5/6
11. SPARE PART AND ACCESSORIES
Metal cable gland for
armored cable M25 (cable
Ø13-21mm) SET
Pushbutton PBT 01, PBT
02
12. INSPECTION, MAINTENANCE, REPAIR AND OVERHAUL
Inspections are carried out in accordance with IEC 60079-17:2014, general and special conditions of manufacturer and users Regulations
and includes supervision of parts on which the explosion protection depends, especially:
-that the housing and all part of housing without repture and demage,
-that the gasket of cover is undamaged and cover screw are fastened with nominal torque,
-that the actuators and indicators are undemage and enough fixed for housing and cover and gaskets are undemage,
-that the screw of terminal pushbutton, nut of operation heads, cable glands and plugs are fastened with nominal torque,.
All the repairs are performed by the manufacturer or the manufacturer's authorized personal and the original parts must be provided
according to the product documentation, all in accordance with EN 60079-19:2011.
If repair or any other procedure are performed on the product by unauthorized person, all producer responsibility for the product and
the warranty and the manufacturer's declaration of conformity becomes invalid.
13. RESPONSIBILITY AND AUTHORIZATION
This instruction is the basic information about the product. It is completed by the corresponding national laws and regulations.
Production, use, certification and supervision are determined at the national level:
a) Regulations concerning equipment and protective systems intended for use in potentially explosive atmospheres EU
directive 94/9 EC (ATEX 95)
b) Regulations on minimum requirements for safety and health protection of workers and technical inspection of facilities,
equipment, installations and equipment in hazardous areas EU directive 1999/92/EC (ATEX 137).
The responsible person shall ensure their implementation at the working facility.
14. STORAGE AND TRANSPORT
Transportation and warehousing of the lamps is only allowed in the original packaging, as outlined in a cardboard box.
15. MANUFACTURER'S WARRANTY
The manufacturer provides a warranty on the product for a period of one year under the provisions of this user manual and the law on
obligations. This statement has the force of Warranty sheet.
