Terex Genie GRC-12 Guide de configuration
Operator's Manual
Serial Number Range
GR
C
™
-
12 from GRCP
-
6000 AUS
Australia
with
Maintenance
Information
Third Edition
First Printing
Part No. 1297727GT
Operator's Manual Third Edition • First Printing
GRC™-12 Part No. 1297727GT
Front Matter
Contents
Introduction ........................................................... 1
Symbol and Hazard Pictorials Definitions............. 6
General Safety ...................................................... 8
Personal Safety................................................... 10
Work Area Safety................................................ 11
Legend ................................................................ 17
Controls............................................................... 18
Inspections.......................................................... 21
Operating Instructions......................................... 34
Transport and Lifting Instructions ....................... 41
Maintenance ....................................................... 46
Specifications...................................................... 48
Copyright © 2008 Terex Corporation
Third Edition: First Printing, September 2020
Genie is a registered trademark of Terex South Dakota, Inc. in
the U.S.A. and many other countries.
“GRC” is a trademark of Terex South Dakota, Inc.
These machines comply with
AS 1418.10
Third Edition • First Printing Operator's Manual
Introduction
Part No. 1297727GT GRC™-12 1
Introducti on
About this manual
Genie appreciates your choice of our machine for
your application. Our number one priority is user
safety, which is best achieved by our joint efforts.
This book is an operation and daily maintenance
manual for the user or operator of a Genie
machine.
This manual should be considered a permanent
part of your machine and should remain with the
machine at all times. If you have any questions,
contact Genie.
Product Identification
The machine serial number is located on the serial
label.
Serial number stamped
on chassis
Serial label located on
chassis
Intended Use and Familiarization
Guide
The intended use of this machine is to lift
personnel, including tools, and materials to an
aerial work site. Before operating the machine, it’s
the operator’s responsibility to read and
understand this familiarization guide.
Each person must be trained to operate a
Mobile Elevating Work Platform (MEWP).
Familiarization with the MEWP must be given
to each person who is authorized, competent
and trained.
Only trained and authorized personnel should
be permitted to operate the machine.
The operator is responsible to read,
understand, and obey the manufacturer’s
instructions and safety rules provided in the
Operator’s Manual.
The Operator’s Manual is located in the
manual storage container, at the platform.
For specific product applications, see
Contacting The Manufacturer.
Operator's Manual Third Edition • First Printing
Introduction
2 GRC™-12 Part No. 1297727GT
Platform controls symbology and related
machine movement:
Lift function enable button
Drive function enable button
Platform up/down (when lift function
selected)
Drive forward/reverse (when drive function
selected)
Steer right/left (when drive function
selected)
Area of operation, indoor use button
Ground controls symbology and related
machine movement:
Lift function enable button
Platform up/down button
Sequential functions and movement:
Drive and steer.
Interlocked functions:
Elevated drive speed.
Elevated drive in an off-level condition.
All platform and ground controls.
Limitations of use:
The intended use of this machine is to lift
personnel, including tools, and materials to an
aerial work site.
Do not elevate the platform unless the machine
is on firm level ground.
Third Edition • First Printing Operator's Manual
Introduction
Part No. 1297727GT GRC™-12 3
Bulletin Distribution and Compliance
Safety of product users is of paramount
importance to Genie. Various bulletins are used by
Genie to communicate important safety and
product information to dealers and machine
owners.
The information contained in the bulletins is tied to
specific machines using the machine model and
serial number.
Distribution of bulletins is based on the most
current owner on record along with their
associated dealer, so it is important to register your
machine and keep your contact information up to
date.
To ensure safety of personnel and the reliable
continued operation of your machine, be sure to
comply with the action indicated in a respective
bulletin.
To view any open bulletins for your machine, visit
us on the web at www.genielift.com.
Contacting the Manufacturer
At times it may be necessary to contact Genie.
When you do, be ready to supply the model
number and serial number of your machine, along
with your name and contact information. At
minimum, Genie should be contacted for:
Accident reporting
Questions regarding product applications and
safety
Standards and regulatory compliance information
Current owner updates, such as changes in
machine ownership or changes in your contact
information. See Transfer of Ownership, below.
Transfer of Machine Ownership
Taking a few minutes to update owner information
will ensure that you receive important safety,
maintenance and operating information that
applies to your machine.
Please register your machine by visiting us on the
web at www.genielift.com or by calling us toll free
at 1-800-536-1800.
Operator's Manual Third Edition • First Printing
Introduction
4 GRC™-12 Part No. 1297727GT
Danger
Failure to obey the instructions and
safety rules in this manual will result
in death or serious injury.
Do Not Operate Unless:
You learn and practice the principles of safe
machine operation contained in this operator’s
manual.
1 Avoid hazardous situations.
Know and understand the safety rules
before going on to the next section.
2 Always perform a pre-operation inspection.
3 Always perform function tests prior to use.
4 Inspect the workplace.
5 Only use the machine as it was intended.
You read, understand and obey the
manufacturer’s instructions and safety
rules—safety and operator’s manuals and
machine decals.
You read, understand and obey employer’s
safety rules and worksite regulations.
You read, understand and obey all applicable
governmental regulations.
You are properly trained to safely operate the
machine.
Safety Sign Maintenance
Replace any missing or damaged safety signs.
Keep operator safety in mind at all times. Use mild
soap and water to clean safety signs. Do not use
solvent-based cleaners because they may damage
the safety sign material.
Third Edition • First Printing Operator's Manual
Introduction
Part No. 1297727GT GRC™-12 5
Hazard Classification
Decals on this machine use symbols, color coding,
and signal words to identify the following:
Safety alert symbol—used to alert
you to potential personal injury
hazards. Obey all safety
messages that follow this symbol
to avoid possible injury or death.
Indicates a hazardous situation
which, if not avoided, will result in
death or serious injury.
Indicates a hazardous situation
which, if not avoided, could result
in death or serious injury.
Indicates a hazardous situation
which, if not avoided, could result
in minor or moderate injury.
Indicates a property damage
message.
DANGER
WARNING
CAUTION
NOTICE
Operator's Manual Third Edition • First Printing
Symbol and Hazard Pictorials Definitions
6 GRC™-12 Part No. 1297727GT
Symbol and Hazard P ictorials Definiti ons
Read the operator’s
manual
Read the service
manual
Crush hazard No smoking Collision hazard
Collision hazard Tip-over hazard Tip-over hazard Electrocution hazard Electrocution hazard
Burn hazard Explosion hazard Fire hazard Batteries used as
counterweights
Tiedown
Voltage rating for
power to platform
Pressure rating for air
line to platform
Keep away from
moving parts
Move machine to
level ground
Lifting & tie down
instructions
Third Edition • First Printing Operator's Manual
Symbol and Hazard Pictorials Definitions
Part No. 1297727GT GRC™-12 7
Maintain required
clearance
Access by trained
and authorized
personnel only
Chock the wheels Release brakes Grounded AC
3-wire only
Replace damaged
wires and cords
Wheel load Lanyard anchorage
points
Side force Manual force
Lifting point Indoor Maximum capacity including occupant, tools,
materials and options
Wind speed
Maximum capacity Auxiliary lowering
+
+
+
Operator's Manual Third Edition • First Printing
General Safety
8 GRC™-12 Part No. 1297727GT
General Safety
