Tenda Nova MX6 Manuel utilisateur
AX1800/AX3000 Whole Home Mesh Wi-Fi 6 System
MX6/EX6/MX12/EX12
2-pack,3-pack
Quick Installation Guide
MESHbutton
Resetbutton
LANport
Powerjack
LAN/IPTVmultiplexing
port,LANport bydefault
Package contents
Appearance
MX6 (3-pack) & EX6 (3-pack)
MX12 (3-pack) & EX12 (3-pack)
• Mesh6X/Mesh12X x 3
• Power adapters x 3
• Ethernet cable x 1
• Quick installation guide x 1
MX6 (2-pack) & EX6 (2-pack)
MX12 (2-pack) & EX12 (2-pack)
• Mesh6X/Mesh12X x 2
• Power adapters x 2
• Ethernet cable x 1
• Quick installation guide x 1
WAN/LAN multiplexing
port,WANport bydefault
Tips
Donot hold downthe MESH buttonfor8 seconds
ifunnecessary.
Button
MESH
RESET
MESH button.
−As a networking button: Press this button on this
device for about 1 to 3 seconds.The LED indicator
blinks green fast, which indicates the device is
searching for another device to form a network.
Within 2 minutes,press the MESH button of another
device for 1 to 3 seconds to negotiate with this
device.
− As a de-networking button: Press this button for
about 8 seconds and release it when the LED
indicator blinks red fast.The node is restored to
factory settings, and also removed from the
network and no longer automatically joins in again.
Reset button.
When the device completes startup, hold down this
button using a needle-like item (such as a pin) for
about 8 seconds,and then release it when the LED
indicator blinks red fast.The device is reset
successfully.
Description
Tips
Ifyou donot use amodem forinternet access,pleaseskip steps1 and 3.
1. Power off your modem.
2.Use the included Ethernet cable to connect the WAN/LAN1 port to your
modem or the Ethernet jack.
3.Power on your modem.
4.Power on the primary node,and wait until the LED indicator blinks green.
*Choose one device from the kit to connect to the internet as the primary node in the network.
Internet
Gigabit
port
or
Modem (such as
optical modem)
Ethernet jack
Ethernet cable
Power outlet
I Connect the primary node
Method 1: Setup through Tenda WiFi App
1.Download the Tenda WiFi App onto your mobile device by searching for
Tenda WiFi in Google Play or App Store or by scanning the QR code.
Then install the Tenda WiFi App.
2.Connect the mobile phone to the WiFi network of the primary node.The
SSID and password can be found on the bottom label of the device.
TendaWiFi
www.tendacn.com
Made in China
NOVA_XXXX_XX
SSID:
NOVA_XXXX_XX
NOVA_XXXX_XX
Settings
II Connect the primary node to the
internet
3.Run the Tenda WiFi App and follow the onscreen instructions to connect
the device to the internet.After the device is connected to the internet,
its LED indicator lights solid green,and the device has become the
primary node in the network.
LEDindicator
www.tendacn.com
Made in China
NOVA_XXXX_XX
SSID:
NOVA_XXXX_XX
NOVA_XXXX_XX
Settings Wi-Fi
Wi-Fi
2.Start a browser on the client and enter tendawifi.com in the address bar
to access the web UI,and follow the onscreen instructions to connect
the device to the internet.
Method 2: Setup through web UI
1.Connect the client to the primary node.
Method 1: Connect the wireless client such as a mobile phone to the WiFi
network of the primary node.The SSID and password can be
found on the bottom label of the device.
Method 2: Use an Ethernet cable to connect the computer to the LAN2 or
LAN3/IPTV port of the primary node.
Tips
Ifyou cannotlog in tothe webUI,refertoQ3 in FAQ.
Ethernet cable
Or
Power outlet
CHOOSE A NETWORK…
1.Place the other devices in the kit within 3 meters from the primary node
to power them on.Wait for about 3 minutes. When the LED indicators of
these devices light solid green,the networking is successful and these
devices become secondary nodes in the network.
2.Please refer to the following relocation tips to locate the secondary
nodes to a proper position:
• Ensure that the distance between any two nodes is less than 10 meters.
• Keep your nodes away from electronics with strong interference,such as
microwave ovens,induction cookers,and refrigerators.
• Place the nodes in a high position with few obstacles.
LEDindicator
III Extend network
Solid green Networking succeeds. Excellent connection quality.
Tips
Ifthe LED indicatorof secondarynode keepsblinking greenslowly for
morethan3 minutes,relocatethe secondary nodeand moveit closerto
theprimary node.
3.Power on the secondary nodes again till these LED indicators blink
green slowly. The MX6 (3-pack) is taken as an example here.
4.Observe the LED indicator of the secondary nodes until the LED indicator
lights one of the following colors:
Solid yellow Networking succeeds. Fair connection quality.
Solid red Networking succeeds. Poor connection quality.
5.If the secondary node's LED indicator lights solid red,relocate it
according to step 2in III Extend network to get an optimal connection
quality.
Done.
• To access the internet with:
- Wired devices: Connect to the LAN ports of your nodes.
- Wireless devices: Connect to your WiFi network using the SSID and
password you set.(All nodes share the same SSID and password)
• If you configure the nodes using the Tenda WiFi App and you want to
manage the network remotely, tap on the App home page and use your
account to log in.
