Texas Instruments THS4601EVM Manuel utilisateur

THS4601EVM

October 2002 High Performance Linear Products

User’s Guide

SLOU150

IMPORTANT NOTICE

Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications,

enhancements, improvements, and other changes to its products and services at any time and to discontinue

any product or service without notice. Customers should obtain the latest relevant information before placing

orders and should verify that such information is current and complete. All products are sold subject to TI’s terms

and conditions of sale supplied at the time of order acknowledgment.

TI warrants performance of its hardware products to the specifications applicable at the time of sale in

accordance with TI’s standard warranty. Testing and other quality control techniques are used to the extent TI

deems necessary to support this warranty. Except where mandated by government requirements, testing of all

parameters of each product is not necessarily performed.

TI assumes no liability for applications assistance or customer product design. Customers are responsible for

their products and applications using TI components. To minimize the risks associated with customer products

and applications, customers should provide adequate design and operating safeguards.

TI does not warrant or represent that any license, either express or implied, is granted under any TI patent right,

in which TI products or services are used. Information published by TI regarding third-party products or services

does not constitute a license from TI to use such products or services or a warranty or endorsement thereof.

Use of such information may require a license from a third party under the patents or other intellectual property

of the third party, or a license from TI under the patents or other intellectual property of TI.

Reproduction of information in TI data books or data sheets is permissible only if reproduction is without

alteration and is accompanied by all associated warranties, conditions, limitations, and notices. Reproduction

of this information with alteration is an unfair and deceptive business practice. TI is not responsible or liable for

such altered documentation.

Resale of TI products or services with statements different from or beyond the parameters stated by TI for that

product or service voids all express and any implied warranties for the associated TI product or service and

is an unfair and deceptive business practice. TI is not responsible or liable for any such statements.

Mailing Address:

Texas Instruments

Post Office Box 655303

Dallas, Texas 75265

EVM IMPORTANT NOTICE

Texas Instruments (TI) provides the enclosed product(s) under the following conditions:

This evaluation kit being sold by TI is intended for use for ENGINEERING DEVELOPMENT OR EVALUATION

PURPOSES ONLY and is not considered by TI to be fit for commercial use. As such, the goods being provided

may not be complete in terms of required design-, marketing-, and/or manufacturing-related protective

considerations, including product safety measures typically found in the end product incorporating the goods.

As a prototype, this product does not fall within the scope of the European Union directive on electromagnetic

compatibility and therefore may not meet the technical requirements of the directive.

Should this evaluation kit not meet the specifications indicated in the EVM User’s Guide, the kit may be returned

within 30 days from the date of delivery for a full refund. THE FOREGOING WARRANTY IS THE EXCLUSIVE

WARRANTY MADE BY SELLER TO BUYER AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED,

IMPLIED, OR STATUTORY, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR ANY

PARTICULAR PURPOSE.

The user assumes all responsibility and liability for proper and safe handling of the goods. Further, the user

indemnifies TI from all claims arising from the handling or use of the goods. Please be aware that the products

received may not be regulatory compliant or agency certified (FCC, UL, CE, etc.). Due to the open construction

of the product, it is the user’s responsibility to take any and all appropriate precautions with regard to electrostatic

discharge.

EXCEPT TO THE EXTENT OF THE INDEMNITY SET FORTH ABOVE, NEITHER PARTY SHALL BE LIABLE

TO THE OTHER FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES.

TI currently deals with a variety of customers for products, and therefore our arrangement with the user is not

exclusive.

TI assumesno liability for applications assistance, customer product design, software performance, or

infringement of patents or services described herein.

Please read the EVM User’s Guide and, specifically, the EVM Warnings and Restrictions notice in the EVM

User’s Guide prior to handling the product. This notice contains important safety information about temperatures

and voltages. For further safety concerns, please contact the TI application engineer.

Persons handling the product must have electronics training and observe good laboratory practice standards.

No license is granted under any patent right or other intellectual property right of TI covering or relating to any

machine, process, or combination in which such TI products or services might be or are used.

Mailing Address:

Texas Instruments

Post Office Box 655303

Dallas, Texas 75265

EVM WARNINGS AND RESTRICTIONS

It is important to operate this EVM within the specified input and output ranges described in

the EVM User’s Guide.The input supply voltage (VS) should be 5 V minimum and no

greater than 15 V. Differential input signal should be no greater than 4 V. The output

current (IO) should be no greater than 100 mA.

