Page 9
©Teradek, LLC 2018. All rights reserved.
Transmitting to a Decoder
Use the following steps to pair the encodcer with a decoder on the same network. To stream to a
decoder over the internet, refer to page 17 for instructions on how to set up a Core account.
Fig. 2-12
1. From the encoder’s front panel, navigate to the Streaming
Setup menu, then select Primary Stream. If using the
web UI, navigate to the Video Stream Output menu, then
select Primary (see page 9).
2. From the decoder’s front panel, navigate to the Decoder
Setup menu. If using the web UI, navigate to the
Video Stream Source menu (Fig. 2-12).
3. Ensure that both the Slice encoder and decoder are on
the same network. Set the streaming mode to MPEG
Transport Stream (Fig. 2-13).
4. Select TCP or UDP as the protocol, enter the decoder’s IP
address in the encoder’s Host field, then enter the port.
Click Apply.
5. Match the decoder’s protocol and port values to the ones
configured on the encoder’s interface, then click Apply.
CHOOSE A STREAMING MODE
Slice encodes and streams video using a variety of stream modes. Use the following steps to view,
modify, or select a streaming mode to best suit your application.
1. Navigate to the Streaming Setup menu using the control
dial, then select Primary Stream. If using the web UI,
navigate to the Video Stream Output menu, then select
Primary (Fig. 2-14).
2. Select one of the following Stream Modes:
Fig. 2-14
● LIVE:AIR ● INTERNET STREAMING
● TERADEK STREAM (TDS) ● RTMP
● SRT ● RTP/RTSP
● MPEG TRANSPORT STREAM
(LICENSE REQUIRED)
● HLS (HTTP LIVE)
See page 18 for Stream Mode descriptions and applications.
Fig. 2-13
