING

3002295

To prevent injury:

• Always connect red battery cable

to the positive (+) post FIRST and

the black cable to negative (-)

post LAST.

• When removing the battery always

remove negative (-) cable FIRST

and positive (+) cable LAST.

• Avoid contact with battery acid.

• Keep sparks and flames away

from the battery.

• Do not short circuit battery posts.

Do not touch frame or negative

terminal when working on positive

terminal.

To install the battery:

1. Install battery with terminals toward frame cen-

ter.

2. Secure battery to support

3. Connect positive (+) (red) FIRST.

4. Connect Negative (-) (black) LAST.

To use jumper cables:

1. Stop the engine on vehicle with good battery

2. Connect RED cable to positive (+) terminal on

good battery and positive (+) terminal on dis-

charged battery.

3. Connect the BLACK cable from the negative (-)

terminal on good battery to frame of vehicle

with discharged battery.

4. Start the engine.

!DANGER !CAUTION

336640

2 DECALS

RADIATOR IS UNDER PRESSURE. REMOVE

CAP SLOWLY TO AVOID BODILY INJURY.

!WARNING

365956

Always keep hands and clothing far away from powered

reels to prevent severe bodily injury. Reels may turn

slowly with bypass valves open. Never Backlap reels with

the engine running in an enclosed building

BACKLAPPING PROCEDURE:

1. Engage Parking brake.

2. Attach remote backlapping hose quick disconnect to

desired circuit and open bypass valves.

3. Engage master backlapping switch located under

seat pan.

4. Set desired rocker switch to reverse; set other rocker

switch in center (OFF) position.

5. Start Engine and set throttle to minimum idle speed.

6. Engage mower switch for backlapping. The reels may

rotate slowly with bypass valve open.

7. Slowly close bypass valve for reels to be backlapped

until reels rotate at the desired speed.

8. With extreme caution, apply lapping compound with

long handled brush.

!DANGER

3002360

!WARNING

365339

To prevent serious injury

never disconnect or tamper

with the seat switch.

Read manual for more information.

To prevent injury, disengage all

drives, engage parking brake

and stop engine before

working on machine or

emptying grass catchers.

!DANGER

361877

CONTROLS 3

3 CONTROLS

3.1 ICONS ___________________________________________________________________

WARNING

Never attempt to drive the tractor unless you have read the Operator’s Manual and know how to

operate all controls correctly.

Familiarize yourself with the icons shown above and what they represent. Learn the location and

purpose of all the controls and gauges before operating this tractor.

Read Manual High Low

Engine Throttle

Reel Rotation

2-WD 4-WD

Forward Reverse

Drive

Travel

Off Run

Engine Start

Parking Brake

Forward

(Cut) Reverse

(Backlap)

Coolant

Temperature

Reels

Lower Raise

Hour Meter Oil Level Switch

On Off/Test

Engine Oil

Pressure Circuit

Breaker Coolant

Temperature Fuel

HydraulicOil

Level

Wing Mowers

Center Mowers

Miscellaneous

Disengaged

Engaged

On Off

Glow Plugs

Mower Switch

Enable Disable

3 CONTROLS

10 12 14 16

ASeat Adjusting Lever

BParking Brake

CLift /Lower Pedal

DMow Speed Pedal

ETraction Pedal - Forward

FTraction Pedal - Reverse

GTow Valve

HHydraulic Expansion Tank

IFuel Cap

JAir Cleaner Indicator

KBacklap Switch

LWing Mower Switch

MCenter Mower Switch

NHyd. Oil Level Light

OHyd. Oil Level Test Switch

PGlow Plug Switch

QMower Switch

R2 WD / 4 WD

SVoltmeter

THour Meter

UTemperature Gauge

VEngine Oil Light

WEngine Throttle

XIgnition Switch

CONTROLS 3

3.2 CONTROLS_______________________________________________________________

Seat Control

Pull left side lever out to adjust seat forward or

backward. To adjust spring tension under seat turn

adjusting knob on front of seat.

Parking Brake Pedal / Parking Brake Lock

To lock parking brake, depress brake pedal (B1)and

lock latch (B2) with your heel. To disengage, press

brake pedal until latch (B3)disengages.

Note:

With parking brake engaged, the traction pedal is

locked in the neutral position.

Figure 3A

Lift /Lower Pedal

Depress front of pedal to lower the lift arms. Keep pedal

depressed until the cylinders are fully extended to allow

proper “float” of the mower.

To lift mowers, depress rear of pedal until mowers are

fully raised.

Mow Speed Pedal

Limits forward speed while mowing. To operate at lower

travel speed while mowing, rotate lever so it contacts

stop screw (Position D1) and depress both the traction

and mow speed pedal. To travel at full speed, set lever

in position shown (D3) or only depress traction pedal.

Stop screw (D2)can be adjusted to set specific mow

speeds. See Parts & Maintenance Manual.

Forward Travel (Traction Pedal)

Press front of pedal down for forward travel. Release

pedal to slow tractor and stop.

Reverse Travel (Traction Pedal)

Press rear of pedal down for reverse travel. Release

pedal to slow tractor and stop. Allow tractor to come to a

complete stop before reversing directions.

Figure 3B

Tow Valve

Places tractor in free wheel mode. Only use when

towing. See 4.8.

Hydraulic Expansion Tank

Fill to Cold mark on tank using clean hydraulic fluid

while machine is cool. Do not overfill

Fuel Cap

Fill fuel tank with No. 2 diesel fuel, minimum cetane

rating of 45. Section 4.11

Air Cleaner Indicator

Indicates condition of air cleaner on engine. Clean or

replace air filter when red band appears in clear window

of indicator. See Parts & Maintenance Manual

Backlap Switch

The backlap switch allows the reels to rotate in reverse

for backlapping.