Exceeding the specified input range may cause unexpected operation and/or irreversible

damage to the EVM. If there are questions concerning the input range, please contact a TI

field representative prior to connecting the input power.

Applying loads outside of the specified output range may result in unintended operation and/or

possible permanent damage to the EVM. Please consult the EVM User’s Guide prior to

connecting any load to the EVM output. If there is uncertainty as to the load specification,

please contact a TI field representative.

During normal operation, some circuit components may have case temperatures greater than

60°C. The EVM is designed to operate properly with certain components above 60°C as long

as the input and output ranges are maintained. These components include but are not limited

to linear regulators, switching transistors, pass transistors, and current sense resistors. These

types of devices can be identified using the EVM schematic located in the EVM User’s Guide.

When placing measurement probes near these devices during operation, please be aware

that these devices may be very warm to the touch.

Mailing Address:

Texas Instruments

Post Office Box 655303

Dallas, Texas 75265

Information About Cautions and Warnings

Preface

Read This First

Information About Cautions and Warnings

This book may contain cautions and warnings.

This is an example of a caution statement.

A caution statement describes a situation that could potentially

damage your software or equipment.

This is an example of a warning statement.

A warning statement describes a situation that could potentially

cause harm to you.

The information in a caution or a warning is provided for your protection.

Please read each caution and warning carefully.

FCC Warning

This equipment is intended for use in a laboratory test environment only. It gen-

erates, uses, and can radiate radio frequency energy and has not been tested

for compliance with the limits of computing devices pursuant to subpart J of

part 15 of FCC rules, which are designed to provide reasonable protection

against radio frequency interference. Operation of this equipment in other en-

vironments may cause interference with radio communications, in which case

the user at his own expense will be required to take whatever measures may

be required to correct this interference.

Trademarks

Electrostatic Sensitive Components

This EVM contains components that can potentially be damaged by

electrostatic discharge, Always transport and store the EVM in its

supplied ESD bag when not in use. Handle using an antistatic

wristband. Operate on an anti-static work surface. For more

information on proper handling, refer to SSYA008.

Related Documentation From Texas Instruments

The URL’s below are correct as of the date of publication of this manual. Texas

Instruments applications apologizes if they change over time.

-THS4601 data sheet (literature number SLOS388)

-Application report (literature number SLMA002), Power Pad Thermally

Enhanced Package,

http://www-s.ti.com/sc/psheets/slma004/slma002.pdf

-Application report (literature number SLMA004), Power Pad Made Easy,

http://www-s.ti.com/sc/psheets/slma004/slma004.pdf

-Application report (literature number SSYA008), Electrostatic Discharge

(ESD), http://www-s.ti.com/sc/psheets/ssya008/ssya008.pdf

-Application report (literature number SLOA102), High Speed PCB Layout

Tips, http://www-s.ti.com/sc/psheets/sloa102/sloa102.pdf

Trademarks

PowerPAD is a trademark of Texas Instruments.

Contents

vii

Contents

1 Introduction and Description 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.1 Evaluation Schematic 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2 Using the EVM 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3 EVM Applications 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1 Noninverting Gain Stages 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2 Inverting Gain Stages 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.3 Transimpedance Amplifier 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.4 T-Network Gain Stages 3-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.5 Transimpedance Networks 3-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4 EVM Hardware Description 4-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents

viii

Figures

1-1 Schematic of the THS4601EVM 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-1 Test Equipment Connections 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-1 Default Configuration—DC-Coupled, Dual Power Supply, Non-Inverting Gain Stage 3-1. . .

3-2 AC-Coupled, Single Power Supply, Noninverting Gain Stage 3-2. . . . . . . . . . . . . . . . . . . . . . .

3-3 DC-Coupled, Dual Power Supply, Inverting Gain Stage 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-4 AC-Coupled, Single Power Supply, Inverting Gain Stage 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . .

