Teufel One M

Quick reference guide

For detailed online documentation,

please visit

http://manual.teufelaudio.com

2• One M

Contents

General Notes and Information

Proper use

The speaker is designed for the

playback of music and speech trans-

mitted via cable or wirelessly from an

external player.

Only use the speaker as described

in this quick reference guide and the

online documentation. Any other use

will be deemed as not in accordance

with the instructions and may lead to

damage of property or even persons.

The manufacturer accepts no liability

for damage caused by improper use.

The speaker is intended for private

use.

Safety notes

The enclosed brochure “Impor-

tant product information” contains

general safety notes which you

should always observe to protect

yourself and third parties. Also be

sure to observe any warning notes

contained in this quick reference

guide.

Before operating the product,

please first read the safety

notes, this quick reference

guide and the online documentation

carefully. Only in this way, can you

ensure that all functions are used in a

safe and reliable manner.

Keep the enclosed documents in a

safe place and also be sure to pass it

on to any subsequent owner.

General Notes and Information ........ 2

Unpacking.......................................... 3

Preparations ...................................... 5

Setup.................................................. 5

Getting Started .................................. 6

Operation ........................................... 7

Troubleshooting................................. 9

Declaration Of Conformity...............11

3• One M

Safety notes

Notas de seguridad

Sicherheitshinweise

Consignes de sécurité

Note relative alla sicurezza

Säkerhetsanvisningar

Sikkerhedshenvisninger

Sikkerhetsinstrukser

Turvallisuusohjeita

Important Product Information

Wichtige Produktinformationen

Información importante del producto

Informations produit importantes

Informazioni importanti sul prodotto

Viktig produktinformation

Vigtige produktinformationer

Viktige produktinformasjoner

Tärkeitä tuotetietoja

:DĬQHLQIRUPDFMHSURGXNWRZH

Belangrijke productinformatie

92958_20170619.indd 1 19.06.2017 15:13:52

Unpacking

Package contents

(1) Teufel One M

(2) Mains cord

(3) Brochure “Important product

information”

• Check that all items have been

delivered and that nothing is

damaged. If you find any damage,

do not operate the device; instead

contact our customer service

department (see back side).

• Please keep the packaging for the

duration of the warranty period.

(2)

(3)

(1)

4• One M

(4) (7) (8)(5) (6)

Operational controls and connections

Front side

(4) Skip track forward/back

(5) Turn: Adjust the volume.

Push: Pause/play.

Press and hold: Standby

(6) Direct selection buttons

Push and hold: save current

playback.

Tap: play saved music.

(7) Control button

Tap to switch to the input

LINE IN (9).

Refer to the online documen-

tation for more possibilities to

assign the control button:

http://manual.teufelaudio.com/

controlbutton.

(8) Control LED

Back side top

(9) Audio input (3.5 mm jack) for

external players via LINE-IN.

(10) Network connection (LAN)

(11) Reset button: hold for 8 seconds

while the device is on to reset

the speaker to the factory

default settings.

(12) USB 2.0 jack: for restoring the

firmware and for sharing music *).

(13) Setup button: push during the

setup process once asked to do

so.

(14) Bluetooth pairing button: push

briefly to set the speaker to

pairing mode.

(15) Connector jack for mains

adapter

(9) (10) (11) (12) (15)(13) (14)

5• One M

*)Music saved on a USB stick is

made available under “My music”

if the stick is connected to the

USB port of the host device. In

the network settings, you can see

which device acts as a host in your

system.

Preparations

To be able to integrate Teufel

Streaming products with Raumfeld

technology in your network and

to ensure smooth operation, we

recommend an up-to-date, high

performance router with a broadband

Internet connection.

Make sure that the Wi-Fi router is

active, has the latest firmware and is

able to access the Internet.

To the extent possible, the router

should be positioned in the middle

of your home in order to ensure an

adequate Wi-Fi signal throughout

your home.

Setup

• Set up the speaker in the desired

location and connect it to the

mains supply with the mains cord

(2).