Forward - For normal operation (mowing) the

switch must be set to the FORWARD (cut)

position.

Reverse - When backlapping the reel must be

operated in the reverse direction. Set switch to

the REVERSE (backlap) position.

When backlapping the parking brake must be set and

both the mower switches (L and/or M) and backlap

switch (K) must be set to reverse. See Parts &

Maintenance Manual

3 CONTROLS

3.3 CONTROL PANEL _________________________________________________________

Wing Mower Switch

Engages or disengages wing mowers. Depress front of

switch for forward rotation. Depress rear of switch for

reverse rotation. Place switch in center position to

disengage wing mowers.

Center Mower Switch

Engages or disengages center and rear mowers.

Depress front of switch for forward rotation. Depress

rear of switch for reverse rotation. Place switch in center

position to disengage mowers.

Hydraulic Oil Level Light

Alerts the operator of a low fluid level in hydrau-

lic tank. This light operates in combination with

the alarm. See Section 3.4.

Note:

The warning light will remain on as long as a low

oil level is detected. If the alarm sounds due to low oil

level, it can be disabled by turning switch

(O)

to OFF.

Low Oil Level Test Switch

This switch is used to test the alarm system or

disable the alarm after a low oil level has been

detected. Keep switch in its ON position when

starting and operating tractor. To test alarm, set switch

to OFF and turn ignition key to RUN. See Section 3.4.

Glow Plug Switch

Press switch forward to energize the glow plugs. See

Section 4.4.

Mower Switch

Used to enable or disable reel switches (L and M). Lift

toggle lever then push forward to engage. Pull back to

disengage. Set main reel switch in disengaged position

to start engine.

2WD / 4WD Switch

Sets tractor into two or four wheel drive.

Voltmeter

Indicates battery condition and charge level.

Hour Meter

Records engine operating hours. Use hour meter to

schedule periodic maintenance.

Temperature Gauge

Indicates engine coolant temperature. Normal operating

temperature should be between 160° - 230°F (71°-

110°C). See Section 3.4.

Engine Oil Light

Will light if engine oil pressure falls below a safe level.

Alerts the operator to condition requiring immediate

action. See Section 3.4.

Engine Throttle

Controls engine speed. Run machine at full throttle

during normal machine operation.

Ignition Switch

The ignition switch has three positions. OFF-RUN-

START. See Section 4.4.

3.4 OPERATOR ALERTS_______________________________________________________

10 12 14 16

Figure 3

Table des matières

Autres manuels Textron Tondeuse à gazon

Textron

Textron Jacobsen 32038 Manuel utilisateur

Textron

Textron Ransomes Jacobsen HR3806 Series Manuel utilisateur

Textron

Textron RANSOMES FRONT-LINE 933 Caractéristiques techniques

Textron

Textron Jacobsen Super LF 1880 Fairway Mower with... Mode d’emploi

Textron

Textron JACOBSEN PGM Series Manuel utilisateur

Textron

Textron Jacobsen Fairway 250 Mode d’emploi

Textron

Textron Jacobsen MH5 Mode d’emploi

Textron

Textron Jacobsen HR800 Mode d’emploi

Textron

Textron JACOBSEN LF 3400 Mode d’emploi

Textron

Textron JACOBSEN PGM Series Manuel utilisateur

Textron

Textron JACOBSEN RC466 Guide de configuration

Textron

Textron Ransomes 933304H Manuel utilisateur

Textron

Textron JACOBSEN GP400 Manuel utilisateur

Textron

Textron BOB-CAT 930022 Manuel utilisateur

Textron

Textron JACOBSEN Turf Groomer 67911 Manuel utilisateur

Textron

Textron Ransomes 933303H Manuel utilisateur

Textron

Textron Jacobsen Ryan LAWNAIRE IV Manuel utilisateur

Textron

Textron BOB-CAT ZT 220D Series Manuel utilisateur

Textron

Textron Ransomes DM Hydraulic 5/7 Mk4 Mode d’emploi

Textron

Textron JACOBSEN JZT 1250 CUTTERDECKS Manuel utilisateur

Textron

Textron RANSOMES JACOBSEN Greens King IV Manuel de service

Textron

Textron JACOBSEN R-311 Mode d’emploi

Textron

Textron RANSOMES G-Plex II Manuel utilisateur

Textron

Textron Jacobsen Turfcat T628D 2WD 2 RM Mode d’emploi

Manuels Tondeuse à gazon populaires d'autres marques

RHINO

RHINO 1958 Manuel utilisateur

Wolf Garten

Wolf Garten Compact plus 40 B Manuel utilisateur

Cub Cadet

Cub Cadet LTX 1045 Manuel utilisateur

Craftsman

Craftsman 917.378461 Manuel utilisateur

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Manuel utilisateur

Challenge

Challenge CH18V2 Instructions de fonctionnement

TALEN TOOLS

TALEN TOOLS AVR HGM30 Manuel utilisateur

DEWEZE

DEWEZE ATM-725 Manuel d'utilisation

Weed Eater

Weed Eater 180083 Manuel utilisateur

Husqvarna

Husqvarna Poulan Pro PP185A42 Manuel utilisateur

Better Outdoor Products

Better Outdoor Products Quick Series Manuel utilisateur

Cub Cadet

Cub Cadet 23HP Z-Force 60 Manuel d'utilisation

MTD

MTD 795, 792, 791, 790 Manuel utilisateur

Toro

Toro Groundsmaster 3505-D Manuel utilisateur

Dennis

Dennis FT 610 Manuel utilisateur

AIRFORCE

AIRFORCE F-15 Gen 3 Manuel utilisateur

MTD

MTD 126-220-000 Manuel utilisateur

Toro

Toro 74806 Manuel utilisateur