3-5 Wideband Photodiode Transimpedance Amplifier 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-6 Parasitic Capacitances in Photodiode Applications 3-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-7 Transimpedance Circuit Bode Plot 3-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-8 Transimpedance Gains 3-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-9 Simplified EVM Schematic for Inverting Gain 3-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-10 SimplifiedEVM Schematic for Noninverting Gain 3-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-11 Single Real Pole 3-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-12 Single Real Zero 3-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-13 Single Real Pole and Single Real Zero (Second Configuration) 3-11. . . . . . . . . . . . . . . . . . . .

3-14 Two Real Poles, One Real Zero 3-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-15 One Real Pole, Two Complex Zeros 3-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4-1 Board Layout Views 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Tables

4-1 THS4601EVM Bill of Materials 4-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-1

Introduction and Description

This EVM provides a platform for testing the THS4601 in 8-pin SOIC

PowerPADt(DDA) package. It contains the high-speed op amp, a number of

passive components, and various features and footprints that enable the user

to experiment, test, and verify various operational amplifier circuit

implementations.

Chapter 1

Evaluation Schematic

1-2

1.1 Evaluation Schematic

As delivered, the EVM has a fully functional example circuit—just add power

supplies, a signal source, and monitoring instrument. See Figure 1-1 for a

complete schematic diagram. EVM features include:

-Wide operating supply voltage range: ±5 V to ±15 V operation (see the

device data sheet)

-Inverting and noninverting gain configurations supported

-Single supply capability—R5 through R7 to provide internal or external

reference to the noninverting input

-Z1 through Z3 for ac coupling

-Nominal 50-Ωinput impedance (R2 or R1). Termination can be configured

according to the application requirement.

-1-kΩ load resistor R8. 1-kΩis the standard data sheet load impedance.

-Footprints for a series resistor (Z3) or an A/D compensation network (Z3

and Z9)

-T-network in the feedback path can also be used to implement

transimpedance networks

-Power supply ripple rejection capacitors (C3 and C6)

-Decoupling capacitors (C4, C5, C7, C8, C9, C10)

-Test point for connection of a high impedance scope probe to op amp

output (TP3)

-Convenient GND test points (TP1 and TP2)

-PowerPAD heatsinking capability

-A good example of high-speed amplifier PCB design and layout

Table des matières

Autres manuels Texas Instruments Carte mère

Texas Instruments

Texas Instruments BQ25611D Manuel utilisateur

Texas Instruments

Texas Instruments PCM6 0Q1EVM-PDK Series Manuel utilisateur

Texas Instruments

Texas Instruments DP83TC812EVM-MC Manuel utilisateur

Texas Instruments

Texas Instruments LM66200EVM Manuel utilisateur

Texas Instruments

Texas Instruments BoosterPack AM2 BLDC Series Manuel utilisateur

Texas Instruments

Texas Instruments Tiva C Series Manuel utilisateur

Texas Instruments

Texas Instruments TPS23882B1EVM Manuel utilisateur

Texas Instruments

Texas Instruments ADS1278EVM-CVAL Manuel utilisateur

Texas Instruments

Texas Instruments ISO1644DWEVM Manuel utilisateur

Texas Instruments

Texas Instruments Chipcon CC2430DB Manuel utilisateur

Texas Instruments

Texas Instruments TLV3801EVM Manuel utilisateur

Texas Instruments

Texas Instruments TPD1E01B04 Manuel utilisateur

Texas Instruments

Texas Instruments LP8754EVM Manuel utilisateur

Texas Instruments

Texas Instruments TPS3899EVM Manuel utilisateur

Texas Instruments

Texas Instruments TLV3607 Manuel utilisateur

Texas Instruments

Texas Instruments TPS543620 Manuel utilisateur

Texas Instruments

Texas Instruments LMK5C33216EVM Manuel utilisateur

Texas Instruments

Texas Instruments DAC7562EVM Manuel utilisateur

Texas Instruments

Texas Instruments TRF4903 Manuel utilisateur

Texas Instruments

Texas Instruments TPS543820EVM Manuel utilisateur

Texas Instruments

Texas Instruments ADS79 EVM-PDK Series Manuel utilisateur

Texas Instruments

Texas Instruments TPSM82810EVM Manuel utilisateur

Texas Instruments

Texas Instruments TRF370315 Manuel utilisateur

Texas Instruments

Texas Instruments ADC12J4000EVM Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