6• One M

• Make sure that your smartphone

or tablet is registered in your home

Wi-Fi.

• Have the Wi-Fi password for your

router ready.

• Load the TEUFEL RAUMFELD APP

from the Play Store/App Store.

• Once you have started the app, the

setup wizard will guide you through

the setup process.

• You can find more information

about setting up your Teufel

streaming system at http://

manual.teufelaudio.com/setup.

The tips in chapter „Trouble-

shooting“ auf Seite 9 should

also be helpful.

TEUFEL RAUMFELD APP

IN THE APPLE APP STORE

TEUFEL RAUMFELD APP

IN THE GOOGLE PLAY STORE

Integration of other devices

in an existing Teufel

streaming system:

‒ You do not have to set up the

entire system again. You can

use the app to add new devices

(under “Settings”).

Getting Started

7• One M

Operation

Standby

Your

One M

switches to standby mode

after a few minutes of inactivity have

elapsed. The timespan leading up to

the beginning of the standby mode

can be configured in the settings

menu within the app. To manually

send the device into standby mode,

simply hold down the play/pause

button (5) for about 2 seconds.

Preset buttons

Your

One M

has 3 programmable

preset buttons(6). They allow you to

access your favourite radio station, a

playlist or any other music with just

the push of a button.

Programming preset buttons

1. Make sure that the One M is oper-

ational.

2. Use the Teufel Raumfeld app to

play any music on your One M (e.g.

a radio station, an album, a playlist

or all tracks of an artist).

3. As soon as the music is played

back, push a preset button and

hold it until you hear a signal tone.

The played back music will be

saved for this preset button.

Accessing saved content

• Tap the preset button to access

saved music with just the push of

a button and to play it back on the

One M.

Control button

Various functions can be assigned to

the control button (7) using the Teufel

Raumfeld app. For a detailed descrip-

tion of the available functions as

well as instructions on how to assign

functions to buttons visit: http://

manual.teufelaudio.com/control-

button.

Spotify Connect

With Spotify Connect, you can play

music on your mobile, tablet or PC

on your One M via the Spotify app.

Please note that you will require

Spotify Premium to use Connect.

1. Connect your One M to your Wi-Fi

network.

2. Open up the Spotify app on your

phone, tablet or laptopusing the

same Wi-Fi network.

3. Play a song and select “Devices

Available”.

4. Select your One M and start liste-

ning.

8• One M

Connecting via Bluetooth®

You can connect compatible devices

such as most smartphones and

tablets to your One M via Bluetooth®

(pairing). The sound of the smart

device is then played by the One M.

1. Turn on the Bluetooth®function on

your smart device.

2. Tap the Bluetooth pairing button

(14) on the back side of the

speaker. The Bluetooth LED in the

button will now blink until pairing

is complete (no more than 60

seconds).

3. Let your smartphone search for

Bluetooth®devices (you can find

more information in the user

manual of your smart device).

“Teufel One M”

should also appear

in the list of detected devices

following the scan.

4. Select “Teufel One M” from the list

of detected devices. If your smart

device requires the entry of a PIN

code, enter the PIN code “0000”

set by factory default.

5. Pairing is now complete and

the smart device is linked to the

One M. The One M will now play

back all sounds that would other-

wise be played by your smart

device.

• To terminate the Bluetooth®

connection, switch the Bluetooth®

function on your smart device off.

9• One M

Troubleshooting

The following advice should help you to solve problems. If this does not work, our

online documentation will provide help:

http://manual.teufelaudio.com

Problem Possible cause/solution

The control LED

is not illumi-

nated.

Make sure that power is supplied. Check to make sure that

the mains cord is securely seated.

Setup fails. Restart your router and your smartphone or tablet.

Set up the device near your router and switch any repeaters

off for the duration of the setup process. If your router

provides guest access, do not use it to connect your Teufel

streaming devices.

Read the notes in our online documentation at: http://

manual.teufelaudio.com/setup.

The app is not

connected or

fails to locate

the configured

streaming

devices.

Make sure that the Teufel streaming devices and the smart

device are operated with the Teufel Raumfeld App on the

same Wi-Fi. Restart your router. Briefly disconnect your

Teufel streaming devices from the power supply and then

start them again.

You can find more information in our online documentation:

http://manual.teufelaudio.com.

I would like to

reset the device.

Notice: By resetting the device, all system configuration

settings will also be reset.

Resetting the device: When the device is switched on, use

a paper clip that has been bent straight to push the reset

button (11) and hold it down until the device restarts (for at

least 8 seconds).

10 • One M

Music playback

skips or is inter-

rupted.

It is possible that one or more Teufel device(s) do not have a

Wi-Fi signal or it is too weak.

Place the devices closer to the router, try alternative setup

locations or connect devices, which are set up far away,

with an Ethernet cable. In the event of problems with multi-

room systems with three or more devices, we recommend

connecting at least one of the devices with an Ethernet cable

and setting it as the host.

As a test, refrain from using repeaters. If applicable, use an

audio stream with low resolution.

Also visit the website of the router manufacturer for tips on

how to improve your Wi-Fi.

You can find more information in our online documentation:

http://manual.teufelaudio.com.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Teufel Intervenants

Teufel

Teufel LT 6 THX Select Manuel utilisateur

Teufel

Teufel L 430 Manuel de la liste des pièces

Teufel

Teufel Concept B 20 Manuel

Teufel

Teufel Bamster XS Manuel utilisateur

Teufel

Teufel LT 4 Complete 5.1-Set L Manuel utilisateur

Teufel

Teufel L 220 FCR Manuel

Teufel

Teufel cinebar 21 Manuel

Teufel

Teufel Ultima 800 Manuel

Teufel

Teufel L 430 FR Manuel

Teufel

Teufel CS 25 Mk3 Manuel

Teufel

Teufel L 430 Manuel de la liste des pièces

Teufel

Teufel T 530 C Manuel de la liste des pièces

Teufel

Teufel Ultima 5 Manuel utilisateur

Teufel

Teufel RADIO ONE Manuel de la liste des pièces

Teufel

Teufel Motiv Go Manuel utilisateur

Teufel

Teufel L 220 FR Manuel utilisateur

Teufel

Teufel Omniton 202 Manuel

Teufel

Teufel Ultima 800 DiY Edition Manuel de la liste des pièces

Teufel

Teufel cinebar 21 mk2 Manuel

Teufel

Teufel Effect Manuel utilisateur

Teufel

Teufel concept b 20 mk2 Manuel utilisateur

Teufel

Teufel Ultima 60 Manuel

Teufel

Teufel MOTIV HOME Manuel de la liste des pièces

Teufel

Teufel S 700 FCR Manuel

Manuels Intervenants populaires d'autres marques

argon audio

argon audio IE20 Manuel utilisateur

Denon

Denon SC-N7 Manuel utilisateur

Gemline

Gemline Ace 3952 Manuel utilisateur

Focal

Focal ON WALL 300 Mode d’emploi

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manuel utilisateur

SoundLogic

SoundLogic BCCS-6/6395 Manuel utilisateur

Peavey

Peavey DTH 218 Manuel utilisateur

Avantree

Avantree Pluto Air Manuel utilisateur

Morel

Morel Integra Series INTEGRA OVATION 4 Manuel utilisateur

Oppo

Oppo SONICA Manuel utilisateur

Bose

Bose SoundLink Wireless Music System Manuel utilisateur

Rocksteady

Rocksteady Stadium Manuel utilisateur

Bowers & Wilkins

Bowers & Wilkins 4 Manuel utilisateur

Sonance

Sonance SONOS OUTDOOR Series Manuel utilisateur

Electro-Voice

Electro-Voice EVID FM4.2 Manuel utilisateur

Pioneer

Pioneer XW-HTD630 Manuel utilisateur

Onn

Onn BWA16AA002 Manuel utilisateur

HP GL313AA - USB Speakers PC Multimedia Manuel utilisateur
