This user’s guide describes the bq24010/2 (bqTINY) evaluation module.

The EVM provides a convenient method for evaluating the performance of a

charge-management solution for portable applications using the bq24010/2

product family. A complete designed and tested charger is presented. The

charger is designed to deliver up to 1.0 A of continuous charge current, but is

programmed for 0.7 A, for single-cell Li-Ion or Li-Pol applications using a dc

power supply.

Topic Page

1.1 Background 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 Performance Specification Summary 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . .

Chapter 1

bqTINY is a trademark of Texas Instruments.

Background

1-2

1.1 Background

The bqTINY series are highly integrated Li-Ion and Li-Pol linear charge

management devices targeted at space limited portable applications. In a

small package, the bqTINY series offer integrated PowerFET and current

sensor, reverse blocking diode, high accuracy current and voltage regulation,

charge status, and charge termination.

The bqTINY charges the battery in three phases: conditioning, constant

current, and constant voltage. Charge is terminated on the basis of minimum

current. An internal charge timer provides backup safety for charge

termination. The bqTINY automatically restarts the charge if the battery

voltage falls below an internal threshold. The bqTINY automatically enters

sleep mode when VCC supply is removed.

In addition to the standard features, different versions of the bqTINY offer a

multitude of additional features. These include temperature-sensing input for

detecting hot or cold battery packs, power good (PG) output indicating the

presence of the ac adapter, a TTL-level charge enable input (CE) to disable

or enable the charge process, and a TTL-level timer and termination-enable

(TTE)input to disableorenablethe fast-charge timer andchargetermination.

1.2 Performance Specification Summary

This section summarizes the performance specifications of the EVM.

Table 1–1 gives the performance specifications of the EVM.

Table 1–1.Performance Specification Summary

Specification Test Conditions Min Typ Max Units

Input dc voltage, VI(DC) VREG+0.5 5.0 5.2†V

Battery charge current, IO(CHG) See note 0.7†A

Power dissipation (V(DC+) –V(BAT+))*I(CHG) 1.5 W

†This input voltage maximum is a function of the maximum allowable power dissipation on the IC. The current level is pro-

grammed for 0.7 amps. If the programmed charge is changed, then the maximum input voltage needs to be adjusted.

PmaxIC = 1.5 Watt = ICHG(VDC+ –VBAT+).

2-1

Test Summary

Thischaptershowsthetestsetupsusedandthetestsperformedinevaluating

the EVM.

Setup: The bq24010/2 EVM board requires a 5-VDC, 1-A power source to

provideinputpowerandasingle-cellLi-IonorLi-Polbatterypack.Thetestset-

upconnectionsandjumpersettingselectionsareconfiguredforastand-alone

evaluation but can be changed to interface with external hardware, such as a

microcontroller.

Topic Page

2.1 I/O and Jumper Connecations 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2 Test Procedure 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Chapter 2

I/O and Jumper Connections

2-2

2.1 I/O and Jumper Connections

Jack Connect To:

J1–DC+ Power supply positive, preset to 5.0VDC, 1-A current limit.

J1–DC–Power supply ground

J2–BAT+ Positive battery pack terminal

J2–BAT–Negative battery pack terminal

J2–TS NC

J2–BAT–NC

J3–STAT1 ExternalhardwareifJ4-EXTisjumpered(Notjumperedfromfactory)

J3–STAT2 ExternalhardwareifJ5-EXTisjumpered(Not jumperedfromfactory)

J3–DC–Return for J3 signals

J3–PG Externalhardware ifJ6–EXTifjumpered(Notjumperedfromfactory)

J4 (Jumper) STAT1 indication location –LED (EVM) | EXT

J5 (Jumper) STAT2 indication location –LED (EVM) | EXT

J6 (Jumper) PG indication location –LED (EVM) | EXT

Note: Factory jumper selections shown in bold.

2.2 Test Procedure

Setuptheevaluationboardasdescribedabove,bymakingthenecessaryI/O

connections and jumper selections. Before test and evaluation, it is

important to verify that the maximum power dissipation on the IC is not

exceeded: P(MAX) = 1.5 watts.

1) Turn on the power supply, which was preset to 5.0 VDC and 1 A for the

current limit setting.

2) The bq24010/2 enters preconditioning mode if the battery is below the

V(LOWV) threshold. In this mode, the bq24010/2 precharges the battery

withalowcurrent(typicallyIO(CHG)/10=0.7A/10=70mA)untilthebattery

voltage reaches the V(LOWV) threshold or until the precharge timer

expires. If the timer expires, then the charge current is terminated, the

bq24010/2entersfaultmode,andbothLEDsturnoff.Togglinginputpower

or battery replacement resets fault mode.

3) Once the battery voltage is above the V(LOWV) threshold, the battery

enters fast-charge mode. This EVM is programmed for 0.7 amps of fast

charging current.

4) Once the battery reaches voltage regulation (4.2 V), the current tapers

down as the battery reaches its full capacity.

5) The battery remains at the fast-charge mode until the fast-charge timer

expires,thechargetapertimeexpires,orthechargeterminationthreshold

is reached.

6) If the battery discharges to the recharge threshold, the charger starts fast

charging.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Texas Instruments Contrôleurs

Texas Instruments

Texas Instruments TPS51100 Manuel utilisateur

Texas Instruments

Texas Instruments TPS65982 Manuel utilisateur

Texas Instruments

Texas Instruments TMS320DM357 Manuel utilisateur

Texas Instruments

Texas Instruments TPS2151 Manuel utilisateur

Texas Instruments

Texas Instruments UCC28600 Manuel utilisateur

Texas Instruments

Texas Instruments TUSB3200EVM2 Manuel utilisateur

Texas Instruments

Texas Instruments TSB12LV26 Guide d'installation et d'utilisation

Texas Instruments

Texas Instruments TPS59640EVM-751 Manuel utilisateur

Texas Instruments

Texas Instruments TMS320x281 series Manuel utilisateur

Texas Instruments

Texas Instruments LM3429 Manuel utilisateur

Texas Instruments

Texas Instruments C2000 Piccolo LaunchPad Manuel utilisateur

Texas Instruments

Texas Instruments TUSB5052 Manuel utilisateur

Texas Instruments

Texas Instruments TMS320C2000 Manuel utilisateur

Texas Instruments

Texas Instruments TMS320DM646 Series Manuel utilisateur

Texas Instruments

Texas Instruments TMS320 2833 Series Manuel utilisateur

Texas Instruments

Texas Instruments bq24133EVM Manuel utilisateur

Texas Instruments

Texas Instruments TMS320C6452 DSP Manuel utilisateur

Texas Instruments

Texas Instruments TMS320x2833x Manuel utilisateur

Texas Instruments

Texas Instruments TMS370 Series Manuel utilisateur

Texas Instruments

Texas Instruments PCI7621 Guide d'installation et d'utilisation

Texas Instruments

Texas Instruments Sitara AM335x Manuel utilisateur

Texas Instruments

Texas Instruments TMDSHVMTRPFCKIT Manuel utilisateur

Texas Instruments

Texas Instruments DLPC3430 Manuel

Texas Instruments

Texas Instruments TMS320C2000 Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur

Texas Instruments bq24010/2 Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques
